BULLDOG EVC300 QUICK
START
EVC300
CONTROLLER
QUICKSTART
GUIDE
Bulldog EVC300 Controller QuickStart Guide - Rev_D - Master

Advertisement

loading
Need help?

Need help?

Do you have a question about the Eco Net Controls EVC300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bulldog Security Eco Net Controls EVC300

  • Page 1 BULLDOG EVC300 QUICK START EVC300 CONTROLLER QUICKSTART GUIDE Bulldog EVC300 Controller QuickStart Guide - Rev_D - Master...

  • Page 2: Basic Controller Functions

    Bulldog EVC300 Controller QuickStart Guide CONTROLLER Basic Controller Functions Press to open or close Bulldog Motor. Press to reset leak alarm. Press to pair leak sensors, emergency stop buttons, and remote buttons.

  • Page 3: Controller Leds

    Bulldog EVC300 Controller QuickStart Guide Controller LEDs LED above – Current System State • (Green): System is armed and ready. Valve is open. • (Red): System is armed and ready. Valve is closed. • (Green, Red): Valve Motor is not fully closed, not fully open, or the Valve Motor control wire is not connected.
  • Page 4 Bulldog EVC300 Controller QuickStart Guide LED next to – Current Valve Controller Command • (Red): Valve is set to open. • (No Colour): Valve is set to closed.
  • Page 5 Bulldog EVC300 Controller QuickStart Guide LED above – Wi-Fi Status • (Solid Blue): Your Bulldog Controller is connected to Wi-Fi. • (Blinking Blue): Your Bulldog Motor is closed. NOTE: To connect your controller to Wi-Fi, please see your EVC300 Wi-Fi Connectivity Guide.

  • Page 6: Device Pairing

    Bulldog EVC300 Controller QuickStart Guide Device pairing NOTE: All devices included with your Starter Kit have already been paired with your Bulldog Controller. Pairing Leak Sensors 1. Press the button. 2. Place a leak sensor on a wet paper towel and allow it to go through 2-3 beep cycles.

  • Page 7: Unpairing Devices

    Bulldog EVC300 Controller QuickStart Guide Pairing Optional Remote Button or Emergency Stop Button 1. Press the button. 2. Press and hold the Remote button. Unpairing Devices All paired devices can be removed by pressing and holding the button for 5 seconds until the red LED blinks.
  • Page 8 Bulldog EVC300 Controller QuickStart Guide MAINTENENCE Maintenance should be performed every 6 months to ensure your device is armed and in working order. Check Leak Sensor Battery NOTE: Testing a Leak Sensors will trigger a leak alert. 1. Set your leak sensor on a wet paper towel. 2.
  • Page 9 Bulldog EVC300 Controller QuickStart Guide Replace Leak Sensor Battery 1. Twist the leak sensor lid counterclockwise and lift. 2. Replace the battery with Type A23 12 Volt only.
  • Page 10 Bulldog EVC300 Controller QuickStart Guide 3. Line up alignment marks. Close and lock with clockwise twist. Check Bulldog Functionality 1. Close your bulldog water valve using the button. 2. Turn on the water at highest point in the building and observe water flow after 10 seconds.
  • Page 11 Bulldog EVC300 Controller QuickStart Guide SUPPORT...
  • Page 12 Bulldog EVC300 Controller QuickStart Guide Econet Support Email: support@econetcontrols.com Econet Support Phone: (888) 320-9188 Leak Sensor Range Support Link: https://www.econetshop.com/PDF/ SensorRange.pdf Additional Support Page Link: https://www.econetshop.com/ index.php/support/ Leak Sensor Pairing Video Link: https://www.youtube.com/ watch?v=otzdhZbWBp4&t=146s Bulldog EVC300 Controller QuickStart Guide – Rev_D...
