1.0 SAFETY INFORMATION
•
The provision of the electrical supply and the connection of the unit to the mains must be
carried out by a qualified electrician.
•
Isolate from power supply before removing any covers. During installation / maintenance ensure
all covers are fitted before switching on the mains supply.
•
All-pole disconnection from the mains as shown in the wiring diagram must be incorporated
within the fixed wiring and shall have a minimum contact separation of 3mm in accordance with
latest edition of the wiring regulations.
•
This unit must be earthed.
•
Ducting must be securely fixed with screws to the spigot to prevent access to live parts. Duct
runs terminating close to the fan must be adequately protected by suitable guards.
•
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
•
Precautions must be taken to avoid the back-flow of gases into the room from the open flue of
gas or other fuel-burning appliances.
•
This appliance should not be used by children or persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge, unless they have been given supervision
or instruction concerning the safe use of the appliance by a person responsible for their safety.
Children shall not play with the appliance. Cleaning and user maintenance shall not be carried
out by children.
1.1 Hazard Symbols
GENERAL WARNING
Signifies a general warning regarding hazard specified by supplementary information.
ELECTRIC SHOCK
This unit must be completely electrically isolated before any panels are removed. Check
mains supply and control connections.
ROTATING PARTS
This unit contains fast moving rotational parts which may start automatically. It is the
sole responsibility of the installer to adequately guard these components.
REFER TO INSTRUCTION MANUAL
Read and understand the installation and maintenance manual before installing,
operating or maintaining this product.
Nuaire |
Western Industrial Estate
MEVDC2
Continuous Mechanical Extract Ventilation
Installation Manual
|
|
| nuaire.co.uk
Caerphilly
CF83 1NA
28. 01. 20. Document Number 671559
EMC Directive
2014/30/EU
LVD Directive
2014/35/EU
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NuAire MEVDC2
Summary of Contents for NuAire MEVDC2
- Page 1 MEVDC2 Continuous Mechanical Extract Ventilation EMC Directive 2014/30/EU Installation Manual LVD Directive 2014/35/EU 1.0 SAFETY INFORMATION • The provision of the electrical supply and the connection of the unit to the mains must be carried out by a qualified electrician.
-
Page 2: Installation
An integral fixing bracket with a single bolt fixing allows easy mounting Nuaire would always recommend a site specific risk assessment by a and removal of the unit when necessary. The unit is supplied with competent person to determine if any additional PPE is required. -
Page 3: Side View
Air Valve mounted Air Valve mounted Air Valve mounted in ceiling. in ceiling. in ceiling. Nuaire MEVDC2 unit mounted on the ceiling using an integral mounting bracket. 3.2 Dimensions Typical Installation of Unit Serving Kitchen and Two Bathrooms Mounting bracket Single screw unit fixing... -
Page 4: Operation
3.6.1 Unit Serving Bathroom IMPORTANT Wiring - Unit Serving Kitchen & Bathroom. Kitchen switch Isolation - Before commencing work make sure that the unit, and Nuaire control are electrically isolated from the mains 3 Pole Light switch isolator supply. (Double Pole) -
Page 5: Warranty
The product warranty applies to the UK mainland and in accordance with Clause 14 of our Conditions of Sale. Customers purchasing from outside of the UK should contact Nuaire International Sales office for further details. Failure to maintain the unit as recommended will invalidate the warranty. - Page 6 GENERAL In addition to the particular requirements given for the individual product, the following general requirements The equipment referred to in this Declaration of Incorporation is supplied by Nuaire to be assembled into should be noted. a ventilation system which may or may not include additional components. The entire system must be...
- Page 7 MEVDC2 Installation Manual Nuaire | | nuaire.co.uk 28. 01. 20. Document Number 671559 Western Industrial Estate Caerphilly CF83 1NA...
- Page 8 MEVDC2 Installation Manual Nuaire | | nuaire.co.uk 28. 01. 20. Document Number 671559 Western Industrial Estate Caerphilly CF83 1NA...
