Page 1 Safety Light Curtain F3SJ-A□□□□P□□-01TS Series User's Manual Cat. No. SCHG-722K...
Page 2 Original instructions Introduction Thank you for purchasing the F3SJ Series Safety Light Curtain (hereinafter referred to as the "F3SJ" ). This is the instruction Manual describing the use of F3SJ. Always heed the following points when using the F3SJ: Be sure to have F3SJ be handled by a "Responsible Person" who is well aware of and familiar with the machine to be installed. The term "Responsible Person"...
Page 3 2. The F3SJ-A is electro-sensitive protective equipment (ESPE) in accordance with European Union (EU) Machinery Directive Index Annex V, Item 2. 3. EC Declaration of Conformity OMRON declares that the F3SJ-A is in conformity with the requirements of the following EC Directives: Machinery Directive 2006/42/EC EMC Directive 2014/30/EU 4.
Page 4 (a) Exclusive Warranty. Omron's exclusive warranty is that the Products will be free from defects in materials and workmanship for a period of twelve months from the date of sale by Omron (or such other period expressed in writing by Omron). Omron disclaims all other warranties, express or implied.
Page 5 Performance Data. Data presented in Omron Company websites, catalogs and other materials is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the result of Omron's test conditions, and the user must correlate it to actual application requirements.
Page 6: Precautions On Safety
Precautions on Safety Precautions on Safety Regarding the alert symbols and meanings used for the safe uses In order to use the F3SJ safely, the precautions listed in this manual indicated by alert symbols and descriptions must be followed. Failure to follow all precautions and alerts may result in an unsafe use or operation.
Page 7 For installation An actual performance is different according to the state of the installation, the user environment, and the application. Make sure to test the operation of the F3SJ after installation to verify that the F3SJ operates as intended. Make sure to stop the machine until the test is complete. Unintended function settings may cause a person to go undetected, resulting in serious injury.
Page 8 When using more than 1 set of F3SJ, install them so that mutual interference does not occur, such as by configuring series connections or using physical barriers between adjacent sets. Make sure that the F3SJ is securely mounted and its cables and connectors are properly secured.
Page 9 For the F3SJ to comply with IEC 61496-1 and UL 508, the DC power supply unit must satisfy all of the following conditions: ± • Must be within the rated power voltage (24V DC 20%) • Must have tolerance against the total rated current of devices if it is connected to multiple devices •...
Page 10: Precautions For Safe Use
Precautions for Safe Use Precautions for Safe Use Make sure to observe the following precautions that are necessary for ensuring safe use of the product. • Thoroughly read this manual and understand the installation procedures, operation check procedures, and maintenance procedures before using the product. •...
Page 11 •Install the emitter and receiver so that their vertical direction should match. •If the protective height is 600 mm or more, use intermediate mounting brackets of specified quantities and locations according to the dimensions. If the brackets described above are not used, ratings and performance cannot be not met. •Sharing the power supply with other devices may cause the F3SJ to be affected by noise or voltage drop.
Page 12: Checking The Contents
Checking the Contents Before use, confirm that the items below were shipped with the product. If you find that an item is missing, please contact your local branch office or distributor. Product Quantity F3SJ-AP-01TS main unit Emitter x 1, Receiver x 1 Top/bottom mounting brackets 4 sets Intermediate mounting brackets...
Page 13: How To Read This Manual (Explanation Of Symbols)
How to Read This Manual (Explanation of Symbols) Indicates the description of an essential point regarding a function, such as an important point regarding operation or advice on how to use it. Indicates the page number for related content. Indicates a reference for when there is trouble, or an explanation of difficult words. F3SJ-A User’s Manual...
Page 14 F3SJ-A User’s Manual...
Page 15: Table Of Contents
Contents Legislation and Standards Terms and Conditions Agreement Precautions on Safety Precautions for Safe Use viii Precautions for Correct Use viii Checking the Contents How to Read This Manual (Explanation of Symbols) Chapter1 Overview and Specifications Basic Configuration and Names Application Examples Detect the Approach to a Hazardous Zone Using Multiple Sets in Combination...
Page 16 External Device Monitoring Function Muting System Upgrading F3SJ for Muting System Standard Muting Mode Wiring Diagrams Installation Standard for Muting Sensors Installation Example 1 of Standard Muting Mode (using 2 muting sensors) Installation Example 2 of Standard Muting Mode (using 4 muting sensors) Override Function (Dynamic Input) External Test Function Self-Test Function...
Page 17 Wiring Procedure Chapter4 Input/Output Circuit and Applications Input/Output Circuit Wiring Examples Using only F3SJ Connecting 2 Muting Sensors Connecting 4 Muting Sensors Connecting to an F3SP-B1P Connecting to an F3SX-E-L2R2 Connecting to a G9SA-301 Connecting to a G9SA-300-SC Connecting to a G9SB-301-D Connecting to a G9SX-AD322-T15 Using a simple wiring connector Chapter5...
Page 18 F3SJ-A User’s Manual...
Page 19: Chapter1 Overview And Specifications
Chapter1 Overview and Specifications Basic Configuration and Names Application Examples Features Indicator Display Patterns Ratings Ratings/Specifications Model Name List/Response Times Power Cable Length F3SJ-A User’s Manual...
Page 20: Basic Configuration And Names
Overview and Specifications Basic Configuration and Names This section describes the system configuration and part names of the F3SJ. Beam center-line mark Beam Emitter To attach or detach the cap and power cable, remove 4 screws shown above. Indicator Receiver Connection cable (Grey) Connection cable (Black) Extension cable...
Page 21 Overview and Specifications Component Model name Description F39-JDA Extension Cable with connector on one This extension cable is used to connect the F3SJ to a cable controller with discrete terminals (e.g. F3SX, G9SA, G9SB, G9SX) or to a safety processing system (e.g. DeviceNet safety).
Page 22: Installation Example 2 Of Standard Muting Mode
Overview and Specifications Components to be selected if necessary Component Model name Description Optional bracket Use this bracket (sold separately) for dedicated applications. p.64 Series connection cable for close contact F39-JJR06L Required for connecting multiple sets of F3SJ in a series. It is used F39-JJR15L when you wish to perform series connection with minimum length.
Page 23: Application Examples
Overview and Specifications Application Examples  Detect the Approach to a Hazardous Zone The F3SJ should be installed where workers require frequent access in order to perform tasks such as maintenance, and where physical barriers are difficult to install.  Detect the Approach of a Person ...
Page 24: Using Multiple Sets In Combination
Overview and Specifications  Using Multiple Sets in Combination By installing sensors on both sides of a machine as well as in front, you can move workpieces in and out more efficiently than when a physical barrier is installed. If the sensors are aligned in a U-shape, series-connection cables can be used between sets (up to 3 sets), so that only one control device is used, drastically reducing the amount of wiring in the panel.
Page 25: Features
Overview and Specifications Features  Protective Height Available in Incremental Sizes Protective height Series Protective height Detection capability F3SJ-AP20- 245mm to 2,495mm (in 15mm increments) Dia. 20mm 01TS F3SJ-AP25- 260mm to 2,500mm (in 20mm increments) Dia. 25mm 01TS  Easy-to-Read Light Level and Error Mode Display LEVEL Incident light...
Page 26: Indicator Display Patterns
Overview and Specifications Indicator Display Patterns Emitter Receiver LEVEL LEVEL LEVEL-5 (Green) LEVEL-5 (Green) LEVEL-4 (Green) LEVEL-4 (Green) 1. Incident light level LEVEL-3 (Orange) LEVEL-3 (Orange) 1. Incident light indicator level indicator LEVEL-2 (Orange) LEVEL-2 (Orange) LEVEL-1 (Orange) LEVEL-1 (Orange) ERROR- C (Red) ERROR-C (Red) 2.
Page 27: Internal Indicator For Muting System
Overview and Specifications  Internal Indicator for Muting System Shown below are internal indicator statuses while the keycap for muting is being attached. Indicators Description Blinking Incident light level LEVEL-1 to 5 Indication status of LEVEL-1 to 5 shows the incident light level indicator status of the F3SJ.
Page 28: Ratings
Overview and Specifications Ratings  Ratings/Specifications In the model names in this table, the  contain the 4-digit number indicating the protective height (mm). F3SJ-AP20-01TS F3SJ-AP25-01TS Detection capability Opaque objects Opaque objects Diameter 20mm Diameter 25mm Beam gap 15mm 20mm Number of beams 16 to 166 13 to 125...
Page 29 Overview and Specifications F3SJ-AP20-01TS F3SJ-AP25-01TS Indicators Emitter Incident light level indicators (green LED x 2, orange LED x 3): ON based on the amount of incident light Error mode indicators (red LED x 3): Blink to indicate error details Power indicator (green LED x 1): ON while power is ON Lockout indicator (yellow LED x 1): Blinks when in lockout External device monitoring indicator (muting input 1 indicator), Test indicator (muting input 2 indicator) (green LED x2): ON/Blink according to function...
Page 30: Model Name List/Response Times
IEC61496-1, EN61496-1, UL61496-1 Type 4ESPE (Electro-Sensitive Protective Equipment) IEC61496-2, EN61496-2, UL61496-2 Type 4AOPD (Active Opto-electronic Protective Devices) IEC61508, EN61508 SIL3, EN ISO 13849-1:2015 (Category 4, PL e), ISO 13849-1:2015 (Category 4, PL e) Safety-related characteristic data See http://www.fa.omron.co.jp/safety_6en/ (EN 61508:2010)  Model Name List/Response Times □□□□...
Page 31: Power Cable Length
Overview and Specifications  Power Cable Length Extension of power cable must be the length shown below or shorter: In case F3SJ is directly connected to external power supply, or connected to G9SA-300-SC Condition Single 2 connected 3 connected Incandescent display lamps are used by auxiliary output and/or external indicator output Incandescent display lamps are not used * 100m...
Page 32 Overview and Specifications F3SJ-A User’s Manual...
Page 33: Chapter2 System Configuration And Functions
Chapter2 System Configuration and Functions How to Select a System System Selection Function List Basic System Wiring Diagrams External Test Function Self-Test Function Auxiliary Output (Non-Safety Output) Resetting Lockout External Device Monitoring Function Muting System Upgrading F3SJ for Muting System Standard Muting Mode Wiring Diagrams Installation Standard for Muting Sensors...
Page 34: How To Select A System
System Configuration and Functions How to Select a System  System Selection The required system configuration depends on the functions to be used. Decide the system to use based on the following: When not using the muting function ... Basic system When using the muting function ...
Page 35: Basic System
System Configuration and Functions Basic System Basic system indicates the F3SJ with its default factory settings. The basic system provides basic safety light curtain functions. Most functions can be used without performing additional configuration.  Wiring Diagrams  Wiring using external device monitoring function (Grey) Communication line (+) (Pink) Communication line (-)
Page 36 System Configuration and Functions  Wiring When External Device Monitoring Function Is Not Used The external device monitoring function is disabled by connecting auxiliary output 1 and external device monitoring input as shown below. (Grey) Communication line (+) (Pink) Communication line (-) +24V DC Power supply...
Page 37: External Test Function
System Configuration and Functions  Ref.: Minimum Wiring Required to Check the Operation of the F3SJ (Wiring for deactivated external device monitoring function) (Grey) Communication line (+) (Pink) Communication line (-) +24V DC Power supply  External Test Function This function forcibly stops the emission using an external signal. It can be used to verify that a safety system should properly stop when F3SJ is interrupted.
Page 38: Self-Test Function
System Configuration and Functions  Self-Test Function The F3SJ performs the self-test when power is turned ON (within 2 second, or 2.2 seconds in case of series connection) to check for errors. Also, it regularly performs the self-test (within the response time) while operating.
Page 39 System Configuration and Functions  Waveform of Safety Outputs When the F3SJ is receiving light, the safety outputs cyclically turn OFF as shown below to test the output circuit. When this OFF signal is fed back, the output circuit is diagnosed as normal. If the output signal does not include an OFF pulse signal, the receiver diagnoses a failure in the output circuit or wiring, and it enters lockout state.
Page 40: Auxiliary Output (Non-Safety Output)
System Configuration and Functions  Auxiliary Output (Non-Safety Output) The auxiliary output is used to monitor the status of the F3SJ. This output can be connected to a device such as a relay, indication lamp, programmable controller, etc. Do not use the auxiliary output or external indicator output for safety applications. Human body may not be detected when F3SJ fails, resulting in serious injury.
Page 41: External Device Monitoring Function
System Configuration and Functions  External Device Monitoring Function This function detects malfunctions, such as welding, in external relays (or contactors) that control the hazardous zone of a machine. This function constantly monitors that a specified voltage is applied to the receiver's external device monitoring input line, and enters lockout state when an error occurs.
Page 42: Muting System
System Configuration and Functions Muting System The muting function temporarily disables the safety function of the F3SJ, keeping the safety outputs ON even if beams are blocked. This makes it possible to install safety light curtains for AGV passage, enabling both safety and productivity.
Page 43: Upgrading F3Sj For Muting System
Through-beam or retro-reflective photoelectric sensors, proximity sensors, or limit switches can be used as muting sensors. (recommendation: OMRON E3Z series, E2E series(3-wire type), D4N series) Use 3-wire type PNP output or N.O. type contact. Two-wire type sensor cannot be used.
Page 44: Standard Muting Mode
System Configuration and Functions • Where to attach the included labels F39-CN6 key cap for muting includes internal indicator label (1). When muting system is used, affix the label (1) in a location so that the arrows are aligned with the portion of the internal indicator display indicated by the shaded zones.
Page 45 System Configuration and Functions  End Conditions If either of the following conditions are satisfied, the muting state is released. •Muting input 1 or 2 turns OFF at T3 or later (0.1s or later). •The muting continuation time exceeds the muting time limit of T2 (60s). T3(0.1s) max.
Page 46: Wiring Diagrams
System Configuration and Functions  Wiring Diagrams  Wiring When Using Muting and External Device Monitoring Function M1 *3 (Grey) Communication line (+) (Pink) Communication line (-) +24V DC Power supply : External test switch(connect to 24V if a switch is not required) : Lockout reset switch(connect to 24V if a switch is not required) : Contact by muting sensor A1 : Contact by muting sensor B1...
Page 47 System Configuration and Functions  Ref.: Minimum Wiring Required to Check the Operation of the F3SJ When Using the Muting Function (Wiring that does not use the external device monitoring function) M1 *1 *2 (Grey) Communication line (+) (Pink) Communication line (-) +24V DC Power supply...
Page 48: Installation Standard For Muting Sensors
System Configuration and Functions  Installation Standard for Muting Sensors •Set the muting sensors so that they can detect all of the passing detection objects (palettes, automobiles, etc.). Do not install in a position so that only the front or rear end of the detection object is detected.
Page 49 System Configuration and Functions The muting sensor outputs are turned ON (muting inputs are HIGH) and the safety function of the F3SJ is disabled. Hazardous zone Reflector F3SJ Workpiece Reflector F3SJ When muting sensors A1 and B1 are turned ON in this order, the muting function is enabled. In this state, the safety function of the F3SJ is disabled.
Page 50 System Configuration and Functions The muting function is released Hazardous zone F3SJ Reflector Workpiece Reflector F3SJ Muting sensor A1 is turned OFF, the muting function is released, and the safety function of the F3SJ is enabled.  Installation Distance The minimum distance, D1 [ m ], required for muting sensors to keep the muting function enabled is <...
Page 51 System Configuration and Functions  Wiring Diagrams Using a photoelectric switch as a muting sensor Using an N.O contact type switch as a muting sensor Two-wire type muting sensor cannot be used. Reflector A1, B1: N.O contact type switch A1, B1: Regressive reflection photoelectric switch + 24V DC - PNP Output...
Page 52: Installation Example 2 Of Standard Muting Mode (Using 4 Muting Sensors)
System Configuration and Functions This is the maximum value for the waveform cracks allowed for muting input 1 and 2 when muting is in effect. It is set to 0.1 sec.  Installation Example 2 of Standard Muting Mode (using 4 muting sensors) This installation example uses 4 through-beam type photoelectric sensors as muting sensors.
Page 53 System Configuration and Functions The muting sensors are blocked and the safety function of the F3SJ is disabled Hazardous zone F3SJ Workpiece Muting sensors A1 and B1 are turned OFF but A2 and B2 are ON, so the muting function is still working.
Page 54 System Configuration and Functions This distance must prevent the muting function from being enabled by a person passing through the muting sensors. Also, install the F3SJ and muting sensors so that a workpiece passes through all muting sensors before the next workpiece arrives at the first muting sensor. Workpiece Workpiece Workpiece...
Page 55 System Configuration and Functions  Timing Chart T3(0.1s ) max. Muting sensor A1 T1min to T1max T3(0.1s ) max. Muting sensor B1 T3(0.1s ) max. Muting sensor A2 T3(0.1s ) max. Muting sensor B2 T2 max. 0.15s max. *1 Enabled Muting state Disabled Blinking...
Page 56 System Configuration and Functions  Reference: Bidirectional Muting Shown below is an example of bidirectional muting with 4 retro-reflective photoelectric sensors. It can be used for applications of workpiece approaching from both directions. Connect outer muting sensors A1 and A2 to the muting input 1 and inner muting sensors B1 and B2 to the muting input 2.
Page 57 System Configuration and Functions  Reference: Preventing light interference of muting sensor When a photoelectric sensor is used as a muting sensor, light interference may cause a muting error of F3SJ. Light interference may occur due to: Reflected light Direct light Light from other F3SJ A1 B1 F3SJ...
Page 58: Override Function (Dynamic Input)
System Configuration and Functions  Override Function (Dynamic Input) The override function forcibly turns the safety outputs ON when the muting start condition is not satisfied. If a workpiece stops while passing through the detection zone of the F3SJ, as shown below, causing a muting error, the normal state cannot be recovered unless the workpiece is removed from the muting sensors and the detection zone of the F3SJ.
Page 59 System Configuration and Functions  Override End Conditions When either of the following conditions is satisfied, the function is released. •When 60 seconds has elapsed under the override state •All muting sensors are turned OFF •When the reset input turns from OFF to ON Override state can be released if a sensor transitions to lockout as well.
Page 60: External Test Function
System Configuration and Functions  External Test Function This function forcibly stops the emission using an external signal. It can be used to verify that the safety system should stop properly when the F3SJ is interrupted. To stop the emission, open the test input line of the emitter or apply 0-1.5V. The voltage must be applied for a period 0.3s plus 4 times of Toff or longer.
Page 61: Auxiliary Output (Non-Safety Output)
System Configuration and Functions  Auxiliary Output (Non-Safety Output) The auxiliary output is used to monitor the status of the F3SJ. This output can be connected to a device such as a relay, indication lamp, programmable controller, etc. Do not use the auxiliary output or external indicator output for safety applications. Human body may not be detected when F3SJ fails, resulting in serious injury.
Page 62 System Configuration and Functions F3SJ-A User’s Manual...
Page 63: Chapter3 Wiring/Installation
Chapter3 Wiring/Installation Installation Conditions Detection Zone and Approach Safety Distance Distance from Reflective Surfaces Mutual Interference Prevention Series Connection Connection Procedure Attaching External Indicators Connection Procedure Output Operation Dimensions When Using Standard Mounting Brackets When Using Optional Mounting Brackets When Using Spatter Protection Covers Mounting a Protect Bar Mounting an Environment-Resistant Case Mounting...
Page 64: Installation Conditions
Wiring/Installation Installation Conditions  Detection Zone and Approach Install a protective structure so that the hazardous part of a machine can only be reached by passing through the sensor's detection zone. Install the sensors so that part of the person is always present in the detection zone when working in a machine's hazardous zones.
Page 65: Safety Distance
Wiring/Installation  Safety Distance The safety distance is the distance that must be set between the F3SJ and a machine's hazardous part to stop the hazardous part before a person or object reaches it. The safety distance varies according to the standards of each country and the individual specifications of each machine.
Page 66 Wiring/Installation determined by comparison of the calculated values in If a person approaches the detection zone of the F3SJ perpendicularly. The greater value resulting from this comparison shall be applied. S=(K × T) + Cro . . . Formula (5) •S: Safety distance •K: Approach speed to the detection zone Safety...
Page 67 Wiring/Installation • Ts: Response time of the F3SJ from ON to OFF (s) • a: Height of machine hazardous zone (mm) • b: Height of upper edge of detection zone (mm) When Tm = 0.05 s, Ts = 0.01 s, a = 1,400 mm, b = 1,500 m: From the table above, Cro = 850 mm.
Page 68 Wiring/Installation S = K x (Ts + Tc + Tr + Tbm) + Dpf •S: Safety distance •K: Approach speed to the detection zone (the value recommended by OSHA standard is 1,600mm/s) Approach speed K is not specified in the ANSI B.11.19 standard. To determine the value of K to apply, consider all factors, including the operator's physical ability.
Page 69: Distance From Reflective Surfaces
Wiring/Installation  Distance from Reflective Surfaces Install the sensor system so that it is not affected by reflective surfaces. Failure to do so may hinder detection, resulting in serious injury. Install the sensor system at distance D or further from highly reflective surfaces such as metallic walls, floors, ceilings, or workpieces, as shown below.
Page 70: Mutual Interference Prevention
Wiring/Installation  Mutual Interference Prevention Do not use the sensor system with mirrors in a retro-reflective configuration. Doing so may hinder detection. It is possible to use mirrors to "bend" the detection zone to a 90- degree angle. When using more than 1 set of F3SJ, install them so that mutual interference does not occur, such as by configuring series connections or using physical barriers between adja- cent sets.
Page 71 Wiring/Installation Install a physical barrier between 2 sets Receiver Receiver Emitter Emitter 1. Alternate the direction of emission between 2 sets (alternation) Aligned vertically Aligned horizontally Receiver Emitter Emitter Receiver Emitter Receiver Emitter Receiver Aligned fore and aft Receiver Emitter Emitter Receiver If 2 sets are installed near each other, reflection from the surfaces may cause mutual interference.
Page 72 Wiring/Installation When using 4 or more sets that are not series-connected, the installations shown below may cause mutual interference. When mutual interference occurs, the safety outputs are turned OFF in a moment or the F3SJ enters lockout. Aligned vertically Aligned horizontally Emitter Receiver Emitter...
Page 73: Series Connection
Wiring/Installation Series Connection From 2 to 3 sets of F3SJ can be series-connected. Series connection allows them to be used as a a safety light curtain, requiring only 1 set to be wired to a controller and preventing mutual interference. If any 1 set of series-connected F3SJ is blocked, both of the safety outputs turn OFF.
Page 74 Wiring/Installation Connect an emitter to another emitter, and a receiver to another receiver, as shown below. Do not face different models of emitters and Do not series-connect an emitter and receiver. receivers toward each other. They will enter They will enter lockout state. lockout state or will be unable to detect objects.
Page 75: Connection Procedure
Wiring/Installation  Connection Procedure  When Using the F39-JJRL Series Connection Cable for Close Contact (sold separately) Remove the connection cable of the secondary-side F3SJ. (driver comes with F39-JJRL) Remove the cap from the secondary-side F3SJ. Use the F39-JJRL series connection cable for close contact to connect them. Emitter power supply 1.
Page 76 Wiring/Installation  When Using the F39-JJR3W Series Connection Cable for Extension (sold separately) Remove the caps from the primary sensor. (driver comes with key cap for muting) Use the F39-JJR3W series connection cable for extension to connect them. When changing the connection distance between the F3SJ, connect a double-ended cable F39-JDB (optional).
Page 77: Attaching External Indicators
Wiring/Installation Attaching External Indicators An external indicator can be connected and turned ON based on the operation of the F3SJ. Indicators can be attached to emitters and/or receivers. Example: • Indicate that the F3SJ is in lockout • Indicate that a machine is stopped (safety output is OFF) •...
Page 78: Output Operation
Wiring/Installation - Attaching/detaching of a cap or a series-connection cable may cause misalignment of rubber grommet in a connector assembly. Press the grommet to the bottom of the connector and attach the connector F3SJ again. Rubber Grommet Rubber Grommet Rubber Grommet in Right Position Misaligned Grommet ...
Page 79: Dimensions
Wiring/Installation Dimensions  When Using Standard Mounting Brackets  Backside Mounting Top/bottom mounting bracket Intermediate mounting bracket The adjustment angle of F39-LJ3 is from -10deg to +10deg. 2-Top/bottom mounting brackets 2-Mounting holes (Unit: mm) 4-M5 Intermediate mounting 2-M5 bracket 2-Mounting holes Beam 4-Mounting holes dia.
Page 80 Wiring/Installation  Side Mounting Top/bottom mounting bracket Intermediate mounting bracket The adjustment angle of F39-LJ3 is from -10deg to +10deg. 2-Top/bottom (Unit: mm) mounting brackets 2-Mounting holes Beam dia. 6 4-Mounting holes dia. 6.5 2-Mounting holes dia. 9 M12 Waterproof connector Bracket mounting procedure (Mounting) p.82 F3SJ-A User’s Manual...
Page 81 Wiring/Installation Dimensions A to E C + 74 C + 46.5 4-digit number of the model name (protective height) C - 20 Depends on the protective height. See the table below. Dimension E Number of intermediate Protective height mounting brackets 0245 to 0596 0600 to 1130 1136 to 1658...
Page 82: When Using Optional Mounting Brackets
Wiring/Installation  When Using Optional Mounting Brackets  F39-LJ2 Side-mounting Optional Bracket F39-LJ2 37.6 (Unit: mm) 4-M5 dia. 6.5 dia. 9 Material: Stainless steel Dimensions A to C C + 74 C + 39.5 4-digit number of the model name (protective height) F3SJ-A User’s Manual...
Page 83 Wiring/Installation  F39-LJ3 Free-location Mounting Bracket Backside mounting The adjustment angle of F39-LJ3 is from -10deg to +10deg. (Unit: mm) 6-M5 Material: Zinc die-cast F3SJ-A User’s Manual...
Page 84 Wiring/Installation Side mounting (when using intermediate brackets for side mounting) The adjustment angle of F39-LJ3 is from -10deg to +10deg. (Unit: mm) 6-M5 Material: Zinc die-cast/stainless steel F3SJ-A User’s Manual...
Page 85 Wiring/Installation Side mounting (when not using intermediate brackets for side mounting) The adjustment angle of F39-LJ3 is from -10deg to +10deg. (Unit: mm) 6-M5 2-dia. 5.5 53 42 Material: Zinc die-cast When performing side mounting without using intermediate brackets for side mounting, F39-LJ3 brackets cannot be used in combination with standard brackets.
Page 86 Wiring/Installation Dimensions B, C, and F C - 90 4-digit number of the model name (protective height) Depends on the protective height. See the table below. Dimension F Number of intermediate Protective height mounting brackets 245 to 440 443 to 785 794 to 1140 1145 to 1490 1495 to 1840...
Page 87 Wiring/Installation  F39-LJ4 Top/bottom Mounting Bracket B Backside mounting F39-LJ4 Use standard brackets (Unit: mm) 4-M5 19(*1) Material: Stainless steel *1 A mounting width of 18 to 20 can be supported when mounting with M5 screws. Dimensions A to C C + 109 C + 66 4-digit number of the model name (protective height)
Page 88 Wiring/Installation Side mounting F39-LJ4 Use standard brackets (Unit: mm) 4-M5 19(*1) Material: Stainless steel *1 A mounting width of 18 to 20 can be supported when mounting with M5 screws. Dimensions A to C C + 109 C + 66 4-digit number of the model name (protective height) F3SJ-A User’s Manual...
Page 89 Wiring/Installation  F39-LJ5 Replacement Bracket for F3SN Use these replacement brackets for an F3SN with a small protective height. (These brackets are designed for use with the F3SN's mounting holes.) Inward-facing mounting Use standard brackets F39-LJ5 (Unit: mm) 44.9 4-M5 dia.
Page 90 Wiring/Installation Outward-facing mounting Use standard brackets F39-LJ5 44.9 (Unit: mm) 4-M5 dia. 6.5 19.9 dia.9 Material: Stainless steel Dimensions A to C C + 65 C + 34 4-digit number of the model name (protective height) F3SJ-A User’s Manual...
Page 91 Wiring/Installation Inward + outward-facing mounting Use standard F39-LJ5 brackets 44.9 (Unit: mm) 4-M5 dia. 6.5 19.9 dia.9 Material: Stainless steel Dimensions A to C C + 44 C + 12 4-digit number of the model name (protective height) F3SJ-A User’s Manual...
Page 92 Wiring/Installation F3SN replacement correspondence table (F3SN mounting holes can be used without modification) •When replacing F3SN-P25 with F3SJ-AP25-01TS F3SN Replacement F3SJ Replacement method using F39-LJ5 Model name Protective height Model name Protective height F3SN-0187P25 F3SN-0217P25 F3SJ-A0260P25-01TS 260 Inward-facing mounting F3SN-0232P25 F3SJ-A0260P25-01TS 260 Inward + outward-facing mounting...
Page 93 Wiring/Installation  F39-LJ8 Space-saving Mounting Bracket Brackets that can save mounting space for top and bottom Backside mounting Use standard F39-LJ8 brackets (Unit: mm) 4-M5 Material: Stainless steel Dimensions A to C C + 23 C - 10.3 4-digit number of the model name (protective height) The F39-LJ8 and intermediate mounting brackets cannot be mounted simultaneously, so set the protective height to 600mm or less.
Page 94 Wiring/Installation  F39-LJ11 Top/bottom Mounting Bracket C Use standard brackets (Unit: mm) Hole size for mounting 4-M5 54.5 C (Protective height) 54.5 4-Mounting holes Material: Stainless steel Dimensions A to C C + 109 C + 69 4-digit number of the model name (protective height) F3SJ-A User’s Manual...
Page 95: F39-A01Po-Pac External Indicator Set
Wiring/Installation  F39-A01P-PAC External Indicator Set •F39-A01P-PAC (Unit: mm) dia. 30 dia. 9 dia. 6.5 Material: Stainless steel  When Using Spatter Protection Covers  Dimensions of the Spatter Protection Cover F39-HJ (Unit: mm) -10 mm Material: PC (protective cover) ...
Page 96: Mounting A Protect Bar
Wiring/Installation  Mounting a Protect Bar  External Dimensions of Protect Bar F39-PJ Backside mounting (Unit: mm) Hole size for mounting 3-M5 Protection Bracket (2) Hex. Bolt Using M5 Using M6 and M8 dia.9 with Washer and Hole (13.75) 2-M8 dia.6.5 16.5 4-M5...
Page 97 Wiring/Installation Side mounting (Unit: mm) Hole size for mounting 3-M5 Protection Bracket (2) Hex. Bolt Using M5 Using M6 and M8 dia.9 with Washer and Hole (13.75) 2-M8 dia.6.5 16.5 6.25 4-M5 3.75 (37) 2-M6 Protection Bracket (4) *1 (Protective 10 20 height) dia.5.5...
Page 98: Mounting An Environment-Resistant Case
Wiring/Installation  Mounting an Environment-Resistant Case  External Dimensions of Environment-Resistant Case F39-EJ Backside mounting (Unit: mm) Hole size for mounting dia. 60.5 Using M5 Using M6 and M8 dia. 9 2-M8 dia.6.5 4-M5 13.5 2-M6 (Protective height) 2-Mounting brackets (F39-EJ-R) *1 Mounting Bracket (F39-EJ-R) is not included.
Page 99 Wiring/Installation Side mounting (Unit: mm) Hole size for mounting dia. 60.5 Using M5 Using M6 and M8 dia. 9 2-M8 dia. 6.5 4-M5 13.5 2-M6 (Protective height) 2-Mounting brackets (F39-EJ-S) *1 Mounting Bracket (F39-EJ-S) is not included. Material: Acrylic resin, nitrile rubber, stainless steel Dimensions A to D C+108 C+76...
Page 100: Mounting
Wiring/Installation Mounting The procedures for using standard mounting brackets (included) are explained in this section.  Top/Bottom Mounting Brackets Mounting screws (M5x20) x 4 Top/bottom mounting bracket (2) x 4 Top/bottom mounting bracket (1) x 4 Top/bottom mounting bracket (3) x 4 *1 The quantities shown here are the number of Mounting screws (M3x8) x 8 parts included in 1 top/bottom mounting bracket set...
Page 101: Mounting Procedure
Wiring/Installation  Mounting Procedure Attach the top/bottom mounting brackets. Place top/bottom mounting bracket (2) in the screw hole at the top/bottom of the F3SJ, and fasten it using the included screw (M5x20). Insert the bracket's protrusion into the groove on the case when attaching.
Page 102 Wiring/Installation Attach the intermediate mounting brackets (for backside mounting). For backside mounting, first lightly attach intermediate mounting bracket (1) to the equipment, wall surface, etc. Then, attach intermediate brackets (1) and (4) to the bracket that was lightly attached to the case in step 2 above, and lightly tighten them using the included mounting screws (M4x25).
Page 103 Wiring/Installation Fasten to equipment. Attach top/bottom mounting bracket (1) to the equipment, wall surface, etc. If you are using an intermediate mounting bracket for side mounting, also attach the side-mounting intermediate bracket to the equipment, wall surface, etc. After the F3SJ is mounted, securely tighten the mounting screws (M3x10) that were lightly tightened in step 2 above.
Page 104: Adjustment Procedure
Wiring/Installation  Adjustment Procedure Check the following points: - The optical surface of the emitter and receiver should be clean. - There should be no interrupting object in the detection zone of the F3SJ. Adjust the emitter's beams. Adjust the angle of the emitter while checking the incident light level indicator, and align the emitter so that it faces the center position where the incident light level indicator turns ON.
Page 105: Wiring
Wiring/Installation Wiring  Wiring Precautions Double or reinforced insulation from hazardous voltage must be applied to all input and output lines. Failure to do so may result in electric shock. Connect the load between the output and 0V line. (PNPoutput) Connecting between the output and +24V line is dangerous because the operation mode is reversed to "ON when blocked".
Page 106: Power Supply Unit
"circuit protection such as a fuse is used to limit the current, which has a rating of 4.2A max." (24VDC power supply). Recommended power supply: OMRON S82K (15 W, 30 W, 50 W, 90 W type), S8VS (60 W type), S82J (10 W, 25 W, 50 W type) These products are approved by UL listing (UL508, class 2 power supply), CE marking compatible (EMC/Low Voltage Directive).
Page 107: Wiring Procedure
Wiring/Installation  Wiring Procedure Connect an emitter cable (F39-JD-L, grey, sold separately) to the emitter's connection cable (grey). Connect a receiver cable (F39-JD-D, black, sold separately) to the receiver's connection cable (black). Connect the 0V line of the power supply directly to the protective earth (PE). To ensure proper wiring, check that the color of the cable matches the color of the connector's resin cover (emitter: grey, receiver: black).
Page 108 Wiring/Installation  Series Connection Cable for Close Contact(F39-JJRL, sold separately) 33.4 33.4 (Unit: mm) Set model name For emitter For receiver L (mm) F39-JJR06L F39-JJR06L-L Grey cable F39-JJR06L-D Black cable F39-JJR15L F39-JJR15L-L F39-JJR15L-D  Series Connection Cable for Extension (F39-JJR3W, sold separately) (Unit: mm) 33.4 39.5...
Page 109 Wiring/Installation  Connection Cable (F39-JJR3K, sold separately) The connection cable is a standard included product. Purchase a replacement when damaged or lost. (Unit: mm) 33.4 Connector 21.4 Body color: Black M12 Waterproof connector (plug) Insulated vinyl round cable dia. 6, shielded 8-wire (Cross section of conductor: 0.15mm / Insulator diameter: 1mm) Set model name...
Page 110 Wiring/Installation Internal wiring diagram (F39-JDB-L, F39-JDB-D) Connected to single-end connector cable, Cable Connected to connection cable and with connectors on both ends, Controller F3SP-B1P, Cable with connectors on both ends Simple Wiring Connector White White Brown Brown Black Black Yellow Yellow Grey Grey...
Page 111 Wiring/Installation Internal wiring diagram (F39-JCC-L) Connected to emitter's connection cable Connected to controller G9SA-300-SC and Cable with connectors on both ends Blue Brown Brown Green Yellow Grey Pink Green Blue Grey Pink Female Male Shield Shield Internal wiring diagram (F39-JCC-D) Connected to receiver's connection cable Connected to controller G9SA-300-SC and Cable with connectors on both ends...
Page 112 Wiring/Installation  Simple wiring connector (optional: F39-CN5) (52) 13.6 24.7 13.6 φ 8 (SPOT FACING 2) φ 4.5 32.1 17.7 Internal Wiring Diagram (Optional: F39-CN5) Connected to emitter's connection cable Connected to receiver's connection cable and Cable with connectors on both ends and Cable with connectors on both ends White White Brown...
Page 113: Chapter4 Input/Output Circuit And Applications
Chapter4 Input/Output Circuit and Applications Input/Output Circuit Wiring Examples Using only F3SJ Connecting 2 Muting Sensors Connecting 4 Muting Sensors Connecting to an F3SP-B1P Connecting to an F3SX-E-L2R2 Connecting to a G9SA-301 Connecting to a G9SA-300-SC Connecting to a G9SB-301-D Connecting to a G9SX-AD322-T15 Using a simple wiring connector F3SJ-A...
Page 114: Input/Output Circuit
Input/Output Circuit and Applications Input/Output Circuit The numbers in white circles indicate the connector's pin numbers. The black circles indicate connectors for series connection. The words in brackets [ ] indicate the signal name for muting system. Indication External indicator output 2 +24V DC Brown Brown...
Page 115: Wiring Examples
Input/Output Circuit and Applications Wiring Examples Some examples of a motor control system using F3SJ are shown. The examples are equivalent to ISO 13849-1 (Category 4, PLe).  Using only F3SJ •Use of relay contact welding detection and is possible without a controller or relay unit - Using external device monitoring function Emitter Receiver...
Page 116: Connecting 2 Muting Sensors
Input/Output Circuit and Applications  Connecting 2 Muting Sensors • Attaching a key cap for muting (F39-CN6) enables the muting function to be used Attaching the key cap for muting (F39-CN6) p.25 Muting lamp (external indicator) - Using external device monitoring function Emitter Receiver F39-JD A-L...
Page 117: Connecting 4 Muting Sensors
Input/Output Circuit and Applications  Connecting 4 Muting Sensors • Attaching a key cap for muting (F39-CN6) enables the muting function to be used Attaching the key cap for muting (F39-CN6) p.25 Muting lamp - Using external device monitoring function (external indicator) :External test switch (connect to 24V if a switch is not required)
Page 118: Connecting To An F3Sp-B1P
Input/Output Circuit and Applications  Connecting to an F3SP-B1P •Reduced wiring due to connector connection •Safety relay included Emitter Receiver - Using external device monitoring function Model F39-JD Model F39-JD Test Reset Auxiliary output Safety Safety Output2 K1 Output1 External device monitoring T31 T32 Model F3SP-B1P...
Page 119: Connecting To An F3Sx-E-L2R2
Input/Output Circuit and Applications  Connecting to an F3SX-E-L2R2 •Emergency stop switch can be connected •Door switch, two hand control, single beam, or relay unit can be used in combination with F3SX •Various settings can be changed and input/output terminals can be monitored using the setting support software for F3SX L2 Module - F3SJ settings...
Page 120: Connecting To A G9Sa-301
Input/Output Circuit and Applications  Connecting to a G9SA-301 Emitter Receiver - F3SJ settings - Does not use external device monitoring function - G9SA-301 settings - Manual reset mode - Using feedback loop - Using emergency stop switch F39-JD F39-JD Communication line (+) (Grey) Communication...
Page 121: Connecting To A G9Sa-300-Sc
Input/Output Circuit and Applications  Connecting to a G9SA-300-SC •Reduced wiring due to connector connection - F3SJ settings - Not using external device monitoring - G9SA-300-SC settings Emitter Receiver - Manual reset mode - Using feedback loop Model F39-JC Model F39-JC +DC24V (Note 2) A1 A2 T11 T12 H1...
Page 122: Connecting To A G9Sb-301-D
Input/Output Circuit and Applications  Connecting to a G9SB-301-D •Thin (22.5mm thick) Emitter Receiver - F3SJ settings - Does not use external device monitoring function - G9SB-301-D settings - Manual reset mode - Using feedback loop F39-JD A-L F39-JD A-D Communication line (+) (Grey) Communication...
Page 123 Input/Output Circuit and Applications  Connecting to a G9SX-AD322-T15 •Can be configured for partial control and total control •Can be extended to connect a door switch or a relay unit Receiver Emitter - F3SJ settings - Not using external device monitoring - G9SX-AD322-T15 settings - Auto reset mode - Using feedback loop...
Page 124: Using A Simple Wiring Connector
Input/Output Circuit and Applications  Using a simple wiring connector •A combination of a cable for reduced wiring (F39-JDBA) and a simple wiring connector (F39-CN5) can be used for a reduced wiring system. F3SJ F3SJ Emitter Receiver Simple Wiring Connector F39-CN5 Cable with connector on one end...
Page 125: Chapter5 Checklists
Chapter5 Checklists Pre-Operation Checklists Maintenance Checklists F3SJ-A User’s Manual...
Page 126: Pre-Operation Checklists
Checklists Pre-Operation Checklists Make sure to test the operation of the F3SJ after installation to verify that the F3SJ operates as intended. Make sure to stop the machine until the test is complete. Unintended function settings may cause a person to go undetected, resulting in serious injury. After installation, the highest level administrator must use the following checklist to verify the operation, placing a check mark in each of the boxes.
Page 127 Checklists A secondary sensor farthest from its power supply has either of the followings: - Cap - Key cap for muting - Muting lamp (set of lamp and cable) Neither connector, cap, or bracket must be loose. Auxiliary outputs 1, and external indicator outputs 1 and 2 must not be used as safety output. Power supply's 0V must be grounded.
Page 128: Maintenance Checklists
Checklists Maintenance Checklists Perform daily and 6-month inspection for the F3SJ. Otherwise, the system may fail to work prop- erly, resulting in serious injury. Do not try to disassemble, repair, or modify this product. Doing so may cause the safety functions to stop working properly.
Page 129 Checklists  Checking that Hazardous Parts Stop While the Machine Operates The hazardous parts are movable when nothing is in the detection zone. The hazardous parts stop immediately when a test rod is inserted into the detection zone at 3 positions: "directly in front of the emitter", "directly in front of the receiver", and "between the emitter and receiver".
Page 130 Checklists F3SJ-A User’s Manual...
Page 131: Chapter6 Appendix
Chapter6 Appendix Troubleshooting Accessories (Sold Separately) Glossary Related Standards Revision History F3SJ-A User’s Manual...
Page 132: Troubleshooting
Appendix Troubleshooting  Lockout State If F3SJ detects any failure, it keeps safety output OFF and transitions to lockout state. Under lockout state, an emitter and a receiver set lockout indicator and OFF indicator blinking respectively, and F3SJ that detected the failure sets an error mode indicator ON or blinking based on the failure. Solve the problems based on the table below.
Page 133 Appendix For other combinations of indication statuses of the error mode indicators on the emitter and receiver than in the table below, refer to the indication status information of the emitter and receiver, respectively in the table. Blink Emitter Receiver Error code Error Description Cause...
Page 134 Appendix Emitter Receiver Error code Error Description Cause Solution Lockout of other A sensor other than the primary Solve the problem of an emitter or sensor than the receiver is in lockout when series- F3SJ in a series connection. primary receiver connected.
Page 135 Appendix Emitter Receiver Error code Error Description Cause Solution 5B, 5E Incorrect wiring of The reset input line is not properly Check wiring of reset input line reset input line/ wired. and emitter side white line. p.17 white wire on the Emitter side white line is short- emitter side circuited to 24V...
Page 136 Appendix Emitter Receiver Error code Error Description Cause Solution Effect of noise is excessive. If other devices using the same power supply generate noise, do not share the same power supply with other devices and use it as that exclusive for the safety component.
Page 137 Appendix Emitter Receiver Error code Error Description Cause Solution Error code Effect of noise. Effect of noise is excessive. If other devices using the same other than power supply generate noise, do those above not share the same power supply with other devices and use it as that exclusive for the safety component.
Page 138: Problem Under Other State Than Lockout
Appendix  Problem under other state than lockout Shown below are actions to take when F3SJ does not work properly while no lockout occurred or no error code is displayed. ON, blink, or OFF depending on the setting •Light intensity level indicators do not turn ON even if a beam receives light, while only the power indicator and OFF output indicator are being turned ON Emitter Receiver...
Page 139: Accessories (Sold Separately)
Appendix Accessories (Sold Separately) Cable with connector on one end (2 cables per set, for emitter and receiver) Appearance Model name Cable length Specifications F39-JD3A M12 connector (8-pin) - 8 wires + Shield F39-JD7A F39-JD10A F39-JD15A F39-JD20A Cable with connectors on both ends: For connection with F3SP-B1P or cable extension (2 cables per set, for emitter and receiver) Appearance Model name...
Page 140 Single-Ended Cable: F39-JD10A-D Note: Also available is a combination of cables for an emitter and a receiver with other lengths than the above. For details, contact Omron. * 1. Double-ended cable for an emitter and single-end cable for a receiver.
Page 141 Appendix Universal indicator cable Appearance Model name Cable length Specifications F39-JJ3N Cap (10-pin) - 2 wires External indicator set Appearance Model name Color Specifications F39-A01PR-PAC Cap (10-pin) - M12 connector (8-pin) Mounting brackets included Cable length 0.1m F39-A01PG-PAC Green F39-A01PY-PAC Yellow Key cap for muting Appearance...
Page 142 Appendix Control unit Appearance Model name Output Note F3SX-N- - A door switch, two-hand control switch, Relay, 2a+1b contact single beam, or relay unit can be added to (expandable) the F3SX. - F3SJ with PNP output can be connected. - Can be used as a muting system if an F39- JDA cable with connectors at both ends is used.
Page 143 Appendix Control unit Appearance Model name Output Note - F39-JDA cable with connector on one G9SX-AD322-T15 Solid-state output end is required. (Instantaneous - F3SJ with PNP output can be connected. output X 3, OFF- - OFF-delay within 15 seconds can be set to delay output X 2) 16 levels.
Page 144 Appendix Environment-resistant case Appearance Model name Note For emitter F39-EJ-L One environment-resistant case is provided in a set. Mounting bracket is not included. You must purchase optional back-mounting bracket (F39-EJ-R) or side-mounting bracket (F39-EJ-S). When environment-resistant case is used, For receiver F39-EJ-D operating range is from 0.2 to 7m (protective height of 1649mm or less) and from 0.2 to 5m (protective height of 1655mm or more).
Page 145 Appendix Top/bottom mounting bracket (for top/bottom mounting) Appearance Model name Application Note F39-LJ1 (Standard brackets included 2 brackets for emitter, 2 with the F3SJ) brackets for receiver (4 brackets Purchase replacements when per set) damaged or lost. Side flat mounting bracket (4 brackets per set) Appearance Model name Application...
Page 146 Appendix Space-saving mounting bracket Appearance Model name Application Note F39-LJ8 Brackets that can save 2 brackets for an emitter, 2 for a mounting space for top and receiver (4 brackets per set) bottom Top/bottom mounting bracket C Appearance Model name Application Note F39-LJ11...
Page 147: Glossary
Appendix Glossary Term Definition Allowable delay time The allowable amount of time from when the safety output changes until the external device monitoring input changes. The F3SJ enters lockout if this time is exceeded. Auxiliary output 1 Allows output appropriate for the setting. This CANNOT be used for safety applications. Basic system This refers to the F3SJ in the state it is in when purchased.
Page 148: Related Standards
Appendix Related Standards  International Standards • IEC61496-1:2012 Safety of machinery - Electro-sensitive protective equipment - Part 1: General requirements and tests • IEC61496-2:2013 Safety of machinery - Electro-sensitive protective equipment - Part 2: Particular requirements for equipment using active opto-electronic protective devices •...
Page 149: Canadian Standards
Appendix • ANSI B11.13:1992(R1998) Single- and multiple-spindle automatic bar and chucking machines • ANSI B11.14:1996 Coil slitting machines/systems • ANSI B11.15:2001 Pipe, tube, and shape bending machines • ANSI B11.16:2003 Metal powder compacting presses • ANSI B11.17:2004 Horizontal hydraulic extrusion presses •...
Page 150: Revision History
Appendix Revision History A manual revision code appears as a suffix to the manual number at the bottom of the front and back covers of this manual. SCHG-722 K Revision No. Revision Revision date Revisions symbol July, 2006 First edition December, 2006 Addition of F3SJ-AP25-01TS series July, 2007...
Page 151 Industrial Automation Company (Manufacturer) Authorized Distributor: Shiokoji Horikawa, Shimogyo-ku, Kyoto, 600-8530 JAPAN Contact: www.ia.omron.com Regional Headquarters OMRON EUROPE B.V. (Representative and Importer in EU) OMRON ELECTRONICS LLC Wegalaan 67-69, 2132 JD Hoofddorp 2895 Greenspoint Parkway, Suite 200 Hoffman Estates, IL 60169 U.S.A.

Omron F3SJ-A P 01TS Series User Manual

Chapter1 Overview And Specifications

Chapter2 System Configuration and Functions

Chapter3 Wiring/Installation

Chapter4 Input/Output Circuit and Applications

Chapter5 Checklists

Chapter6 Appendix

Quick Links

Need help?

Questions and answers

Related Manuals for Omron F3SJ-A P 01TS Series

Summary of Contents for Omron F3SJ-A P 01TS Series

Table of Contents
