MAKFRY MDFE-300S User Manual

Open fryer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MDFE-300S / MDFE-300D
OPEN FRYER
USER MANUAL
WWW.MAKFRY.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MDFE-300S and is the answer not in the manual?

Questions and answers

Related Manuals for MAKFRY MDFE-300S

Summary of Contents for MAKFRY MDFE-300S

  • Page 1 MDFE-300S / MDFE-300D OPEN FRYER USER MANUAL WWW.MAKFRY.COM...

  • Page 2: Table Of Contents

    CONTENTS 1- GENERAL INFORMATION 2- PRODUCT INTRODUCTION 3- TECHNICAL SPECIFICATIONS 4- TRANSPORTATION AND STORAGE CONDITIONS 5- UNPACKING THE PACKAGE 6- PRE-INSTALLATION INFORMATION 7- INSTALLATION AND USAGE 7.1- ELECTRICAL CONNECTION OF MDFE 300S DEVICE 7.2- ELECTRICAL CONNECTION OF MDFE 300D DEVICE 7.3- DEVICE ACCESSORIES 8- DIGITAL CONTROL PANEL INTRODUCTION AND USAGE 9- INITIAL START-UP AND PUMP SYSTEM CLEANING...
  • Page 3 DEAR USER, AS MAKFRY FAMILY, WE THANK YOU FOR CHOOSING OUR DEVICE AND FOR YOUR TRUST IN OUR COMPANY. WE IMPORTANTLY REMEMBER YOU TO READ THE INSTRUCTIONS AND INFORMATION IN THE USER MANUAL CAREFULLY AND HAVE YOUR USERS READ IT IN ORDER TO GET THE PRODUCT SUITABLE FOR YOUR EXPECTATIONS AND TO USE IT FOR A LONG-TERM.

  • Page 4: 1- General Information

    1- GENERAL INFORMATION THIS USER'S MANUAL CONTAINS INFORMATION ABOUT MAKFRY MDFE-300S / MDFE-300D INSTRUCTIONS FOR USE, REQUIREMENTS AND COVERAGE OF WARRANTY. CAREFULLY READ ALL INSTRUCTIONS AND WARNINGS IN THE USER'S MANUAL. THIS USER'S MANUAL CONTAINS IMPORTANT INFORMATION ABOUT THE SAFE INSTALLATION, USE AND MAINTENANCE OF YOUR PRODUCT.

  • Page 5: 2- Product Introduction

    2- PRODUCT INTRODUCTION MAKFRY MDFE-300S / MDFE-300D OPEN FRYERS ARE DESIGNED TO BE USED IN INDUSTRIAL KITCHENS AND IT IS RECOMMENDED FOR USE BY PROFESSIONAL USERS. 3- TECHNICAL SPECIFICATIONS PRODUCT: MDFE 300S DIMENSIONS WIDTH:450 MM - DEPTH:750 MM – HEIGHT: 960 MM...

  • Page 6: 4- Transportation And Storage Conditions

    4- TRANSPORTATION AND STORAGE CONDITIONS THE PRODUCT IS SPECIALLY PACKED AND SHIPPED IN A FORM. CARRY THE PRODUCT WITH THE FORKLIFT FEET INSTALLED UNDER THE PALLET. IF THE TRANSPORT DISTANCE IS FAR, IT MUST BE MOVED SLOWLY AND SUPPORTED BY AN ADDITIONAL PERSON TO AVOID LOSS OF BALANCE. DO NOT KNOW OR DROP THE PRODUCT WHEN CARRYING IT.

  • Page 7: 6- Pre-Installation Information

    6- PRE-INSTALLATION INFORMATION INSTALLATION MUST BE DONE BY AN AUTHORIZED TECHNICIAN ACCORDING TO THE INSTRUCTIONS AND REGULATIONS. OUR COMPANY CANNOT BE LIABLE FOR ANY DAMAGES DUE TO INCORRECT INSTALLATION. IF THE PRODUCT FAILS, TURN OFF THE PRODUCT. ONLY A SERVICE AUTHORIZED BY THE MANUFACTURER MUST PROVIDE THE PRODUCT.

  • Page 8: 7- Installation And Usage

    7- INSTALLATION AND USAGE 7.1- ELECTRICAL CONNECTION OF MDFE 300S DEVICE THE ELECTRICAL CONNECTION OF YOUR MACHINE SHOULD BE MADE BY AN AUTHORIZED PERSONNEL. THE POWER VALUES AND CONNECTION DIAGRAM ON THE DEVICE SHOULD BE CONSIDERED DURING CONNECTION. THE MACHINE CONSUMES A TOTAL OF 13.5 KW OF ENERGY, WITH 3X4.5 KW.

  • Page 9: Electrical Connection Of Mdfe 300D Device

    7.2- ELECTRICAL CONNECTION OF MDFE 300D DEVICE THE ELECTRICAL CONNECTION OF YOUR MACHINE SHOULD BE MADE BY AN AUTHORIZED PERSONNEL. THE POWER VALUES AND CONNECTION DIAGRAM ON THE DEVICE SHOULD BE CONSIDERED DURING CONNECTION. THE MACHINE CONSUMES A TOTAL OF 13.5 KW OF ENERGY, WITH 3X4.5 KW. THE DEVICE IS SHIPPED WITH THREE-PHASE CABLE FROM THE FACTORY.

  • Page 10: Device Accessories

    7.3- DEVICE ACCESSORIES THE ACCESSORY LIST FOR THE DEVICE IS AS FOLLOWS DEVICE ACCESSORY LIST MDFE 300 S MDFE 300 D BASKET 2 PIECES 4 PIECES 25+1 PIECES (1 FILTER 25+1 PIECES (1 FILTER ASSEMBLED PAPER FILTER ASSEMBLED IN EACH) IN EACH) PAPER FILTER HOOK 2 PIECES...

  • Page 11: 8- Digital Control Panel Introduction And Usage

    8- DIGITAL CONTROL PANEL INTRODUCTION AND USAGE 1- ON-OFF / POWER SWITCH THIS SWITCH IS USED TO TURN YOUR DEVICE ON AND OFF WHEN IT IS PLUGGED INTO THE POWER OUTLET. 2- DIGITAL DISPLAY PANEL: THIS IS THE DIGITAL DISPLAY WHERE YOU CAN SEE THE SETTINGS OF THE FRYER, SUCH AS COOKING TIME AND PROGRAMMING.
  • Page 12 3- COOK BUTTON: TO USE THE FRYER IN COOK MODE, YOU FIRST NEED TO TURN OFF IDLE MODE AND SELECT THE DESIRED COOKING PROGRAM (1-6). PRESS THE COOK BUTTON ONCE TO START COOKING IN THE SELECTED PROGRAM. NOTE: PRESSING AND HOLDING THE COOK BUTTON ENTERS THE PROGRAMMING MODE FOR ACCESSING THE SETTINGS PAGES.
  • Page 13 UP BUTTON: THIS BUTTON IS USED TO INCREASE THE DIGIT VALUE ON THE PARAMETER CHANGE SCREEN WHEN THE CURSOR IS ON IT. 16- ENTER BUTTON: THIS BUTTON IS USED TO SAVE THE PARAMETER VALUES AND RETURN TO THE MAIN SCREEN WHEN ON THE PARAMETER CHANGE SCREEN. DOWN BUTTON: THIS BUTTON IS USED TO DECREASE THE DIGIT VALUE ON THE PARAMETER CHANGE SCREEN WHEN THE CURSOR IS ON IT.

  • Page 14: 9- Initial Start-Up And Pump System Cleaning

    9- INITIAL START-UP AND PUMP SYSTEM CLEANING BEFORE ADDING OIL TO YOUR FRYER, WHICH YOU HAVE CONNECTED TO ELECTRICITY AND IS READY TO OPERATE, IT IS NECESSARY TO TEST IT WITH WATER AND MAKE SURE THAT THE PUMPED WATER IS CIRCULATING FOR HYGIENE PURPOSES, ESPECIALLY IF THE WATER HAS BEEN BOILED. TO DO THIS, FOLLOW THE STEPS BELOW IN ORDER: 1- CLOSE THE EMPTYING AND PUMP VALVES LOCATED ON THE FRONT COVER.
  • Page 15 6- PRESS THE COOK BUTTON AGAIN. 7- OPEN THE EMPTYING VALVE LOCATED ON THE FRONT COVER AND LET THE WATER DRAIN COMPLETELY FROM THE POT. DURING THIS PROCESS, YOU CAN CLEAN THE RESISTOR GAPS WITH AUXILIARY BRUSHES. 8- AFTER THE DRAINING PROCESS IS COMPLETED, CLOSE THE EMPTYING VALVE AND OPEN THE PUMP VALVE.

  • Page 16: 10- Automatic Filtration

    10- AUTOMATIC FILTRATION BE SURE TO HAVE A FILTER PAPER INSTALLED IN YOUR FRYER BEFORE STARTING THE FILTRATION PROCESS. FOLLOW THE STEPS BELOW FOR THE FILTRATION PROCESS: 1- TURN THE DRAIN VALVE OF YOUR FRYER FROM THE CLOSED POSITION TO THE OPEN POSITION..
  • Page 17 3- AFTER EMPTYING THE OIL, CLEAN THE RESIDUE AT THE BOTTOM OF THE TANK WITH THE CLEANING KIT. 4- TURN ON THE SWITCH AND PRESS THE PUMP BUTTON. 5- AFTER THE DIGITAL SCREEN TURNS ON, TURN THE DRAIN VALVE TO THE CLOSED POSITION AND THE PUMP VALVE TO THE OPEN POSITION.

  • Page 18: 11- Changing The Paper Filter

    11- CHANGING THE PAPER FILTER HERE IS THE ENGLISH TRANSLATION OF THE INSTRUCTIONS FOR CHANGING THE PAPER FILTER IN THE DEEP FRYER: 1- DISCONNECT THE TUBE FROM THE RECORD KEY. 2- PULL OUT THE EMPTYING TANK WHERE THE FILTER PLATE IS LOCATED. 3- REMOVE THE FILTER PLATE FROM THE EMPTYING TANK BY LIFTING THE COVER OF THE OIL EMPTYING TANK.

  • Page 19: 12- Electrical Diagram

    12- ELECTRICAL DIAGRAM...

  • Page 20: 13- Warranty Certificate And Terms

    13- WARRANTY CERTIFICATE AND TERMS AS MAKFRY FAMILY, THANK YOU FOR CHOOSING OUR PRODUCTS. WARRANTY DOCUMENT MUST BE KEPT DURING THE WARRANTY PROCESS. IF THE DOCUMENT IS LOST, A SECOND DOCUMENT WILL NOT BE GIVEN TO THE CUSTOMER AND THIS DOCUMENT MUST BE SHOWED WHEN THE CUSTOMER REQUIRES WARRANTY REPAIR.
  • Page 21 ELECTRICAL COMPONENTS ARISING FROM OPERATION OF THE DEVICE IN ACIDIC OR HUMID ENVIRONMENTS. • IN TSE OR CE CERTIFIED PRODUCTS USED, EXCEPT MAKFRY SPECIAL PRODUCTION ON THE GOODS. 6- TRANSPORTATION COSTS OF MAKFRY AUTHORIZED SERVICE PERSONNEL IN THE REPAIR PROCESS TO BE DONE WHERE THE GOODS ARE AVAILABLE, WITH ON-SITE SERVICE.
  • Page 22 MODEL SERIAL NUMBER WARRANTY PERIOD WARRANTY PROCESS START STAMP - SIGNATURE ADDRESS: GÖKDERE CADDESİ NO:27/A 35040 - GÖKDERE / BORNOVA/ İZMİR CONTACT: +90 232 207 21 51 E-MAIL: INFO@MAKFRY.COM...

This manual is also suitable for:

Mdfe-300d
