EMB HubLite
Data Acquisition System
TM
Cat. No. A7810
Quick Start Guide
DG-006-A7810-00A

Advertisement

loading
Need help?

Need help?

Do you have a question about the EMB HubLite A7810 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Leviton EMB HubLite A7810

Summary of Contents for Leviton EMB HubLite A7810

  • Page 1 EMB HubLite Data Acquisition System Cat. No. A7810 Quick Start Guide DG-006-A7810-00A...
  • Page 3 1 PRODUCT APPLICATION LIMITATION • Leviton products are not intended for use in critical applications such as nuclear facilities, human implantable devices or life support. Leviton is not liable, in whole or in part, for any claims or damages arising from such uses.
  • Page 4 2 OVERVIEW EMB HubLite is a family of data acquisition systems which provides owners and managers of commercial and industrial facilities with a cost-effective means of gathering crucial information in a timely manner. The EMB footprint and industrial temperature range makes this a perfect solution for embedded applications.

  • Page 5: Installation Checklist

    3 INSTALLATION CHECKLIST Hardware: • A Data Acquisition Server (DAS • Laptop (not provided) with one RJ45 port (required for LAN or direct laptop-to-EMB HubLite connection) • Ethernet Cat 5 or better ethernet cable (not provided) • Power Supply 24VDC, 500mA or greater (not provided) Optional hardware: •...
  • Page 6 4 HARDWARE AND ELECTRICAL CONNECTION DIAGRAM Figure 1 Unpack materials. Mount the DAS using either the din rail mount, or with screws through the mounting tabs. (Optional) Connect the Modbus network loop as shown in the above diagram. Follow the manufacturer’s instructions for installing and powering the Modbus devices.
  • Page 7 5 DHCP ENABLED MODE Confirm the DAS is properly connected to the computer or a LAN, and both are powered on. Confirm that DHCP is enabled on the computer. For most computers, this is the default setting. To confirm you have established connection to the device, do a ping to the IP address shown in the DAS’s LCD display.

  • Page 8: Static Ip Mode

    6 STATIC IP MODE Confirm the DAS is properly connected to the computer, and both are powered on. On the EMB HubLite, click the “Menu” button to select the “TCP/IP Config” option. Click the “Select” button to enter the “TCP/IP Menu”. Select the “DHCP+UPnP on/off”...
  • Page 9 6 STATIC IP MODE Enter the desired admin user password in both boxes and click the Apply button. Figure 6 A Thank You message will be displayed, confirming that the password was succesfully set. Click on the line below to proceed to the login screen. Figure 7...
  • Page 10 7 LOGGING INTO THE EMB HUBLITE From the web browser interface, click on “Click here to enter”. Enter the username and password. Figure 8 Login successful. Figure 9...

  • Page 11: Warranty And Contact Information

    LIMITED 5 YEAR WARRANTY AND EXCLUSIONS Leviton warrants to the original consumer purchaser and not for the benefit of anyone else that this product at the time of its sale by Leviton is free of defects in materials and workmanship under normal and proper use for five years from the purchase date. Leviton’s only obligation is to correct such defects by repair or replacement, at its option.
  • Page 12 DG-006-A7810-00A...
