- Page 1 Interactive Calming Station SK7393 Installation Manual 57515 June 2022...
-
Page 2: Table Of Contents
Contents Warnings Description Includes Building Cleaning Maintenance Guarantee Contact us Scan QR code for an instructional video. -
Page 3: Warnings
Warnings This product is designed for users with special needs. Adult supervision is required during use at all times. For indoor use only. The equipment uses a mains power supply. We recommend two people to assemble the package. Never use abrasive cleaning pads to clean this item. Description The Interactive Calming Station is a complete standalone sensory resource. -
Page 4: Includes
Includes Right Hand ( RH ) Mirror Panel Left Hand ( LH ) Fiber Optic Sideglow and Light source Right Hand Platform Center Platform Left Hand Platform Bubble Tube or 2 x Power Adapters Color Column 2 x Power Cords Power Strip Carefully check you have all the parts listed. -
Page 5: Building
Placement of Station We always recommend equipment is installed by a qualified professional; however, a competent DIY person would have no problem installing this equipment. An electrical outlet is required within 9' 10" (3 meters). Make sure you have plenty of space to work in and do not attempt to build alone. 1 ) Identify - Left Hand (LH) Platform and remove the top and place on one side for now. - Page 6 The Mirror Panel and the Center Platform are a little larger. The process of attaching them together is exactly the same as the LH and RH side of the sensory station. The mirror section includes key equipment and the cord management. Bringing all the pieces together Position each Platform as shown and prepare to attach together using the M12 bolts, washers and nuts.
- Page 7 7) Feed 2 x power cords from both wall panels into Platforms using the holes provided. 8) Feed 1 x power board through the center hole provided. This provides power equipment from center platform (UK plug shown). Push the complete sensory station into its final location. May require more than two people. 9) Drop the Bubble Tube / Waterless Column into the center platform and feed the Fiber Optic Harness through the front mouse hole.
-
Page 8: Cleaning
Cleaning To clean your wall panels and platforms, wipe with a soft white cloth and mild detergent such as a dishwashing liquid diluted in water. Never use an abrasive cloth or any solvent such as mineral spirits or chlorine based cleaning products. Always unplug power cord from the electrical outlet before cleaning. -
Page 10: Contact Us
Size - 70.8"H x 116"W x 30.5"D (2940 mm x 1810mm x 785mm D) Weight - 379 lbs. (175 KG) Disclaimer No part of this manual may be reproduced in any form or by any means (graphic, electronic or mechanical, including recording, taping, photography or information retrieval system) without express written permission of the publisher of this material.
