- Page 1 HDMI 2.0 Over HDBaseT Extender 4KEX70-H2 User Manual...
-
Page 2: Table Of Contents
Table of Contents Introduction ......................2 Overview ............................2 Features ............................2 Package Contents ........................2 Panel .............................. 3 Transmitter......................... 3 Receiver..........................4 Installation and Application................... 5 Brackets Installation ......................... 5 Application ..........................5 Operate with RS232 ....................6 Specification ......................7 Warranty ......................... -
Page 3: Introduction
Introduction Introduction Overview This product is a slim HDBT transmitter receiver set. It supports resolutions up to 4K@60Hz 4:4:4 8bit and HDCP 2.2 compatibility, transmitting HDMI signals up to 40m/131ft at 4K and up to 70m/230ft at 1080P via a Cat 6a/7 cable. -
Page 4: Panel
Introduction Panel Transmitter Front Panel Name Description Power On: The device is powered on. Off: The device is powered off. Status Blinking: The device is working properly. Off: The device is not working properly. On: HDCP protected content is being transmitted. HDCP Blinking: Non-HDCP protected content is being transmitted. -
Page 5: Receiver
Introduction Receiver Front Panel Name Description ON: The device is powered on. Power LED OFF: The device is powered off. Blinking: The device is working properly. Status LED OFF: The device is not working properly. ON: HDCP protected content is being transmitted. Blinking: Non-HDCP protected content is being HDCP LED transmitted. -
Page 6: Installation And Application
Installation and Application Installation and Application Brackets Installation Note: Before installation, please ensure the device is disconnected from the power source. Position and install the mounting brackets with the four mounting screws provided. Mount and secure the transmitter/receiver to a surface or a suitable location with the mounting screws (not included in the package). -
Page 7: Operate With Rs232
Operate with RS232 Operate with RS232 According to the bi-direction RS232 pass through function, users can use RS232 control system and RS232 controlled device for serial communication by connecting to the devices via serial cables. Control System or Controlled Device RS232 cable HDBT RS232 cable... -
Page 8: Specification
Specification Specification Technical Video Signal Type HDMI 2.0 with 4K@60Hz 4:4:4 8bit, HDCP 2.2 SMPTE: 1280x720P ,1920x1080I 1,2,3,4,5,6,7,8 1920x1080P , 3840x2160 1,2,3,4,5,6,7,8 2,3,5,6,8 4096x2160 2,3,5,6,8 VESA: 800x600 , 1024x768 , 1280x768 Input/Output 1280x800 , 1280x960 , 1280x1024 Resolution Supported 1360x768 , 1366x768 , 1400x1050 1440x900... -
Page 9: Warranty
Warranty Products are backed by a limited 1-year parts and labor warranty. For the following cases AV Access Technology Limited shall charge for the service(s) claimed for the product if the product is still remediable and the warranty card becomes unenforceable or inapplicable.
