CFORCE CF011C Pro Manual page 11

便携式显示器带有两种类型的视频端口
支持大多数主流计算机或者游戏主机视频输入
The portable monitor comes with two types of video ports
that support most mainstream computer or game console video inputs
更多视频设备连接方式
5.PS4/5/Xbox/
Method of connecting PS4/5/Xbox/more video devices
请将CFORCE提供的电源适配器连接到①全功能USB-C接口，显示屏
通电后，使用CFORCE提供的视频线连接到③视频接口，再将另一端
连接到PS4/5/Xbox/更多视频设备；
Please connect the power adapter provided by CFORCE to the ① full-featured
USB-C interface. After the display is powered on, use the video cable provided
by CFORCE to the ③ video interface, and then connect the other end to the
PS4/5/Xbox/more video devices;
操作注意事项：
1.两个USB-C口均可作为视频输入或电源输入。但它们不能同时用于相
同的功能。(例如：如果一个 USB-C 端口用于电源输入，另一个USB端口用
于视频输入)。
2.如果便携式显示器需要外接电源，请先连接电源线，然后再连接视
频线。这对于高质量和流畅的视频信号传输很重要。
3.便携式显示器未连接外接电源时。节能模式将自动开启并限制最大
亮度和最大音量。如果将亮度和音量调节到70%以上，请确保有5V2A
或以上的外接电源已连接。电量不足可能会导致便携式显示器关闭或重
新启动。
Operational notes:
1. Both USB-C ports can be used as video input or power input. But they cannot
be used for the same function at the same time. (Example: if one USB-C port is
for power input, the other USB port is for video input).
2. If the portable monitor needs to be connected to an external power supply,
please connect the power cable before connecting the video cable. This is
important for high quality and smooth video signal transmission.
3. When no external power supply is connected to the portable monitor. Energy
saving mode will automatically turn on and limit maximum brightness and
maximum volume. if you want to adjust the brightness and volume to more than
70%, please make sure that an external power supply of 5V/2.0A or above is
connected.Insufficient power may cause the portable monitor to shut down or
restart.
Power Cable
①
③
Video Cable
