The Clear Screen button deletes all the text in the display window. The Clear CTS and
Clear DCD buttons reset the respective changes counters to zero.

Function Keys

All of the function key shortcuts are described below:
F1
F2
F3
F5
F6
F8
PgUp Sets data rate of PC serial port to next higher value.
PgDn Sets data rate of PC serial port to next lower value.

Recover

When the Wizard program is opened, it reads the parameters of the HopNet radio
connected to the PC. These initial parameters are stored by the Wizard until the
program is closed. This function allows the initial parameters to be loaded into any
HopNet radio that is connected to the PC. Clicking on the Recover button displays the
settings stored when the Wizard was first opened but will not load them in the radio
until the Apply Settings is clicked. When the Apply Settings button is clicked, all the
changed values will be loaded into the radio, even if the changed values are not on the
tab currently displayed.
Copyright © Murata Manufacturing Co., Ltd. All Rights Reserved. 2004
HN-210/210X 01/13/17
Toggles state of DTR (Sleep). State is shown in status
line.
Toggles state of RTS. State is shown in status line.
Transmits ":wit2400". Used to enter control mode.
Toggles local echo. If you are transmitting characters
through one modem to another modem, this allows you
to see what you are typing.
Toggles stream mode. Causes WinCOM to transmit a
repeating pattern of characters. Useful for testing.
Toggles binary mode. Displays extended ASCII and
control characters. Useful for testing.
Value is displayed in status line. Useful when WinCOM
is used to change the interface data rate. WinCOM can
communicate at new data rate without having to exit and
re-enter WinCOM.
Value is displayed in status line.
