- Page 1 Fan Oven Instruction Manual Model number(s): RHFEO7004B (SS) For Customer Services & Spare Parts please call 0345 208 8750 or visit us at mda.russellhobbs.com IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Contents Safety Instructions ………………………………………. Product Overview ………………………………………. Positioning ………………………………………. Installation ………………………………………. Usage ………………………………………. 10-14 Cleaning & Maintenance ………………………………………. 15-18 Trouble shooting ………………………………………. Guarantee ………………………………………. Technical specification ………………………………………. Notes ………………………………………. 22-23... -
Page 3: Safety Instructions
Safety Instructions Important note: Please read this booklet before installing and switching on this appliance. The manufacturer assumes no responsibility for incorrect installation and usage as described in this booklet. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand... - Page 4 Safety Instructions • This appliance can only be installed in a well-ventilated place in accordance with existing regulations and ventilation specifications. • This appliance is intended for domestic use and the household environment only. The appliance is not intended for use outside. •...
- Page 5 Safety Instructions • Alcoholic vapours may catch fire in the hot cooking compartment. Never prepare food containing large quantities of drinks with a high alcohol content. Only use small quantities of drinks with a high alcohol content. Open the appliance door with care. •...
-
Page 6: Product Overview
Product overview 1. Oven function dial 5. 2 x Wire shelf 2. Handle 6. 1 x Universal tray & handle 3. Glass window 7. 1 x Wire rack 4. Temperature dial 8. 2 x Distance holding screws Unit & Spare Parts If any of the above parts are missing please contact the customer service team on 0345 208 8750 or visit mda.russellhobbs.com... -
Page 7: Positioning
Positioning • This appliance is to be installed under a counter top or in cabinets. • Avoid damaging the product during installation. • The appliance can only be used safely if it is correctly installed according to the safety instructions. The installer is responsible for ensuring that the appliance works correct when installed. -
Page 8: Installation
Installation Preparation & installation Ensure that there are no electric wires, gas or water pipes in the area where holes are to be made. Components of the appliance may have sharp edges. Wear protective gloves. 1. Ensure that there is an electrical power point within adequate distance of the oven after it has been installed. - Page 9 Installation Electrical connection • WARNING- THIS APPLIANCE MUST BE EARTHED • This appliance is designed to be connected to a 220-240V~50Hz-60Hz AC electricity supply. • Before proceeding with the electrical connection, verify that the current carrying capacity of the system and the isolator / main switch is adequate for the maximum power rating of the oven.
-
Page 10: Usage
Usage Control panel The appliance has an oven function dial and a temperature dial, these are explained below: Oven function dial The oven function dial allows you to set the oven function mode for the oven. The dial has to be rotated clockwise or anti-clockwise to set the required oven function. - Page 11 Symbol Function Convection heating: A fan with a ring heating element on the back of the oven ensures that the heated air is distributed evenly. You can bake cakes, pizza, biscuits, small cakes and puff pastry on two levels at the same time. Eco: Energy-saving cooking mode where the fan distributes the heated air around the food that is emitted from the top and rear heating elements.
- Page 12 Usage The oven cavity • The oven light is located in the cooking compartment. During oven operation, the oven light is on. By turning the function selector to any position, the oven light can also be switched on without the oven heating up. •...
- Page 13 Usage Accessories Warning: • Correct placement of the shelves in the side racks is imperative. This will ensure that food does not fall off or slide out when in the oven or being carefully removed from the oven. • Ensure that you always insert the accessories into the cooking compartment the right way round.
- Page 14 Usage The accessories can be inserted in the oven at 5 different levels. Always insert the accessories as far as they can go to ensure that they do not touch the door glass. Universal Tray Wire Rack For cooking large quantities of food For grilling and roasting.
-
Page 15: Cleaning & Maintenance
Cleaning and Maintenance: Important notes: • The appliance will become hot during operation, allow the appliance to cool down before cleaning. • Do not use any high-pressure cleaners or steam cleaners. • Wash new sponge cloths thoroughly before use. • Do not leave acidic substances (lemon juice, vinegar) on stainless steel parts. •... - Page 16 Cleaning and Maintenance: How to clean: • After each use, clean all surfaces once they have cooled down. If any residue is left (baked-on food, drops of grease etc.), however little, will become stuck to the surface and more difficult to remove later. •...
- Page 17 Cleaning and Maintenance: • Very dirty door seal: If the door seal is very dirty, the appliance door will no longer close properly when the appliance is in use. The fronts of adjacent units could be damaged. Always keep the door seal clean. •...
- Page 18 Cleaning and Maintenance: Removing the Side Racks The side racks in the oven cavity can be removed for deep cleaning. Follow the below steps (ensure the oven & side racks are cold and not hot): 1. Unscrew the small screw at the base of the side support racks. 2.
-
Page 19: Trouble Shooting
Trouble Shooting: Problem Solution The circuit break is defective or turned off check circuit breaker is in working order and that it is not switched off No power Power cut or faulty fuse Check whether other kitchen appliances are working or check in the fuse box to make sure that the fuse for the appliance is working The oven doesn’t heat up... -
Page 20: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship you must contact Customer Services with the original proof of purchase so a replacement or refund can be arranged. Refund or replacement is at the discretion of Customer Services. -
Page 21: Technical Specification
Technical Specification Model number RHFEO7004B (SS) Rated Voltage 220V – 240V ~ 50Hz-60Hz External Dimensions(HxWxD) 595mm x 595mm x 575mm... -
Page 22: Notes
Notes... - Page 23 Notes...
- Page 24 Russell Hobbs is a registered trademark used under license from Spectrum Brands (UK) Ltd. Made under license by Product Care Trading Limited, Wigan, WN2 4AY/ PCT (NI) Ltd, Belfast, BT5 5AD Russell Hobbs Support: call 0345 208 8750 or visit: mda.russellhobbs.com The ‘wheelie bin’...
