- Page 1 INSTRUCTION LEAFLET FOR 2 TONNE GENERAL DUTY QUICK LIFT TROLLEY JACK STOCK No.63205 PART No.TJ2/QL It is important that you read this instruction manual before using your jack. Always ensure its correct use which will help to prevent damage and injury.
-
Page 2: Declaration Of Conformity
Lifting range ....................135 x 385mm Overall size ..................550 x 212 x 140mm Weight ........................9kg nett DECLARATION OF CONFORMITY Draper Tools Ltd. Hursley Road, Chandler’s Ford, Eastleigh, Hampshire. SO53 1YF. England. Declare under our sole responsibility that the product: Stock No:- 63205. - Page 3 KNOW YOUR TROLLEY JACK 1. Cylinder Pump. 9. Front Wheel. 2. Release Valve. 10. Radius Link. 3. Base. 11. Saddle. 4. Castor. 12. Lifting Arm. 5. Oil Filler Plug. 13. Cover Plate. 6. Reservoir. 14. Handle Sleeve. 7. Middle Spindle. 15.
-
Page 4: Care And Maintenance
CARE AND MAINTENANCE 1. When the jack is not in use, the lifting arm and handle sleeve should be kept in the fully lowered position. 2. Keep the jack clean and lubricated. Oil the points indicated on the diagram below on a regular basis. -
Page 5: Optional Accessories
IMPORTANT SAFETY TIPS cont’d 2. CORRECT POSITIONING: The jack should be positioned (normally under the suspension near appropriate FRONT front or rear wheels). Since these points WHEELS may vary with each vehicle, it is important SUGGESTED to consult the vehicle manufacturer’s JACKING handbook or Haynes manual. -
Page 6: Troubleshooting
No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, mechanical photocopying, recording or otherwise without prior permission in writing from Draper Tools Ltd. - 5 -...
