indice

ABRI UTILITY 7.5

3150 X 2390

ZF63

140603

À CONSERVER

TO BE KEPT

BITTE AUFBEWAHREN

NOTICE DE MONTAGE ASSEMBLY INSTRUCTIONS AUFBAUANLEITUNG

ISTRUZIONI PER IL MONTAGGIO

MANUAL DE MONTAJE MONTAGE INSTRUCTIES

FOLHETO DE MONTAGEM

Need help?

Do you have a question about the ABRI UTILITY 7.5 ZF63 and is the answer not in the manual?

Questions and answers

Summary of Contents for Grosfillex ABRI UTILITY 7.5 ZF63

Page 1 All manuals and user guides at all-guides.com indice ABRI UTILITY 7.5 3150 X 2390 ZF63 140603 À CONSERVER TO BE KEPT BITTE AUFBEWAHREN NOTICE DE MONTAGE ASSEMBLY INSTRUCTIONS AUFBAUANLEITUNG ISTRUZIONI PER IL MONTAGGIO MANUAL DE MONTAJE MONTAGE INSTRUCTIES FOLHETO DE MONTAGEM...
Page 2 Gartenhaus / Gerätehaus Jardin GROSFILLEX. Le consigliamo di leggere Wij raden u aan om deze Recomendamos leitura aus dem Hause Grosfillex Nous vous recommandons de We recommend that you read interamente le istruzioni per il Le recomendamos lea por montage instructies grondig completa deste folheto de entschieden haben.
Page 3 All manuals and user guides at all-guides.com UTILITY7.5-03...
Page 4 All manuals and user guides at all-guides.com OUTILLAGE TOOLS • WERKZEUG • ATTREZZI • HERRAMIENTAS • GEREEDSCHAP • FERRAMENTAS 2,50m Ø 6mm 10-13 Ø 10mm 3150 mm 3600 mm (9X400 mm) UTILITY7.5-04...
Page 5 All manuals and user guides at all-guides.com Concernant le sol : Regarding the ground: Weitere Hinweise Terreno: zum Beschaffenheit des Untergrundes: Um ein einwandfreies Ergebnis Ihrer Montage, insbesondere in Hinsicht auf die Ausbildung der Spaltmaße der Türen, zu erzielen, ist es zwingend erforderlich, dass der Untergrund absolut waagerecht und eben ist.
Page 6 All manuals and user guides at all-guides.com UTILITY7.5-06...
Page 7 All manuals and user guides at all-guides.com UTILITY7.5-07...
Page 8 All manuals and user guides at all-guides.com UTILITY7.5-08...
Page 9 All manuals and user guides at all-guides.com UTILITY7.5-09...
Page 10 All manuals and user guides at all-guides.com UTILITY7.5-10...
Page 11 All manuals and user guides at all-guides.com (x4) M02A (x2) F4B2 (x2) F4B3 (x8) V13- SH03 (x2) A02- SHA M02A F4B2 F4B3 Ø4,2X25mm UTILITY7.5-11...
Page 12 All manuals and user guides at all-guides.com (x2) (x2) F4B3 F4F3 (x1) (x1) A02- SHA A01B (x4) (x4) V13- SH03 V13- SH03 F4B3 F4B3 Ø4,2X25mm F4F3 F4F3 Ø4,2X25mm A01B Ø4,2X25mm UTILITY7.5-12...
Page 13 All manuals and user guides at all-guides.com (x1) M02A (x1) V04- SH01 (x1) V08- SH01 (x1) V23- SH01 Ø 10mm M02A Ø 10mm Ø8X50mm Ø10mm Ø 36mm UTILITY7.5-13...
Page 14 All manuals and user guides at all-guides.com (x1) (x5) A03- SHA (x5) V03- SH09 (x5) V16- SH05 (x5) V22- SH07 Ø 6mm Ø 6mm Ø4,2X35mm Ø14mm Ø6mm UTILITY7.5-14...
Page 15 All manuals and user guides at all-guides.com (x1) (x4) A03- SHA (x4) V03- SH09 (x4) V16- SH05 (x4) V22- SH07 Ø 6mm 90° 90° 0,75m Ø 6mm Ø4,2X35mm Ø14mm Ø6mm UTILITY7.5-15...
Page 16 All manuals and user guides at all-guides.com M02A (x1) (x1) M02A NE PAS FIXER AU SOL • DO NOT SECURE IT NICHT AM BODEN BEFESTIGEN • NO FIJAR AL SUELO NON FISSARE AL SUOLO • NIET BEVESTIGEN AAN DE BODEM NÃO FIXAR AO SOLO Intérieur Inside...
Page 17 All manuals and user guides at all-guides.com M02A (x2) (x1) M02A NE PAS FIXER AU SOL • DO NOT SECURE IT NICHT AM BODEN BEFESTIGEN • NO FIJAR AL SUELO NON FISSARE AL SUOLO • NIET BEVESTIGEN AAN DE BODEM NÃO FIXAR AO SOLO Intérieur Inside...
Page 18 All manuals and user guides at all-guides.com F1V1 (x20) F1V2 (x4) CLIC F1V1 F1V1 CLIC F1V1 F1V1 F1V2 F1V2 UTILITY7.5-18...
Page 19 All manuals and user guides at all-guides.com F10A (x4) (x1) F10A UTILITY7.5-19...
Page 20 All manuals and user guides at all-guides.com (x1) F1V2 + F1V2 UTILITY7.5-20...
Page 21 All manuals and user guides at all-guides.com (x1) UTILITY7.5-21...
Page 22 All manuals and user guides at all-guides.com (x1) F1V1 + F1V1 UTILITY7.5-22...
Page 23 All manuals and user guides at all-guides.com F10A (x1) F10A F10A UTILITY7.5-23...
Page 24 All manuals and user guides at all-guides.com (x1) UTILITY7.5-24...
Page 25 All manuals and user guides at all-guides.com F10A (x1) F10A F10A UTILITY7.5-25...
Page 26 All manuals and user guides at all-guides.com (x9) (x1) F10A (x18) (x1) (x6) (x3) F10A F10A UTILITY7.5-26...
Page 27 All manuals and user guides at all-guides.com EM15 (x1) EM16 (x1) EM16 EM15 EM16 EM15 EM15 EM16 UTILITY7.5-27...
Page 28 All manuals and user guides at all-guides.com (x2) (x1) F24E1 (x1) F24E1 CLIC UTILITY7.5-28...
Page 29 All manuals and user guides at all-guides.com F24D1 (x2) (x4) CLIC CLIC F24D1 CLIC F24D1 UTILITY7.5-29...
Page 30 All manuals and user guides at all-guides.com S01F (x1) Intérieur S01F Inside UTILITY7.5-30...
Page 31 All manuals and user guides at all-guides.com F1V3 F1V3 (x2) (x2) (x1) (x2) F24E1 F24E1 (x1) (x2) F24D1 (x2) S01F (x1) F1V3 CLIC F24E1 F1V3 CLIC EF1 + F24E1 S01F UTILITY7.5-31...
Page 32 All manuals and user guides at all-guides.com V04- SH01 (x3) V08- SH01 (x3) V23- SH01 (x2) M02B Ø10mm Ø8X50mm Ø36mm Ø10mm Ø 10mm M02B M02B UTILITY7.5-32...
Page 33 All manuals and user guides at all-guides.com (x3) (x8) V03- SH09 V11- SH02 (x3) (x2) V20- SH08 (x1) Ø6mm Ø4X40mm Ø6mm Ø4X40mm Ø 6mm Ø6mm CLIC Ø4X45mm UTILITY7.5-33...
Page 34 All manuals and user guides at all-guides.com (x11) (x11) V03- SH09 (x11) V16- SH05 (x11) V22- SH07 Ø6mm Ø4,2X35mm Ø 6mm Ø14mm Ø6mm UTILITY7.5-34...
Page 35 All manuals and user guides at all-guides.com (x2) F4B2 (x2) F4B3 (x8) V13- SH03 (x2) F4B2 F4B3 Ø4,2X25mm Intérieur Intérieur Inside Inside UTILITY7.5-35...
Page 36 All manuals and user guides at all-guides.com F3D1 (x2) (x2) F3C1 (x2) F3B3 (x1) A15A (x2) F3D1 F3D1 Intérieur Inside F3B3 A15A F3C1 F3C1 A15A A15A Intérieur Inside UTILITY7.5-36...
Page 37 All manuals and user guides at all-guides.com F24A2 (x1) M1A1 (x2) M1A2 (x2) F24A2 F24A2 Intérieur Inside F24A2 M1A1 M1A2 M1A2 M1A1 UTILITY7.5-37...
Page 38 All manuals and user guides at all-guides.com (x2) M06A/M06B (x8) V01- SH04 (x8) V22- SH07 (x2) M06A M06B Ø4X32mm Ø14mm UTILITY7.5-38...
Page 39 All manuals and user guides at all-guides.com T3-1 (x2) T3-2 (x2) T3-3 (x2) T3-4 (x2) T3-2 T3-3 T3-1 T3-4 T3-3 T3-4 T3-2 T3-1 UTILITY7.5-39...
Page 40 All manuals and user guides at all-guides.com F4T3 YM09 (x4) (x2) Intérieur Inside F4T3 CLIC YM09 UTILITY7.5-40...
Page 41 All manuals and user guides at all-guides.com (x1) EA2A (x1) EA2B EA2A EA2B Ø4X8mm UTILITY7.5-41...
Page 42 All manuals and user guides at all-guides.com (x1) UTILITY7.5-42...
Page 43 All manuals and user guides at all-guides.com (x4) V05- SH06 (x4) V06- SH06 (x8) V21- SH06 (x1) Ø6mm Ø18mm Ø18mm Ø6X80mm UTILITY7.5-43...
Page 44 All manuals and user guides at all-guides.com F1T3 (x16) F1T3 CLIC UTILITY7.5-44...
Page 45 All manuals and user guides at all-guides.com A12C (x6) A12C UTILITY7.5-45...
Page 46 All manuals and user guides at all-guides.com (x24) CLIC UTILITY7.5-46...
Page 47 All manuals and user guides at all-guides.com FP113A (x1) (x1) EP1H (x1) EP2H (x1) EP1H EP2H FP113A 0 mm 0 mm EP1H EP2H UTILITY7.5-47...
Page 48 All manuals and user guides at all-guides.com (x20) V11- SH02 (x5) (x20) V11- SH02 CLIC Ø4,X45mm Ø4X45mm UTILITY7.5-48...
Page 49 All manuals and user guides at all-guides.com FP113C (x1) FP113C UTILITY7.5-49...
Page 50 All manuals and user guides at all-guides.com F11C (x5) F11C F11C F11C F11C 13mm 50mm F11C 50mm 13mm UTILITY7.5-50...
Page 51 All manuals and user guides at all-guides.com (x8) V13- SH03 (x8) V22- SH07 13mm 13mm 13mm 13mm F11C Ø14mm Ø4,2X25mm Ø4,2X25mm Ø14mm Ø4,2X25mm 13mm UTILITY7.5-51...
Page 52 All manuals and user guides at all-guides.com (x8) V13- SH03 100cm Ø4,2X25mm UTILITY7.5-52...
Page 53 All manuals and user guides at all-guides.com (x4) A15- SHA (x4) V13 - SH03 (x8) V22 - SH07 13mm Ø14mm Ø4,2 x 25mm Ø14mm UTILITY7.5-53...
Page 54 All manuals and user guides at all-guides.com (x4) A15- SHA (x8) V13- SH03 (x8) V22- SH07 13mm F11C Ø14mm Ø4,2 x 25mm 13mm Ø4,2 x 25mm Ø14mm Ø4,2X25mm UTILITY7.5-54...
Page 55 All manuals and user guides at all-guides.com F18A-SHB (x8) A22-SHB (x8) V27-SHB (x16) F18A CLIC F18A F18A UTILITY7.5-55...
Page 56 All manuals and user guides at all-guides.com (x4) V11- SH02 (x6) V16- SH05 Ø4X45mm Ø4,2X35mm UTILITY7.5-56...
Page 57 All manuals and user guides at all-guides.com (x8) V13- SH03 (x1) M02C M02C M02C M02C Ø4,2X25mm 10 mm UTILITY7.5-57...
Page 58 All manuals and user guides at all-guides.com (x44) V11- SH02 (x11) (x12) V11- SH02 Ø4X45mm Ø4X45mm Ø4X45mm UTILITY7.5-58...
Page 59 All manuals and user guides at all-guides.com (x4) UTILITY7.5-59...
Page 60 All manuals and user guides at all-guides.com (x8) V11- SH02 Ø4X45mm UTILITY7.5-60...
Page 61 All manuals and user guides at all-guides.com (x1) (x1) UTILITY7.5-61...
Page 62 All manuals and user guides at all-guides.com (x1) UTILITY7.5-62...
Page 63 All manuals and user guides at all-guides.com F72B (x4) (x2) F72B F72B UTILITY7.5-63...
Page 64 All manuals and user guides at all-guides.com (x4) M5F1 (x2) M5F2 (x2) F72B M5F1 M5F2 M5F2 M5F1 M5F1 UTILITY7.5-64...
Page 65 All manuals and user guides at all-guides.com (x4) F71C (x2) M5E1 (x2) M5E2 (x4) V20- SH08 F71C Ø4X40mm M5E1 M5E2 M5E1+F71C M5E2+F71C M5E2+F71C M5E1+F71C UTILITY7.5-65...
Page 66 All manuals and user guides at all-guides.com (x2) (x4) V20- SH08 (x16) V13- SH03 Ø4X40mm Ø4,2X25mm Ø4,2X25mm Ø4,2X25mm Ø4,2X25mm UTILITY7.5-66...
Page 67 All manuals and user guides at all-guides.com (x4) V20- SH08 Ø4X40mm Ø4X40mm 63mm UTILITY7.5-67...
Page 68 All manuals and user guides at all-guides.com Conseils pour rendre étanche votre abri. Matériel nécessaire présenté non fourni (adhésif d'emballage transparent, cartouche silicone, ...) Tips for a waterproof shed. Necessary tools not supplied. Consigli per rendere a tenuta stagna la vostra casetta.Materiale necessario non fornito ( nastro adesivo trasparente, silicone, etc.). Tipps zum Abdichten Ihres Hauses: Silikon, transparentes Abdichtband (nicht im Lieferumfang enthalten).
Page 69 Liebe Kundin, lieber Kunde, Vous venez de faire l’acquisition d’un abri de jardin Grosfillex Garden We have been paying special attention to the quality of our products Home.
Page 70 Os abrigos com dimensões reduzidas (até 5 m2) podem ser edificados e fixados Zoals op alle producten uit ons gamma is ook op dit tuinhuis een Grosfillex em lajes de brita ou em pinos para ângulos de betão. Acima dos 5 m2, garantie van toepassing, onder de volgende voorwaarden : aconselhamos sistematicamente a realização prévia de uma laje de betão...
Page 71 All manuals and user guides at all-guides.com UTILITY7.5-71...
Page 72 KIT DE FIXATION Attachment Kit Kit di Fissagio Befestigungskit Kit de fijación Bevestigingskit Ref : 22 950 136 Grosfillex - Arbent F-01107 Oyonnax Tél. 00 33 (0)4 74 73 30 30 Fax 00 33 (0)4 74 73 32 30 www.grosfillex-gardenhome.com www.grosfillex.com...
