Parameters Tab

The Wizard program opens the main screen with the Parameters Tab displayed. The
parameters screen of the Wizard allows the following variables to be set;
1. Base or Remote
2. Point-to-Point or Multipoint
3. Baud rate
4. Network number
5. Lockout Key
6. Roaming Mode
7. Protocol Mode
Depending on whether HopNet radio is configured as a Remote or Base when first
connected, the heading on the Parameters page will display either "Remote
Parameters" or "Base Parameters." If the radio has a Modbus adapter, Transparent,
Modbus and DNP3 selections will appear above the Point-Point-Multipoint selection
as shown below.
