Technical Specifications

Refer to the tables below for the technical specifications for the HN-210 Remotes.

Electrical

Specification
Transmitter FCC ID
Transmit Power
Hopping Patterns
Number of Channels
Line-of-Sight Range
Frequency Band
Approvals
Receiver Sensitivity
Data Interface
Input Power at Connector
Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2004
HN-210/210X 01/13/17
Value
HSW-2410M
EIRP: +24 dBm Nominal (HN-210)
+18 dBm (HN-210X)
User configurable, 64 patterns (networks) available
75 US; 25 France, Spain & Japan
Greater than 3.5 miles (up to 20 miles with HN-210x
and appropriate antennas)
2401-2475 MHz (USA)
2448-2478 MHz (France)
2448-2473 MHz (Spain)
2473-2495 MHz (Japan)
US FCC: Part 15. 203
Industry Canada
European Community: ETS 300.328 Compliance
-93 dBm (HN-210 Integrated patch antenna adds 6 dB
to the link budget and -99dBm sensitivity)
RS-232
9 VDC Operating
160 mA Typical (750 mA surge)
