VGX-TP1 Series
Meet your
Conozca su computadora personal
System unit and supplied items
Unidad principal y artículos suministrados
B
A
F
E
J
K
A
B
C
Main unit
Rear cover
AC adapter
Unidad principal
Cubierta posterior
Adaptador de CA
F
G
Remote commander
Remote sensor control
Control remoto
Control del sensor remoto
K
L
HDMI to DVI-D adapter
AV cable adapter
Adaptador HDMI a DVI-D
Adaptador de
cable de AV
* Use this screw, which comes in a bag with the wireless LAN antenna, to mount the wireless LAN antenna to a wall.
Use este tornillo, que viene en una bolsa con la antena de LAN inalámbrica, para montar la antena en la pared.
** Supplied in a box with other cables.
Incluido en una caja con otros cables.
The illustrations in this document may appear different from your model, depending on the country or area of your residency.
Es posible que las ilustraciones de este documento difieran de su modelo, según su país o región de residencia.
¡IMPORTANTE!
Por favor lea detalladamente este manual de instrucciones antes de conectar y operar este equipo. Recuerde que un mal uso de su aparato podria anular la
garantia.
3-093-638-11 (1) © 2007 Sony Corporation
personal computer
Serie VGX-TP1
C
D
G
H
I
L
M
N
O
D
E
Power cord
Wireless keyboard
Cable de alimentación
Teclado inalámbrico
H
I
J
AA batteries (6)
TV coaxial cable
Baterías AA (6)
Cable coaxial de TV
M
N
O
Wireless LAN antenna
Screw *
Digital TV tuner **
Antena de LAN inalámbrica
Tornillo *
Sintonizador de TV
digital **
Printed in China

To turn on your computer

Para encender la computadora
Before starting your computer for the first time, do not connect any other hardware except a display (TV) that did not originally come with your computer.
Make sure to start up your computer with only the supplied accessories connected and set up your system. Upon completion, connect one device (for
example, a printer, an external hard disk drive, a scanner, and so on) at a time, following the manufacturers' instructions.
Antes de iniciar por primera vez su computadora, no conecte ningún hardware a excepción de una pantalla (TV) que no venga incluido originalmente
con la computadora. Asegúrese de iniciar su computadora sólo con los accesorios suministrados que están conectados y de configurar su sistema.
Una vez finalizado lo anterior, conecte un dispositivo (por ejemplo, una impresora, una unidad de disco duro externa, un escáner, etc.) a la vez, de
acuerdo con las instrucciones del fabricante.
1

Connect a Display (TV)

1
Connect a display (not supplied) to your computer. When
connecting it, see the manual that came with your display
as well.
2

Connect the AC Adapter

1
Plug one end of the power cord 1 into the AC adapter 3.
2
Plug the other end of the power cord and the power cord
from your display into AC outlets 2.
3
Route the cable from the AC adapter 3 through the hook
4 on the back of your computer and plug it into the DC IN
port 5.
3

Attach the Rear Cover

1
Once you have set up your computer, attach the rear
cover. Be sure to hold the cover with your both hands
HDMI cable
when attaching it.
Cable HDMI

Power On

4
1
Press the power button of the main unit until the power
indicator turns on.
Conecte una pantalla (TV)
1
Conecte una pantalla (no suministrada) a la computadora.
Al conectarla, también consulte el manual que viene con
la pantalla.
Conecte el adaptador de CA
1
Conecte un extremo del cable de alimentación 1 al
adaptador de CA 3.
2
Conecte el otro extremo del cable de alimentación y el cable
de alimentación de su pantalla a tomas de alimentación de
CA 2.
3
Haga pasar el cable del adaptador de CA 3 a través del
gancho 4 ubicado en la parte posterior de la computadora y
conéctelo en el puerto DC IN 5.
5
3
2
1
4
Instale la cubierta posterior
1
Luego de configurar la computadora, coloque la cubierta
posterior. Sostenga la cubierta con ambas manos mientras
la instala.
Encienda la computadora
1
Pulse el botón de encendido de la unidad principal hasta
que el indicador de encendido se ilumine.
