Summary of Contents for Spinner BN 553664
- Page 1 RF plug-in switch (DPDT) Coaxial interface: 43-98 USL-D BN 553664 BN 553665...
-
Page 2: Table Of Contents
Content Basic Safety Instructions for SPINNER Broadcast Products ..............3 Intended use ............................. 6 Improper use ............................6 Function ..............................6 Motor drive ............................... 6 SPINNER crank drive ..........................6 ... -
Page 3: Basic Safety Instructions For Spinner Broadcast Products
The following instructions and safety instructions are to be carefully read and followed! The Spinner group makes every effort to keep the safety standard of our products up to date to be able to offer our customers the highest possible degree of safety. Our products are designed and tested in accordance with the relevant safety standards. - Page 4 Doing so can cause short circuits inside the product and/or electric shocks, fire or injuries. 23. Dangerous voltage must not reach the product over the outer conductor / waveguide. Data subject to change without notice │ M36275 │ Issue B 4 / 23 www.spinner-group.com...
- Page 5 36. The operator is responsible for disposing of the product according to national waste disposal regulations. Improper disassembly or disposal may be hazardous. 37. SPINNER RF switches are not equipped with separating equipment for safe disconnection from mains. The user must provide external separation equipment. The mains connector must be de-energized during plugging.
-
Page 6: Intended Use
A capacitor motor with a supply voltage of 230 V AC 50/60 Hz is used to actuate the RF plug-in switch via a special crank gear box developed by SPINNER. Depending on the type of switch the drive control system enables remote switching by means of a control voltage of 230 V AC, 50/60 Hz or 8 to 31 V... -
Page 7: Bistable Switching Property (Latching)
RF connectors. Integration of the strapping plug into the interlock loop is mandatory to avoid hot switching in case of accidental removal of the RF plug-in switch from the patch panel. To ease attachment of the RF plug-in switch to the patch panel, BN 553664 and BN 553665 are equipped with a centering pin. -
Page 8: Data Sheet
USL-interlock I Nominal fuse The circuits must be externally limited to 0.5 A. Connector J2 ** 5 pole SPINNER connector BN 126920, certified according to for mains connection VDE-Reg. No. B687, DIN EN 61984: 2009-11; EN 61984: 2009 Mains connection... - Page 9 4,000 m or 13,120 ft according to IEC EN 60664-1 Protection class I according to IEC EN 61140 IP40 according to IEC EN 60529 IP protection level (all interfaces equipped with appropriate gaskets) Data subject to change without notice │ M36275 │ Issue B 9 / 23 www.spinner-group.com...
- Page 10 Load VSWR, max. 1.0 (no standing wave) No modulation, sinusoidal carrier only Suitable mating connector included Suitable SPINNER mating connector BN 539145 not in delivery! **** At room temperature and nominal voltage 230 V AC ***** Extended temperature range on request Data subject to change without notice │...
-
Page 11: Dimensions (All Dimensions In Millimeters)
(marking) Circuit diagram ~116 +10 to disconnect the connector RF connection Ground connection RF position I: A-B / C-D RF position II: A-D / B-C Data subject to change without notice │ M36275 │ Issue B 11 / 23 www.spinner-group.com... -
Page 12: Circuit Diagrams
Circuit diagrams No. B41003-CD Issue G, valid for BN 553664 Data subject to change without notice │ M36275 │ Issue B 12 / 23 www.spinner-group.com... - Page 13 No. B41001-CD Issue E, valid for BN 553665 Data subject to change without notice │ M36275 │ Issue B 13 / 23 www.spinner-group.com...
-
Page 14: Storage
The RF plug-in switch is heavy. Use suitable transportation and lifting gear approved to carry at least 30 kg. Manual lifting of the cardboard requires at least two persons. Do not unpack until immediately prior to installation. Data subject to change without notice │ M36275 │ Issue B 14 / 23 www.spinner-group.com... -
Page 15: Installation
Failure to observe could result in death or serious injury. Only trained electricians should install SPINNER RF plug-in switches in accordance with applicable national and international safety rules and regulations. -
Page 16: 10.1 Mechanical And Rf Installation
Assembly of the centering pin: BN 553664 and BN 553665 are supplied with a separate centering pin, which needs to be mounted to the RF plug-in switch prior to installation. Screw the centering pin into the tapped hole M25x1 on the bottom of the RF plug-in switch using a flat wrench A/F 19 mm. -
Page 17: 10.2 Electrical Installation
Relieve all connections to the RF plug-in switch from any bending torque, e.g. caused by heavy cables or assemblies. Avoid sharp bends and tensile load. Data subject to change without notice │ M36275 │ Issue B 17 / 23 www.spinner-group.com... - Page 18 EN 61984: 2009 Approved plug connector BN 126920 Please attend the valid safety rules for assembling! Design is subject to change without notice Strain relief for cable Data subject to change without notice │ M36275 │ Issue B 18 / 23 www.spinner-group.com...
-
Page 19: Commissioning
Before you start, ensure to read and understand the Basic Safety Instructions and the additional safety instructions on personal safety that appear in relevant parts of this manual. Failure to observe could result in death or serious injury. Only trained electricians should commission SPINNER RF plug-in switches. WARNING Electric shock hazard Electric shock can cause severe burns and fatal injuries. -
Page 20: Cleaning
Do not disassemble the RF plug-in switch. The warranty is void, if the RF plug-in switch is modified, improperly handled or third party intervention or modification has occurred. Data subject to change without notice │ M36275 │ Issue B 20 / 23 www.spinner-group.com... -
Page 21: Demounting
Use safety gloves and handle carefully. ATTENTION The supplied packaging and all connector transportation locks are reusable and required for transportation. If not available, contact SPINNER before starting demounting. The RF plug-in switch is heavy. Use transportation and lifting gear approved to carry at least 30 kg and the handles of the RF plug-in switch only. -
Page 22: Disposal
GB/T 26572. (Enterprises may further provide in this box technical explanation for marking ”X” based on their actual circumstances.) X：表示该有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 规定的限量要求。 （企业可在此处，根据实际情况对上表中打“X”的技术原因进行进一步说明。） Data subject to change without notice │ M36275 │ Issue B 22 / 23 www.spinner-group.com... -
Page 23: Spare Parts
SPINNER GmbH • Headquarters Erzgiessereistr. 33 80335 München Germany Phone +49 8912601-0 E-mail: info@spinner-group.com Web: www.spinner-group.com Spinner Telecommunication Devices (Shanghai) Co., Ltd 351 Lian Yang Road Songjiang Industrial Zone Shanghai 201613 China Phone +86 21 5774 5377 E-mail: info-china@spinner-group.com Web: www.spcn.cn...
