- Page 1 ＰＴ－ＰＳＥ１０５ＧＢＳ－Ｄ－１０ 10G Fiber to 802.3bt PoE++ Converter Ｑｕｉｃｋ Ｉｎｓｔａｌｌａｔｉｏｎ Ｇｕｉｄｅ www.procetpoe.com...
- Page 2 Ｄｅｃｌａｒａｔｉｏｎ This document belongs to PROCET company. It is not allowed to reproduce and modify without the original author's permission. It is PROCET's policy to improve its products as new technology, components, software, and firmware at any time. PROCET, therefore, reserves the right to change specifications without prior notice.
- Page 3 Ｏｖｅｒｖｉｅｗ The installation Guide for PT-PSE105GBS-D-10 and mainly introduces the hardware specification, installation methods, and precautions of the installation. There may be differences in the appearance and configuration from other models. All product images in this manual are for illustration purposes only and may differ from the actual product.
- Page 4 Ｔａｂｌｅ ｏｆ ｃｏｎｔｅｎｔｓ １. Ｉｎｔｒｏｄｕｃｔｉｏｎ １．１ Ｉｎｔｒｏｄｕｃｔｉｏｎ．．．． ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０１ １．２ Ａｐｐｅａｒａｎｃｅ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０１ １．３ Ｓｐｅｃｉｆｉｃａｔｉｏｎ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０３ ２．Ｉｎｓｔａｌｌａｔｉｏｎ Ｐｒｅｐａｒａｔｉｏｎ ２．１ Ｐａｃｋａｇｅ ｃｏｎｔｅｎｔｓ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０４ ２．２ Ｉｎｓｔａｌｌａｔｉｏｎ ｔｏｏｋｉｔｓ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０４ ２．３ Inspection ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０４ ３．Ｉｎｓｔａｌｌａｔｉｏｎ ３．１ Ｉｎｓｔａｌｌing ｉｎ ｗａｔｅｒｐｒｏｏｆ ｃａｓｅ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０６ ３．２ Cｏｎｎｅｃｔｉｏｎ．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０８ ３．３ Grounding．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．０８ ３．４ Inspection．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．．１０ Ｔａｂｌｅ ｏｆ ｃｏｎｔｅｎｔｓ...
- Page 5 １． Ｉｎｔｒｏｄｕｃｔｉｏｎ １．１ Ｉｎｔｒｏｄｕｃｔｉｏｎ PT-PSE105GBS-D-10 is a single-port media converter with PoE function. The single PoE output port delivers 1.75A up to 95W(max) power for remote PDs over 4 pairs. Equipped detecting chip inside which will make the PoE identification handshake with IEEE802.3af/at/bt PDs. Such as PTZ cameras, wireless APs, base stations, and other PoE-powered devices which need high power watts.
- Page 6 Ｓｉｄｅ Ｖｉｅｗ ＤＩＮ Ｒａｉｌ Mounting Bracket １－２ Ｓｉｄｅ Ｖｉｅｗ Ｆｒｏｎｔ Ｖｉｅｗ ＳＦＰ Ｉｎｐｕｔ ｐｏｒｔ ＰｏＥ Ｏｕｔｐｕｔ Ｐｏｒｔ Ｄａｔａ Ｉｎｄｉｃａｔｏｒ PoE Load Indicator DC Power Indicator １－３ Ｆｒｏｎｔ Ｖｉｅｗ ０２ Ｉｎｔｒｏｄｕｃｔｉｏｎ...
- Page 7 １．３ Ｓｐｅｃｉｆｉｃａｔｉｏｎ Items Ｄｅｓｃｒｉｐｔｉｏｎ Ｉｎｐｕｔ ５０－５７Ｖｄｃ ２．０Ａ ４８－５５Ｖｄｃ １７５０ｍＡ Ｏｕｔｐｕｔ Ｐｏｗｅｒ Ｐｉｎｓ ４／５（＋）， ７／８（－） ＆ ３／６（＋）， １／２（－） ＰｏＥ Ｓｔａｎｄａｒｄ ＩＥＥＥ８０２．３ａｆ／ａｔ／ｂｔ １００Ｍ／１０００Ｍ／２．５Ｇ／５Ｇ／１０Ｇ, １０Ｇ ＳＦＰ＋ Ｄａｔａ Ｓｐｅｅｄ －４０℃ ｔｏ ６５℃ Ｗｏｒｋ Ｔｅｍｐ． ２０％－８０％，ｎｏｎ－ｃｏｎｄｅｎｓａｔｉｏｎ Ｏｐｅｒａｔｉｎｇ Ｈｕｍｉｄｉｔｙ Ｕｐ ｔｏ ５０００Ｍ Ｏｐｅｒａｔｉｎｇ Ａｌｔｉｔｕｄｅ Ｓｔｏｒａｇｅ Ｔｅｍｐ． －４０℃ to ８５℃ Ｓｔｏｒａｇｅ Ｈｕｍｉｄｉｔｙ １０％－９０％，ｎｏｎ－ｃｏｎｄｅｎｓａｔｉｏｎ Ｎｅｔｗｏｒｋ Ｐｒｏｔｏｃｏｌ ＩＥＥＥ８０２．３ｕ／ａｂ／ｂｚ／ａｎ ＩＥＥＥ８０２．３ａｅ ＣＥ ＦＣＣ Regulatory Compliance ＩＰ４０ ＩＰ Ｒａｔｅｄ １４４．５ｍｍ×９５ｍｍ×３５．４ｍｍ （４８５ｇ） Ｄｉｍｅｎｓｉｏｎｓ & NW ＥＮ ５５０３２:２０１５／Ａ１１: ２０２０ ＥＭＣ...
- Page 8 ２．Ｉｎｓｔａｌｌａｔｉｏｎ Ｐｒｅｐａｒａｔｉｏｎ ２．１ Ｐａｃｋａｇｅ ｃｏｎｔｅｎｔｓ Ｏｐｅｎ ｔｈｅ ｂｏｘ ｏｆ ｔｈｅ ＰＴ－ＰＳＥ105GBS-D-10 ａｎｄ ｃａｒｅｆｕｌｌｙ ｕｎｐａｃｋ ｉｔ， ｔｈｅ ｂｏｘ ｓｈｏｕｌｄ ｃｏｎｔａｉｎ ｔｈｅ ｆｏｌｌｏｗｉｎｇ ｉｔｅｍｓ： Ｇｒｏｕｎｄ ＰＴ－ＰＳＥ１０５ＧＢＳ－Ｄ－１０ Ｕｓｅｒ ｍａｎｕａｌ ｌｕｇ Ｗｉｒｅ＆ ２．５ ｓｃｒｅｗ ２．２ Ｉｎｓｔａｌｌａｔｉｏｎ ｔｏｏｌｋｉｔ Ｔｈｅｓｅ ｔｏｏｌｓ ｍａｙ ｂｅ ｎｅｅｄｅｄ ｄｕｒｉｎｇ ｅｑｕｉｐｍｅｎｔ ｉｎｓｔａｌｌａｔｉｏｎ， ａｎｄ ｓｈｏｕｌｄ ｂｅ ｐｒｅｐａｒｅｄ ｂｙ ｙｏｕｒｓｅｌｆ： ｌｅｖｅｌ ｒｕｌｅｒ， ｍａｒｋｉｎｇ ｐｅｎ， ｃｒａｆｔ ｋｎｉｆｅ， ｗｉｒｅ ｓｔｒｉｐｐｅｒ， ｎｅｔｗｏｒｋ ｐｌｉｅｒｓ， ｉｍｐａｃｔ ｄｒｉｌｌ，ｄｉｆｆｅｒｅｎｔ ｍａｔｃｈｉｎｇ ｄｒｉｌｂｉｔｓ， ｒｕｂｂｅｒ ｈａｍｍｅｒ， ｃｒｏｓｓ ｓｃｒｅｗｄｒｉｖｅｒ， ｗｒｅｎｃｈ， ｌａｄｄｅｒ， ｅｔｃ． ２．３ Ｉｎｓｐｅｃｔｉｏｎ ２．３．１ Ｃｏｎｎｅｃｔ ｔｈｅ ｄｅｖｉｃｅ ｔｏ ａ ＤＣ Ｐｏｗｅｒ Ｓｙｓｔｅｍ ａｎｄ ｃｈｅｃｋ ｔｈｅ ＰＷＲ ＬＥＤ ｔｏ ｅｎｓｕｒｅ ｐｒｏｐｅｒ ｆｕｎｃｔｉｏｎ ｂｅｆｏｒｅ ｉｎｓｔａｌｌａｔｉｏｎ． ２．３．２ Ｃｏｎｎｅｃｔ ｔｈｅ ＰｏＥ ｐｏｒｔ ｔｏ ｔｈｅ ＰｏＥ ｐｏｗｅｒｅｄ ｄｅｖｉｃｅ（ＰＤ）． Ｓｕｃｈ ａｓ ｔｈｅ ＩＰ Ｃａｍｅｒａｓ ｏｒ Ｗｉｒｅｌｅｓｓ ＡＰｓ． Ａｓ ｓｈｏｗｅｄ ｉｎ Ｆｉｇｕｒｅ ２－１； Ｃａｕｔｉｏｎ： Ｐｌｅａｓｅ ｕｓｅ ＰｏＥ ｐｏｗｅｒｅｄ ｄｅｖｉｃｅ（ＰＤ） ｔｈａｔ ｃｏｍｐｌｉｅｓ ｗｉｔｈ IEEE802.3af/at/bt to connect this product. ０４ Ｉｎｓｔａｌｌａｔｉｏｎ Ｐｒｅｐａｒａｔｉｏｎ...
- Page 9 2. Please place it in a well-ventilated and dry area, and it is for indoor use only. 3. Connect the DC power cable with positive and negative wires into the DC terminal block of Procet Injector. 4. Connect a fiber cable with SFP+ optical module at 10G from your switch into the injector's SFP slot for data Input.(The optical module does not include in the...
- Page 10 ３． Ｉｎｓｔａｌｌａｔｉｏｎ This product is safe to use for waterproof case installation and wall-mounted installation. ３．１ Ｉｎｓｔａｌｌａｔｉｏｎ ｉｎ ｗａｔｅｒｐｒｏｏｆ ｃａｓｅ Ｉｆ ｉｔ ｉｓ ｐｌａｃｅｄ ｉｎ ａｎ ｏｕｔｄｏｏｒ ｅｎｖｉｒｏｎｍｅｎｔ， ｐｌｅａｓｅ ｉｎｓｔａｌｌ ｔｈｅ ｄｅｖｉｃｅ ｉｎ ａ ｗａｔｅｒｐｒｏｏｆ ｃａｓｅ ａｎｄ ｗｉｔｈ ａ ｈｅｉｇｈｔ ｏｆ ４５ｃｍ ｉｆ ｐｏｓｓｉｂｌｅ． ３．１．１ Ｉｎｓｔａｌｌ ｔｈｅ ｗａｔｅｒｐｒｏｏｆ ｃａｓｅ ｆｉｒｓｔ， ａｎｄ ｋｅｅｐ ｔｈｅ ｃａｓｅ ｏｐｅｎ． As showed in 3-1. Backplate Ｃａｂｌｅ ３－１ Ｗａｔｅｒｐｒｏｏｆ ｃａｓｅ ０６ Ｉｎｓｔａｌｌａｔｉｏｎ...
- Page 11 ３．１．２ Ｒｅｍｏｖｅ ｔｈｅ ｍｅｔａｌ ｂａｃｋｐｌａｔｅ ｆｒｏｍ ｔｈｅ ｗａｔｅｒｐｒｏｏｆ case ａｎｄ fix the DIN rail bracket on the backplate, then ｉｎｓｔａｌｌ ｔｈｉｓ ｐｒｏｄｕｃｔ on ＤIＮ ｒａｉｌ bracket. As showed in 3-2. Backplate ＤＩＮ Ｒａｉｌ ＤＩＮ Ｒａｉｌ Ｒａｉｌ Ｍｏｕｎｔｉｎｇ Ｓｃｒｅｗs ３－２ Ｉｎｓｔａｌｌａｔｉｏｎ ３．１．３ Rｅｉｎｓｔａｌｌ ｔｈｅ ｂａｃｋｐｌａｔｅ ｗｉｔｈ ｔｈｅ ｉｎｓｔａｌｌｅｄ ｐｒｏｄｕｃｔ ｉｎｔｏ ｔｈｅ ｗａｔｅｒｐｒｏｏｆ case. Ｃａｕｔｉｏｎ： Ｐｌease ｕｓｅ ｔｈｅ ｅｘｐａｎｓｉｏｎ ｂｏｌｔｓ, when you install the product with wall-mounted way. Ｉｎｓｔａｌｌａｔｉｏｎ ０７...
- Page 12 ３．２ Ｃｏｎｎｅｃｔｉｏｎ Ａｆｔｅｒ ｉｎｓｔａｌｌａｔｉｏｎ ｉｓ ｄｏｎｅ， ｔｈｅ ｎｅｘｔ ｓｔｅｐ ｉｓ ｔｈｅ ｃｏｎｎｅｃｔｉｏｎ. The following precautions should be taken when connecting the Ethernet cable: ３．２．１ Ｌａｙ ｔｈｅ ｃａｂｌｅ ａｃｃｏｒｄｉｎｇ ｔｏ ｔｈｅ ｄｅｓｉｇｎ ｒｅｑｕｉｒｅｍｅｎｔｓ． Ｔｈｅ ｃａｂｌｅ ｓｈｏｕｌｄ ｂｅ ｌａｉｄ ｆｉｒｍｌｙ ａｎｄ ｎｅａｔｌｙ， ｗｉｔｈ ｎｏ ｃｒｏｓｓｉｎｇ， ｔｗｉｓｔｉｎｇ， ｏｒ ｃｒａｃｋｉｎｇ． ３．２．２ Ｄｏ ｎｏｔ ｌａｙ ｔｈｅ ｃａｂｌｅ ｔｏｇｅｔｈｅｒ ｗｉｔｈ ｈｉｇｈ－ｖｏｌｔａｇｅ ｐｉｐｅｌｉｎｅｓ， ｆｉｒｅ ｐｉｐｅｌｉｎｅｓ， ｏｒ ｂｕｉｌｄｉｎｇ ｌｉｇｈｔｎｉｎｇ ｐｒｏｔｅｃｔｉｏｎ ｓｙｓｔｅｍｓ ｔｏ ａｖｏｉｄ ｉｎｔｅｒｆｅｒｅｎｃｅ ｆｒｏｍ ｓｔｒｏｎｇ ｅｌｅｃｔｒｉｃｉｔｙ ｏｒ ｍａｇｎｅｔｉｓｍ． ３．２．３ Ｕｓｅ ＰＶＣ ｐｉｐｅｓ， ｉｒｏｎ ｐｉｐｅｓ， Ｐｒｉｌｋａ ｐｉｐｅｓ， ｏｒ ｃａｂｌｅ ｔｒａｙｓ ｆｏｒ ｃａｂｌｅ ｌａｙｉｎｇ． Ｔｈｅ ｃａｂｌｅ ｔｒａｙｓ ｓｈｏｕｌｄ ｂｅ ｐｌａｃｅｄ ａｇａｉｎｓｔ ｔｈｅ ｗａｌｌ， ｗｉｔｈ ｎｅａｔ ａｎｄ ｂｅａｕｔｉｆｕｌ ｒｏｕｔｉｎｇ． Ｓｏｆｔ ｈｏｓｅｓ ｏｒ ｅｌｂｏｗ ｊｏｉｎｔｓ ｓｈｏｕｌｄ ｂｅ ｕｓｅｄ ａｔ ｔｕｒｎｉｎｇ ｐｏｉｎｔｓ． Ｔｈｅ ｃａｂｌｅ ｔｒａｙｓ ｓｈｏｕｌｄ ｂｅ ｓｅｃｕｒｅｄ ｗｉｔｈ ｃａｂｌｅ ｔｉｅｓ， ｈａｎｇｅｒｓ， ａｎｄ ａｎｇｌｅ ｓｔｅｅｌｓ ａｔ ａ ｓｐａｃｉｎｇ ｏｆ １ ｔｏ １．５ ｍｅｔｅｒｓ． Ｉｆ ａ ｍｅｔａｌ ｃａｂｌｅ ｔｒａｙ ｉｓ ｕｓｅｄ， ｉｔ ｓｈｏｕｌｄ ｂｅ ｇｒｏｕｎｄｅｄ ａｔ ｂｏｔｈ ｅｎｄｓ． ３．２．４ Ｆｏｒ ｏｕｔｄｏｏｒ ｈｏｒｉｚｏｎｔａｌ ｗｉｒｉｎｇ， please use ａ ｓｌｏｔ ｅｖｅｒｙ ６ ｍｅｔｅｒｓ ｕｎｄｅｒ ｔｈｅ ＰＶＣ ｐｉｐｅ ａｓ ａ ｄｒａｉｎ ｔｏ ｐｒｅｖｅｎｔ ｗａｔｅｒ ａｃｃｕｍｕｌａｔｉｏｎ ｉｎｓｉｄｅ ｔｈｅ ｐｉｐｅ． 3.2.5 The wall penetration for the Ethernet cable should be sealed with waterproof and flame-retardant materials.
- Page 13 ＧＮＤ Ｔｅｒｍｉｎａｌ ２．５ Ｓｃｒｅｗ Ｇｒｏｕｎｄｉｎｇ Ｂｕｓｂａｒ ３－３ Ｇｒｏｕｎｄｉｎｇ For the safety of personnel and equipment in an environment without dedicated grounding equipment, a simple grounding device can be constructed as follows: a. Prepare a 6mm 2 grounding wire or a braided soft copper wire. b.
- Page 14 ＧＮＤ Ｔｅｒｍｉｎａｌ ２．５ Ｓｃｒｅｗ Ｇｒｏｕｎｄ Ｓｏｉｌ 2200 ３－４ Ｓｉｍｐｌｅ Ｇｒｏｕｎｄｉｎｇ ３．４ Ｉｎｓｐｅｃｔｉｏｎ Inspect the installed equipment before putting it into operation： · Make sure the PD is compliant with our product. · Make sure the Ethernet cable connection is correct. Make sure all connections are correct, and turn on the power, inspect all the indicators.
- Page 15 Qualification Card PASS Ｃｒｅａｔｉｖｅ Ｌｉａｎｊｉｅ Ｎｅｔｗｏｒｋ Ｔｅｃｈｎｏｌｏｇｙ Ｃｏ．Ｌｔｄ ｗｗｗ．ｐｒｏｃｅｔｐｏｅ．ｃｏｍ...
