- Page 1 SensaSoft™ Musical Lightup Hopscotch MW7277 User Manual 34136 October 2022...
-
Page 2: Table Of Contents
Contents Warnings Description Includes Installation Charging the Floor Pad Panel Operation Troubleshooting Cleaning and Maintenance Guarantee Technical Contact Us... -
Page 3: Warnings
Warnings All our equipment is designed for users with special needs. We suggest supervision at all times when using this equipment. For indoor use only. The panel uses a mains power supply. Do Not use free standing. The panel should be installed securely to the wall. Never use abrasive cleaning pads to clean this item. -
Page 4: Installation
Installation This equipment connects to a power supply. The wall panel is designed to attach to the wall at a convenient height for the users. DO NOT use as standalone equipment. The Floor Pad sits on the floor in front of the wall panel. Both pieces of equipment should be installed in a dry area (indoor only). - Page 5 Step 2 Lift the panel onto the wall bracket. Hook the bracket located on the back of the panel onto the wall bracket. Note: Lift gently and set slowly into place. Make sure the brackets are securely connected. Wall Bracket Drill holes into the wall and use appropriate hardware (wall anchors) to screw the panel onto the wall.
- Page 6 Step 4 Connect the power adapter and plug the power cord into the electrical outlet. Power Cord and Adapter Floor Pad Set Up - Charging USB Charger Cord Typical USB Charger UK version Shown ( Not Supplied ) The Floor Pad uses wireless remote technology to operate the wall panel. It comes with a rechargeable battery that is charged using the supplied USB cord.
-
Page 7: Charging The Floor Pad
Charging the Floor Pad Place the pad on a flat surface. Locate the zipper around the edge of the pad Zipper 1) Open the zipper to half way across the pad where you will find the charging socket in the plastic cover behind the zipper. Charging Socket 2) Plug the USB Lead into pad and into charger. -
Page 8: Panel Operation
Panel Operation The Musical Lightup Hopscotch uses a touch sensitive control panel where every function can be changed. When turning on the display, the panel will show the last display used. For demonstration purposes, we will use the sound bank menu. When turning on or touching the standby button, the splash screen will display and then move on to the Sound Bank Menu. -
Page 9: Troubleshooting
Troubleshooting Q - My Hopscotch display is completely blank and nothing lights up. A - Make sure the power supply is switched on and the power cord is plugged into the electrical outlet. If this still does not work, unplug the panel and check the fuse in the plug. Q - The LEDs are lighting but no sound is coming from the speaker. -
Page 10: Guarantee
Guarantee CONDITIONS OF GUARANTEE This guarantee is in addition to and does not in any way affect any statutory or other rights of consumer purchasers .If within the applicable guarantee period (as shown in 8 below) the appliance proves to be defective by reason of faulty design, workmanship or materials, we undertake subject to the following conditions to have the defective appliance (or any part or parts thereof) repaired or at our discretion replaced free of charge. -
Page 11: Technical
Technical Table 1 Supply Voltage 110 / 240 Power Supply Primary Voltage 110 / 240 Power Supply Secondary Voltage Power Supply Current Rating Power Supply Plug top Fuse Working Load Current Power Supply Compliance EN-FCC UK-CA Complies to: BS EN 60355-1 Generic EMC standards - Emission standard for residential, commercial and light-industrial environments The Hopscotch power supply is fitted with a 3 Amp fuse .
