- Page 1 DLM4040Li Lithium Lawnmower USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. SYMBOLS MARKED ON THE PRODUCT ..................... 2 2. GENERAL SAFETY RULES ........................3 3. GENERAL IDENTIFICATION ........................6 4. TECHNICAL DATA ........................... 7 5. ASSEMBLY .............................. 7 6. ADJUSTMENT OF CUTTING HEIGHT ....................11 7. SAFETY PRECAUTIONS ........................11 8. -
Page 3: Symbols Marked On The Product
KNOW YOUR LAWN MOWER Read this manual carefully, observing the recommended safety instructions before, during and after using your lawn mower. Following these simple instructions will also maintain your lawn mower in good working order. Familiarize yourself with the controls on your mower before attempting to operate it, but above all, be sure you know how to stop your mower in an emergency. -
Page 4: General Safety Rules
WEEE Marking CAUTION! Unusable power tools do not belong with domestic waste. They must be taken to a communal collecting point for environmentally friendly disposal in accordance with local regulations. Accumulator Disposal: Old Accumulators and batteries must not be added to household waste, but should be disposed of in accordance with the applicable legislation. - Page 5 WARNING: The operation of any tool can result in foreign objects being thrown into your eyes, which can result in eyes severely damaged. Before beginning power tool operation, always wears safety goggles or safety glasses with side shields and a full face shield when needed. We recommend Wide Vision Safety Mask for use over eyeglasses or standard safety glasses with side shield.
- Page 6 - before checking, cleaning or working on the lawnmower; - after striking a foreign abject. Inspect the lawnmower for damage and make repairs before restarting and operating the lawnmower. If lawnmower starts to vibrate abnormally (check immediately): - inspect for damage; - replace or repair any damage parts;...
-
Page 7: General Identification
power supply. Take special care of the battery. Avoid dropping it onto any hard surface and do not subject it to pressure or any other form of mechanical stress. Keep the battery away from extreme heat and cold. Do not open or attempt to repair the battery or the battery charger. If any parts are defective, have them repaired by a qualified technician or send them to our service department for repair. -
Page 8: Technical Data
4. TECHNICAL DATA Model DLM4040Li Rated voltage : 40 V d.c. No load speed: 3300 rpm Grass catcher capacity: 40L Cutting width: 380 mm Net weight: 15 kg Height adjustment: 25-75 mm, 5 adjustment Model DYM101301 Sound pressure level at the operator’s position: 72.1dB(A) K=3 dB(A) Measured sound power level: 83.3dB(A) K=3.65dB(A) - Page 9 Fig. 2D Fig. 2E Fig. 2F 5.2 Assemble the grass catcher Insert one end of handle with a projection into the grass catcher, and then fix another end of the handle onto the grass catcher with the screw. (Fig.3A/ Fig.3B/ Fig.3C). 1.
- Page 10 Fig. 3D Fig. 3E Fig. 3F Fig. 3G Fig. 3H 5.3 Assemble the battery 1. Make sure the On-off button is pulled out. (Fig. 4A). 2. Open the battery door. (Fig. 4B). 3. Insert the battery pack into battery holder.(Fig. 4C). 4.
- Page 11 Fig. 4C Fig. 4D 5.4 Remove the battery 1. Lift and hold up the battery door (Fig. 5A). 2. Press and hold the battery latch button(1) at the bottom of the battery pack. (Fig. 5B). 3. Remove battery pack(2) from the product. (Fig. 5C). Fig.
-
Page 12: Adjustment Of Cutting Height
6. ADJUSTMENT OF CUTTING HEIGHT Apply outward pressure to disengage lever from rack. Move lever forward or back to adjust height. The height (the blade to the ground) can be adjusted from 25mm (position 1) to 75mm (position 5), 5 height positions. -
Page 13: Starting
Fig. 8C 8. OPERATING INSTRUCTIONS 9.1. Starting Insert the On-off button (Fig.9A). Start the motor as follows: 1.Press the On-off button. (Fig.9B). 2.And meanwhile, grasp the brake control handle, and keep it in grasp. (Fig.9C) ,after the motor is running,then release the On-off button(Fig.9D), If you release the brake control handle, the motor will stop. - Page 14 CAUTION: The blade starts turning as soon as the motor is started. WARNING! Cutting elements continue to rotate after the motor is switched off. CAUTION: your mower is designed to cut normal residential grass of a height no more than 250mm.
-
Page 15: Blade
Mowing leaves. The mowing of leaves can also be beneficial to your lawn. When mowing leaves make sure they are dry and are not laying too thick on the lawn. Do not wait for all the leaves to be off the trees before you mow. WARNING: if you strike a foreign object, stop the motor. -
Page 16: Troubleshooting
a) if the lawn mower strikes an object. b) if the motor stops suddenly c) if the blade is bent (do not align!) d) if the motor shaft is bent (do not align!) e) Use only manufacturer’s recommended replacement parts and accessories. 11. -
Page 17: Warranty
Manufactured under license of Daewoo International Corporation, Korea...
