- Page 1 121-GR BRACKET PRO SERIE ® USER GUIDE...
-
Page 2: Copyright
Copyright 2021 Technimount E.M.S. Holding Inc. (Technimount), an affiliated company of Technologies CGC Inc. All Rights Reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of Technimount or its affiliate companies. -
Page 3: Contact Information
Email to techsupport@technimount.com. Please have the serial number of your Technimount product available (as shown in the figure below) when calling Technimount Customer Service or Technical Support. Include the serial number in all written communications. -
Page 4: Table Of Contents
Warranty Policy ................................27 Return Policy ................................27 Prior to 30 Days ..............................28 Prior to 45 Days ..............................28 Prior to 60 Days ..............................28 Return Authorization ..............................28 Damaged Merchandise ..............................28 International Warranty Clause ..........................29 Claim Process ................................29 Required Information ............................29 BP121-GR UG 202111-01 www.technimount.com... - Page 5 Table of Contents Findings and Conclusion .............................29 Questions about our policy ............................29 SAE CERTIFICATION ............................. 30 www.technimount.com BP121-GR UG 202111-01...
-
Page 6: Introduction
Introduction PURPOSE OF THE DOCUMENT This User Guide is designed to assist you with the installation, operation and maintenance of the Technimount Bracket Pro Serie 121-GR that was designed for the Spectrum IQ Infusion System from Baxter®. PRODUCT DESCRIPTION The Bracket Pro Serie 121-GR is a complete mounting system for Spectrum IQ Infusion System from Baxter in different applications such as cot/stretchers and wall systems. -
Page 7: Possible Mounting Options For The Bracket Pro Serie® 121-Gr
Introduction POSSIBLE MOUNTING OPTIONS FOR THE BRACKET PRO SERIE® 121-GR Safety MD-Transporter Wall Mount System (EU) Return To Table of Contents www.technimount.com BP121-GR UG 202111-01... -
Page 8: Symbols And Definitions
Introduction SYMBOLS AND DEFINITIONS SYMBOL DESCRIPTION Warning and Caution, special attention is required. Consult accompanying documents Safe working load symbol and Load balance symbol Pinch Point Return To Table of Contents BP121-GR UG 202111-01 www.technimount.com... -
Page 9: Warning / Caution / Note
NOTE Provides special information about the product. Return To Table of Contents www.technimount.com BP121-GR UG 202111-01... -
Page 10: Product Illustration
Introduction PRODUCT ILLUSTRATION BRACKET PRO SERIE 121-GR Front View Stainless Steel IV pole hooks Integrated Transport Handle High-density aluminum with silver-anodized finish Rubber pads to protect the medical device Return To Table of Contents BP121-GR UG 202111-01 www.technimount.com... -
Page 11: Back View
Knob to lower Anti-Rotation Micro Disc is or raise the used for vertical support on IV pole different wall or arm systems Integrated feet to protect the bracket when placed on a surface Return To Table of Contents www.technimount.com BP121-GR UG 202111-01... -
Page 12: Specifications
Contact Technimount EMS for more information or for other options at customerservice@technimount.com *Product and medical equipment manufacturer names are trademarks™ or registered trademarks® of their respective holders. Technimount does not have a commercial relationship with these medical equipment manufacturers. Return To Table of Contents BP121-GR UG 202111-01 www.technimount.com... -
Page 13: Notice
The end user and administrator are responsible to validate regulations and standards for safety in their region, in order to comply with applicable safety regulations. Technimount is not responsible to inform the end user and/or the administrator of applicable legislation for safety in their area. -
Page 14: Summary Of Safety Precautions
9 Do not place additional equipment or items onto the Bracket or mounts other than approved Technimount Systems or components, as this could damage the product and may result in injury to the patient or operator. - Page 15 9 Inspect regularly all components on the equipment for any issue and loose screws, bolts and nuts. 9 Never install the mount into or on other similar mounting systems or brackets without written confirmation by Technimount System as these different systems may be from other brands or models and may not be compatible with Technimount Systems.
-
Page 16: Installation Guide
5. Refer to the identification of components at the beginning of this user guide if needed. TOOLS REQUIRED FOR INSTALLATION No tools are required for installation. If you have any questions regarding the installation, or need assistance, please contact our Technical Support team at techsupport@technimount.com Return To Table of Contents BP121-GR UG 202111-01 www.technimount.com... -
Page 17: Installation Of The Baxter Pumps Onto The Bracket
1. Place the bracket on a stable surface for installation. 2. Before inserting the device, locate the locking block on the medical device. 3. Align the locking block with the support system on the bracket. Return To Table of Contents www.technimount.com BP121-GR UG 202111-01... - Page 18 4. Pull on the Quick Release Mechansim and insert the medical device into the bracket. 5. Proceed to install all pumps while following steps 1 to 4. 6. Once properly locked the Baxter pumps are ready for EMS transport. Return To Table of Contents BP121-GR UG 202111-01 www.technimount.com...
- Page 19 2. Slide in until you reach one of the grooves on the IV pole to hold into position. 3. The IV pole is now ready to be used with IV bags. WARNING 9 Do not use the IV pole during EMS transport. Return To Table of Contents www.technimount.com BP121-GR UG 202111-01...
-
Page 20: Part Numbers
NOTE Technimount reserves the right to change Part Numbers and Products without notice. Please refer to Customer Service to ensure product part number availability. For any replacement parts or for repair, please contact Technical Support at techsupport@technimount.com... -
Page 21: Maintenance Guide
Cleaning procedure below does NOT provide recommendations for cleaning of the medical device. The following cleaning guidelines consider the Technimount mounting assemblies and components. Remove medical device from the bracket if thorough cleaning is needed. -
Page 22: Removal Of Iodine Compounds
PREVENTIVE MAINTENANCE A preventive and regular maintenance program should be established for all Technimount equipment. Preventive maintenance may be required more frequently based on the usage level of the product. The Bracket requires regular preventative maintenance. -
Page 23: Inspection Process And Schedule
If you are unsure as to how to perform these maintenance inspections or at what interval to perform these inspections, please contact your Technical Support Team at techsupport@technimount.com. Check each routine and replace damaged or worn out parts if necessary. -
Page 24: Inspection And Maintenance Record
Maintenance Guide INSPECTION AND MAINTENANCE RECORD PREVENTIVE MAINTENANCE DATE TIME PERFORMED Return To Table of Contents BP121-GR UG 202111-01 www.technimount.com... -
Page 25: Training Record
Maintenance Guide TRAINING RECORD TRAINING DATE TRAINING METHOD USER GUIDE, IN-SERVICE, BASIC TRAINING TRAINEE NAME IN-CLASS, TRAINING UPDATE ETC. Return To Table of Contents www.technimount.com BP121-GR UG 202111-01... -
Page 26: Replacement Parts
The parts and accessories listed are all currently available for purchase. Some of the parts identified on the assembly drawing parts in this user guide may not be individually available for purchase. Please call Technimount Customer Service : +1.888.639.2758 or at customerservice@technimount.com... -
Page 27: Warranty
Technimount products are intended to retain a medical device in place in the case of a single crash impact. A Technimount product must NOT be used again if it was involved in a crash. The product MUST be replaced. If the Purchaser uses a Technimount product following a crash, it is at the Purchaser’s own risk and Technimount will not be... -
Page 28: Return Policy
▪ Product must be undamaged and in its original packaging ▪ The product return request must be provided in writing and it must be approved by TECHNIMOUNT prior to returning the product ▪ Returns will not be approved on a modified or damaged item ▪... -
Page 29: Damaged Merchandise
Email by then, please contact techsupport@technimount.com. If the RMA request is approved, TECHNIMOUNT will provide you with an RMA number for your claim. We will also include instructions for the replacement of your product. No product return will be accepted without the RMA number labeled on the outside of the box being returned. - Page 30 SAE Certification Return To Table of Contents BP121-GR UG 202111-01 www.technimount.com...
- Page 31 Return To Table of Contents www.technimount.com BP121-GR UG 202111-01...
- Page 32 Technimount E.M.S Holding Inc. 3770 Jean Marchand Street, Suite 100-C Quebec (QC) G2C 1Y6 Canada T + 1 888.639.2758 F + 1 855.339.6351 technimount.com info@technimount.com © 2021 Technimount E.M.S. Holding Inc. - All Rights Reserved Printed in Canada...
