Outer View; Top View - Motorola Avigilon Ava Quad Camera Mounting Manual
Table of Contents
OVERVIEW
Outer view
Release button
PACKAGE CONTAINS
Quad camera
IR light cover
Alignment sticker
Screws and anchors
T10 security L-key
MOUNTING GUIDE
| AVIGILON AVA QUAD CAMERA
IR LEDs
Dome cover
Top view
Threaded holes for
mounting adapter
Top mounting plate
Through holes for ceiling-mount
or wall mount bracket
