TFT LCD User Manual

Table of Contents

1. Introduction and Package Contents ......................................................................................................
2. System Requirements and Hardware Installation ..................................................................................
3. Monitor and OSD Controls ..................................................................................................................
4. OSD Control Function List ....................................................................................................................
Main Menu (VGA Mode) ............................................................................................................................................
Main Menu (Video Mode) ...........................................................................................................................................
Hot Key .....................................................................................................................................................................
5. Caring for Your LCD Monitor ...............................................................................................................
6. Frequently Asked Questions ................................................................................................................
7. Regulations, Warnings and Maintenance .............................................................................................
8. Technical specifications .......................................................................................................................
1
2
3
4
6
6
19
22
23
24
26
27
TFT LCD Monitor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VM-15LCD and is the answer not in the manual?

Questions and answers

Related Manuals for Speco VM-15LCD

Summary of Contents for Speco VM-15LCD

  • Page 1: Table Of Contents

    4. OSD Control Function List ... Main Menu (VGA Mode) ... Main Menu (Video Mode) ... Hot Key ... 5. Caring for Your LCD Monitor ... 6. Frequently Asked Questions ... 7. Regulations, Warnings and Maintenance ... 8. Technical specifications ...

  • Page 2: Introduction And Package Contents

    Congratulations on your purchase. You can expect only the sharpest and most brilliant color images from this monitor. Featuring easy to use OSD controls and built in speakers, you will find this monitor both easy to use and a pleasure to look at.

  • Page 3: System Requirements And Hardware Installation

    Connect LCD monitor to a PC with a D-sub 15-pin cable. Connect the audio cable from the rear of the LCD monitor to the line-out of your audio card - this step may be omitted if you do not plan to use the LCD monitor's internal speakers...

  • Page 4: Monitor And Osd Controls

    TFT LCD User Manual Monitor and OSD Controls Monitor and OSD Controls The LCD color monitor has a simple control layout for controlling the monitor and OSD (On Screen Display) functions. The table below summarizes the control keys and their related functions. Keys POWER Pressing this key turns he display system power ON/OFF.

  • Page 5: Led Status Display

    TFT LCD User Manual LED Status Display The following table describes the various power states of the LCD monitor as represented by different LED color. Power State LED Color Green Standby Orange Orange No power Blank TFT LCD Monitor...

  • Page 6: Osd Control Function List

    If you push the “MENU” key, will appear this main menu page, you can use the “UP” or “ADJ. +” AND “Down” or “ADJ. –“ key (appear Pic1) to select the function you need. Pic1 The working resolution and frequency are shown at end of the main page. TFT LCD Monitor...

  • Page 7: Auto Setup

    If you select BRIGHTNESS function and push the SELECT key (appear Pic3), you can push ADJ+ or ADJ- key to increase or decrease backlight current of the inverter. You can push SELECT key again to quit this function. Pic2 Pic3 TFT LCD Monitor...
  • Page 8 You can push SELECT key again to quit this function. DISPLAY If you select DISPLAY ADJUST function and push the SELECT key that will into the sub-page (appear Pic5) to adjust display’s function of the picture. TFT LCD Monitor Pic4 Pic5...
  • Page 9 If you select V.POSITION function and push the SELECT key (appear Pic7), you can push ADJ+ or ADJ- key to shift UP or DOWN the picture in vertical position. You can push SELECT key again to quit this function. Pic6 Pic7 TFT LCD Monitor...
  • Page 10 You can push SELECT key again to quit this function. 5. In the VGA mode, the SHARPNESS, HUE and SATURATION functions are disable. 6. EXIT If you select EXIT function and push the SELECT key, this sub-page will back to OSD Main page. TFT LCD Monitor Pic8 Pic9...

  • Page 11: Color Temperature

    If you select 6500K function and push the SELECT key, that could recall the value for the color temperature of 6500K. 4. AUTO GAIN If you select AUTO GAIN function on COLOR TEMPERATURE menu and push the SELECT key, that could active the function for auto white balance adjusting. Pic10 TFT LCD Monitor...
  • Page 12 If you select GREEN function on COLOR TEMPERATURE menu and push the SELECT key (appear Pic12), you can push ADJ+ or ADJ- key to increase or decrease the G gain in user’s mode of color temperature. You can push SELECT key again to quit this function. TFT LCD Monitor Pic11 Pic12...
  • Page 13 If you select EXIT function push the SELECT key, this OSD menu will back to MAIN MENU page. LANGUAGE In this mode, that could into the sub-page (appear Pic14) to select the language for OSD display. Pic13 Pic14 TFT LCD Monitor...

  • Page 14: Osd Display

    If you select OSD H-POS function and push the SELECT key (appear Pic16), you can push ADJ+ or ADJ- key to shift left or right of the horizontal position for OSD display. You can push SELECT key again to quit this function. TFT LCD Monitor Pic15...

  • Page 15: Osd Timer

    If you select OSD TIME function and push the SELECT key (appear Pic18), in this function, you can push ADJ+ or ADJ- key to increase or decrease the time of OSD display. Except, “0” is always display. You can push SELECT key again to quit this function. Pic17 Pic18 TFT LCD Monitor...

  • Page 16: Osd Transparency

    If you select EXIT function and push the SELECT key, this sub-page will back to MAIN MENU page. INPUT SELECT If You select INPUT SELECT function and push the SELECT key that will into the sub-page (appear Pic20) to select input source. TFT LCD Monitor Pic19 Pic20...
  • Page 17 If you select AUDIO function and push the SELECT key, that will into the sub-page (appear Pic21) to adjust the audio function. 1. MUTE If you select MUTE function and push the SELECT key, you can switch the audio mode is mute or volume. Pic21 TFT LCD Monitor...
  • Page 18 3.EXIT If you select EXIT function and push the SELECT key that will back to the MAIN MENU page. EXIT If you select EXIT function and push the SELECT key, the OSD menu will be quit. TFT LCD Monitor Pic22...

  • Page 19: Main Menu (Video Mode)

    If the input signal is from CVBS or S VIDEO, the AUTO SET and COLOR TEMPERATURE functions will be disable. The other functions are same to the VGA mode, except the DISPLAY ADJUST function. (appear Pic23) Pic23 TFT LCD Monitor...

  • Page 20: Display Adjust

    The functions for H. POSITION, V. POSITION, CLOCK and PHASE are same as to VGA mode. SHARPNESS If you select the SHARPNESS function and push the SELECT key, you can adjust the sharpness for the picture by ADJ+ or ADJ-. (appear Pic25) TFT LCD Monitor Pic24 Pic25...
  • Page 21 If you select this HUE function and push the SELECT key, you can adjust the color phase for the picture by ADJ+ or ADJ – key. (appear Pic26) SATURATION If you select this SATURATION function and push SELECT key, you can adjust the color saturation for the picture by ADJ+ or ADJ- key. (appear Pic27) Pic26 Pic27 TFT LCD Monitor...

  • Page 22: Hot Key

    You could push the “ADJ+” or “UP” key to switch the mode of audio mute. You could push the “ADJ-” or “DOWN” key to adjust the volume of audio output. You can push the “SELECT “ key to select input source. TFT LCD Monitor...

  • Page 23: Caring For Your Lcd Monitor

    By following these guidelines you can ensure many years of trouble free use. 1. The LCD monitor's plastic casing and LCD glass panel can be cleaned with a soft, lint-free cloth. Never use scrub pads or other cleaning materials with abrasive surfaces to clean your LCD monitor! a.

  • Page 24: Frequently Asked Questions

    Ensure there is electrical power coming from the AC outlet. Use another device to check for power. Unplug the power cord of the monitor from the AC outlet, wait a few minutes, then plug the power cord into the AC outlet again.
  • Page 25 Make sure the computer is not in a power-saving mode (move the mouse or press a key on the keyboard). No sound coming from the audio speakers The audio cable should be connected to the lineout on the audio card and the line-in on the monitor. Ensure that the audio cable is properly connected.

  • Page 26: Regulations, Warnings And Maintenance

    Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. WARNING: Any unauthorized modification to this equipment could result in the revocation of the authorization to operate the equipment and void the product warranty. TFT LCD Monitor...

  • Page 27: Technical Specifications

    TFT LCD User Manual Technical specifications LCD Monitor Specifications TFT-LCD Monitor scan Horizontal frequency Vertical frequency VESA specifications Physical characteristics Weight Dimensions Tilt Monitor MTBF LCD lamp Operating Storage Humidity LCD Characteristics Active area Pixel pitch Pixel format Response time...
  • Page 28 TFT LCD User Manual Timing Item Remark: 1. The timings with presetting are recommended. 2. Users have to adjust the timing manually, if it is not included in the presetting list. TFT LCD Monitor Resolution H Freq.(kHz) 640x400@70 31.469 640x480@60 31.469...
  • Page 29 Product Do not cover or block the vent holes in the case. Do not insert sharp objects or spill liquid into the LCD monitor through cabinet slots. They may cause accident fire, electric shock or failure. Disconnect the power plug from the AC outlet if you will not use it for an indefinite period of time.
  • Page 30 Ensure that the total ampere rating of all units plugged into the extension cord is not over the cord’s rating. If the power supply cord, which came with your monitor, is to be connected to the PC instead of the wall outlet, this equipment is to be used with UL/TUV approved computers with receptacle rated 100~240V AC, 50/60Hz, 2.0A(minimum).
