- Page 1 USER’S MANUAL Study Desk with Chair HW70403 THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
-
Page 2: Before You Start
Before You Start Read each step carefully before starting. It is very important to ensure each step followed in correct order, otherwise assembly difficulties may occur. Most of board parts are labeled or stamped on the raw edges. Have a check to make sure all parts are included. Work in a spacious area, preferably on a carpet close to where the unit will be used. - Page 3 A x1 B x1 C x1 Top Panel Front Frame Panel Back Frame Panel D x1 E x1 F x1 Leg Frame (Right) Leg Frame (Left) Drawer G x2 H x1 I x1 Leg Frame Drawer Runner Rail Chair Leg (Right) J x1 K x1 L x1...
- Page 4 1 x1 2 x6 3 x6 Allen Key M4x110mm JCBC Bolt Flat Washer With Ball Blk M6x60mm 1/4"IDx13mmOD 4 x6 5 x6 6 x4 Pan Head Spring Washer Barrel Nut Chipboard Screw 1/4" M6x13mm Zn M4x32mm Rbw 7 x10 8 x1 9 x1 Pan Head Flat Head...
- Page 5 LEFT RIGHT...
- Page 6 Ensure that the hole for Barrel Nut (5) is facing outside. Outside View BottomView Place the fixed frame according to the corner marking made on Top Panel (A). Corner Marking FRONT VIEW Corner Marking...
- Page 7 BACK VIEW...
-
Page 8: Complete Assembly
MARKING HOLE COMPLETE ASSEMBLY... -
Page 9: Care And Maintenance
Care and Maintenance Use a soft, clean cloth that will not scratch the surface when dusting. Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area. Using solvents of any kind on your furniture may damage the finish. Never use water to clean your furniture as it may cause damage to the finish. - Page 10 Contact our friendly customer service department for help first. Replacements for missing or damaged parts will be shipped ASAP ! US office: Fontana UK office: Ipswich AU office: Truganina Contact Us ! Do NOT return this item. US:cs.us@costway.com UK:cs.uk@costway.com AU:cs.au@costway.com...
