READ INSTRUCTIONS CAREFULLY: YOUR SAFETY IS IMPORTANT TO YOU AND TO OTHERS Read and
follow all instructions. Place instructions in a safe place for future reference. Do not allow anyone who has
not read these instructions to assemble, light, adjust or operate the heater.
Heatstar ERSP
Gas-Fired Low-Intensity Infrared Heaters Approved
For Residential Garage/Commercial Applications
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause
property damage, injury or death. Read the installation, operating and maintenance instructions
thoroughly before installing or servicing this equipment.
- WHAT TO DO IF YOU SMELL GAS
• Open Windows
• DO NOT try to light any appliance.
• DO NOT use electrical switches.
• DO NOT use any telephone in your house. Immediately call your local gas supplier from a telephone remote from the
area of the leak. Follow the gas supplier's instructions.
• Do not touch any electrical switch; do not use any phone in your building.
• Installation and service must be performed by a qualified installer, service agency, or the gas supplier.
• If you cannot reach your gas supplier, call the Fire Department.
FOR YOUR SAFETY:
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
WARNING: If the information in these instructions are not followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
OPERATING INSTRUCTIONS
AND OWNER'S MANUAL
ENERCO Group, Inc., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 866-447-2194
Model #
ERSP-40
ERSP-60
ERSP-80
ERSP-100
ERSP-125 ERSP-150
ERSP-175
LANGUAGES INCLUDED
•ENGLISH
•FRENCH
•SPANISH
02701
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HeatStar ERSP-60
Summary of Contents for HeatStar ERSP-60
- Page 1 OPERATING INSTRUCTIONS Model # ERSP-40 ERSP-60 ERSP-80 ERSP-100 AND OWNER’S MANUAL ERSP-125 ERSP-150 ERSP-175 READ INSTRUCTIONS CAREFULLY: YOUR SAFETY IS IMPORTANT TO YOU AND TO OTHERS Read and follow all instructions. Place instructions in a safe place for future reference. Do not allow anyone who has not read these instructions to assemble, light, adjust or operate the heater.
-
Page 2: Table Of Contents
Consult local building inspectors, Fire Marshals or your local Enerco Group, Inc Factory Representative for guidance. Heatstar ERSP heaters are installed on the basis of information given in a layout drawing, which together with the cited codes and regulations, comprise the basic information needed to complete the installation. -
Page 3: Section 2 Planning
The following codes and instructions should be followed when airborne material or vapor, consult the local Fire Marshal, the planning the installation of the Heatstar ERSP heater. In addition fire insurance carrier or other authorities for approval of the to these instructions, the warnings in (Section 1) must be carefully proposed installation. - Page 4 TABLE 1 gives minimum acceptable clearances to combustibles. Clearances as shown in TABLE 1 are not for use in four-sided enclosures. Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
- Page 5 45 DEGREE REFLECTOR TILT STANDARD REFLECTOR U-TUBE OPPOSITE 45 DEGREE U-TUBE STANDARD “U”-Tube, Standard “U”-Tube, Opposite 45° “U”-Tube, Full 45° Front and Back Clearance FRONT AND BACK CLEARANCE U-TUBE FULL 45 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
-
Page 6: Section 3 Installation & Assembly
TUBE HANGER (14585P) REFLECTOR 10' (00418A) HEAT EXCHANGER TUBE 10' (06413) TURBULATOR BAFFLE 10' (03445) TURBULATOR BAFFLE 5' (03447) **NOT INCLUDED WITH ALL MODELS** **ONLY HEATERS 30' LENGTH AND UNDER** Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual... - Page 7 “point” in the same direction. Vent Adapter Used to attach the heat exchanger tubing to vent pipe. Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
- Page 8 (46cm) (46cm) 10' 2½" (3.11m) ALUMINIZED 9' (2.75 m) Long Turbulator Section FIGURE 2B: Ener-Radiant SP Model ERSP-60, ERSP-80, Assembly Overview 20 ft. Exchanger length. 21 ft. - 4 in. Total Heater length. 4 Suspension points indicated. HANGER HANGER HANGER HANGER 18"...
- Page 9 (46cm) (46cm) (46cm) 10' 2½" (3.11m) 10' 2½" (3.11m) 10' 2½" (3.11m) 10' 2½" (3.11m) 10' 2½" (3.1 1m) 10' 2½" (3.1 1m) ALUMINIZED ALUMINIZED ALUMINIZED ALUMINIZED ALUMINIZED ALUMINIZED Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
- Page 10 15' (4.57 m) - 25' (7.62 m) ERSP-175 175,000 50 ft. (15.25 m) None 61 ft. 4" (18.69 m) 15' (4.57 m) - 25' (7.62 m) ERSP-175 175,000 60 ft. (18.3 m) None E-10 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
- Page 11 Assembly When assembling coupling note the location of Hole 1 and Hole 2 (43cm) Plain Coupling - 14612 Key for Coupling - 14616 U-Tube Fitting Dimensions 180° U-Tube E-11 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
- Page 12 Insert tube 06413 into front casting to point (A). Tighter all set screws marked (B) until snug. After both set screws are snug, turn each additional 1/4 turn to secure tube in place. E-12 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
-
Page 13: Section 4 Engineering Specifications
2. Reflector to be of aluminum material and designed to direct all radiant output below horizontal center line of radiant tube. 3. Heaters shall be vented according to manufacturer’s recommendations. E-13 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual... -
Page 14: Section 5 Venting/Ducting
All flue joints should be sealed using suitable product such as ERSP-175 D = 10" (25.4 cm) D = 10" (25.4 cm) D = 8" (20.5 cm) E-14 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual... - Page 15 Vent Adapter Stk. #19021 Vent Adapter Stk. #19021 Burner Box Burner Box Burner Box Burner Box 4” Aluminized steel Heat Exchange Tube 4” Aluminized steel Heat Exchange Tube E-15 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
- Page 16 Pitch flue pipe down toward outlet 1/4" per foot (0.6 cm per 0.3m) for condensate drainage. 2"(5cm) Clearance thimble 2"(5cm) Clearance thimble required when flu pipe extends through combustible materials E-16 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
-
Page 17: Section 6 Gas Piping
2" 12" Heater Movement Heater Movement 0° 1/2" Stainless Steel Flex Gas Connector Heater Movement Heater Movement Stk. #16401 45° 45° 90° E-17 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual... -
Page 18: Section 7 Wiring
Igniter Wire Is 16 AWG / 25 KVDC / 10 KVDC All Quick Connects Are Fully Insulated (Except Igniter) Crimp Caps Are # CE5 / 105 Degrees C E-18 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual... - Page 19 • LP inlet pressure should be 1 1.0” (2.74 kPa) • LP outlet pressure at manifold should be 10.5” (2.61 kPa) 3. Check for proper orifice and air plate. E-19 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
- Page 20 The valve will be turned off immediately, and the combustion blower will be turned off following the optional post purge period. E-20 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
-
Page 21: Section 9 Troubleshooting
Check the continuity of the ground wire. for heat ends? Check the thermostat. Replace igniter If a problem still exists, contact Heatstar, Inc Technical Products Customer Service 1-866-447-2194 E-21 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual... -
Page 22: Replacement Parts
ERSP-60 Item Stock # Description Item Stock# Description F102650XL ERSP-60 NG / BRN & Cont Box F102652XL ERSP-80 LP / BRN CONT Box F102651XL ERSP-60 LP / BRN & Cont Box F102653XL ERSP-80 NG / BRN CONT Box F106404XL ERSP-60, / Tube Set- 20'... - Page 23 ERSP-100, / Tube Set- 30' 14616 Key for Tube Coupling 06413 Tube H.E. 4" O.D. X 10' 00419 Reflector End Cap 00418A Reflector 09369 Spring Clips 03447 Turbulator Baffle 5' 14585P Hanger E-23 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
- Page 24 14585 Hanger F102661XL ERSP-175 LP / BRN & Cont Box 00419 Reflector End Cap F106407XL Tube Set- 50' 09369 Spring Clips 06413 Tube H.E. 4" O.D. X 10' E-24 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
- Page 25 LP TO NG 1 1739 NG TO LP ERSP-150 1 1740 LP TO NG 1 1741 NG TO LP ERSP175 1 1730 LP TO NG 1 1731 NG TO LP E-25 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
- Page 26 125K AIR PLATE 10414A 150K-175K PRESSURE SWITCH 05503XL 150K AIR PLATE 07376 BLOWER MOTOR 05796 150 NG ORIFICE 05508XL 175K AIR PLATE 05794 40K NG ORIFICE 05728 150 LP ORIFICE E-26 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
- Page 27 NOTES : E-27 Enerco | Heatstar ERSP Series Heater Operating Instructions and Owner’s Manual...
-
Page 28: Warranty Information
The company warrants this product to be free from imperfections in material or workmanship, under normal and proper use in accordance with instructions of the Heatstar Company, for a period of 10 years from the date of delivery to the buyer with the following exceptions.
