Roller Door Installation - Duratuf Kapiti Assembly Instructions Manual

6. Roller door installation

Scan this QR code to watch a
video on roller door installation:
Series 1 Roll-A-Door
Item Description
A Rolled plastic wrapped door
B "A" Style brackets, left and right hand
C Doors guides, Left and right handed
D Steel locking bars
Small parts bag
E Guide clips(door size dependant)
F Door handle and fixing to suit
G Bottom rail stops and 6mm screws
H Faceplate and fixing to suit
I Locking bar retainer
J Locking bar covers
K U-Bolts
L Axle / Bracket saddles
M 8mm Nuts for Ubolts
N Counter sunk screws for lock and facia
O 7mm x 4mm Mushroom head screws for locking bar
P 4mm x 6mm Screws for handle
Q 10mm Washers
R 8mm Washers (Door size dependent)
S Plastic Clamp
T 14gx50mm Coach screw
Dura
®
LIFESTYLE LIFESTYLE
Kapiti
T
Quantity
1
2
2
2
4
1
2
1
2
2
2
2
4
2
2
2
4
8
1
18
Page 34
