Speco CVC-61HRB Specifications

CVC61HRB
CVC61HRW

Features

™
• 1/3" Sony Super-HAD CCD
• 540 TV Lines Super High Resolution
• Compact Size - Only 1.89" In Diameter!
• Vandal Resistant Housing
• Cast Aluminum Construction
• Integrated 3mm Fixed Lens
• Impressive Picture Quality
• IP66 Rated
• 12V DC Required

Specifications

Image Sensor . . . . . . . . . . . . . . . . .1/3" Sony Super-HAD
Horizontal Resolution . . . . . . . . . . .540 TV Lines
Sensitivity . . . . . . . . . . . . . . . . . . . .0.1 Lux
Lens . . . . . . . . . . . . . . . . . . . . . . . .3mm Fixed Lens
Effective Pixels (H x V) . . . . . . . . .768 x 594
Electronic Shutter Speed . . . . . . . .Auto: 1/60 ~ 1/120,000 Seconds
Scanning System . . . . . . . . . . . . . .2:1 Interlace
Synchronization . . . . . . . . . . . . . . .Internal
Frequency . . . . . . . . . . . . . . . . . . .Horizontal: 15.734KHz / Vertical: 60Hz
Video Output . . . . . . . . . . . . . . . . .1.0Vp-p~75 Ohm
S/N Ratio . . . . . . . . . . . . . . . . . . . .>50dB (AGC Off)
Gain Control . . . . . . . . . . . . . . . . . .Auto
White Balance . . . . . . . . . . . . . . . .Auto
IP Rating . . . . . . . . . . . . . . . . . . . .IP66
Operating Temperature . . . . . . . . .-14° F ~ +120° F
Power Supply . . . . . . . . . . . . . . . . .12V DC Required
Power Consumption . . . . . . . . . . . .120mA Max.
Dimensions . . . . . . . . . . . . . . . . . .1.46" H x 1.89" D
Weight . . . . . . . . . . . . . . . . . . . . . .0.25 lbs.
Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specifications without notice and without incurring any obligation.
For more information contact Speco Technologies
200 New Highway, Amityville, NY 11701
www.specotech.com
simply unique.
Black Housing
White Housing
™
• Toll Free: 1-800-645-5516
CCD
Weather/Vandal Resistant
Miniature Color Camera
with 3mm Fixed Lens
Perfect for use in all vehicles or anywhere that a
miniature, aesthetically pleasing, high resolution
camera is desired.
1.89" D
• Fax: 631-957-9142 or 631-957-3880
Shown at actual size
1.89" D
Rev. 7/14/11
