- Page 1 Compressed Air Dryer OPERATION AND INSTRUCTION MANUAL MODELS: ACD/SCD Part Number: 882.03168.00 Effective: 02.13.2023 Bulletin Number: DRY1-600.00 Compressed Air Dryer 882.03168.00 2/13/2023...
- Page 2 Write Down Your Serial Numbers Here For Future Reference: _________________________ _________________________ _________________________ _________________________ _________________________ _________________________ We are committed to product improvement. Specifications, appearance, and dimensions described in this manual are subject to change without notice. DCN No. ____________ © Copyright 2023 All rights reserved. Compressed Air Dryer 882.03168.00 2/13/2023...
- Page 3 According to the contract terms and conditions of the Carrier, the freight claims are filed by the terms below. If the order is prepaid, ACS Group is responsible for the freight payment. ACS will file the claim with the truck line. We need pictures of the damaged freight and a copy of the delivery receipt marked Damaged Freight.
- Page 4 Please call 262-641-8600. Have the order number and item number available. Hold the items until you receive shipping instructions. Do not return any goods before receiving your RMA (Return Material Authorization) number from ACS. Returns Do not return any goods before receiving your RMA (Return Material Authorization) number and shipping instructions from ACS.
-
Page 5: Table Of Contents
Table of Contents CHAPTER 1: SAFETY ..............6 How to Use This Manual ......................6 Safety Symbols Used in this Manual ................... 6 General Safety Regulations ....................... 7 Responsibility ..........................7 Safety Tags and Warning Labels ..................6 Warnings and Precautions ...................... 10 CHAPTER 2: FUNCTIONAL DESCRIPTION ...... -
Page 6: Chapter 1: Safety
Chapter 1: Safety How to Use This Manual Use this manual as a guide and reference for installing, operating, and maintaining your machine. The purpose is to assist you in applying efficient, proven techniques that enhance equipment productivity. This manual covers only light corrective maintenance. No other maintenance should be undertaken without first contacting a service engineer. -
Page 7: General Safety Regulations
General Safety Regulations These regulations should be read, understood and periodically reviewed by all personnel involved in any way with this machine. Never operate or remove any machine components that are secured by mechanical fasteners unless the motor is electrically locked out and all moving parts are motionless. Do not circumvent the safety interlocks. -
Page 8: Safety Tags And Warning Labels
Figure 1: Safety Tags and Warning Labels Hazard Alert Symbol Description/Explanation Preventative Maintenance High Voltage Hazard. The Every six months inspect all electrical electrical enclosure is supplied connections for secure attachment. with 3-phase electrical power. For further information see the Use caution when using or Maintenance Chapter in this manual. - Page 9 Mandatory Symbol Description/Explanation Read operators Manual. This equipment must be operated and maintained by properly trained personnel. The information contained within this manual must be read and understood prior to operating this equipment. Lock Out. This equipment is operated with 3-phase electrical power.
-
Page 10: Warnings And Precautions
Warnings and Precautions Our machines are designed to provide safe and reliable operation when installed and operated within design specifications, and follow national and local safety codes. To avoid possible personal injury or equipment damage when installing, operating, or maintaining this machine, use good judgment and follow these safe practices: ... - Page 11 ROTATION OF MOTORS: The correct rotating direction for the machine motor is clearly marked on the machine. Always check for proper rotation of motors. Incorrect rotation direction can cause severe damage. ELECTRICAL GROUNDING: All electrical equipment on the machine must be grounded in accordance to all local codes and Article 250 of the National Electric Code.
-
Page 12: Chapter 2: Functional Description
Chapter 2: Functional Description Models Covered in This Manual This manual provides instructions for installing and operating your 5, 10 or 15 cfm compressed air dryer General Description Mini compressed air dryers are designed to generate heated, dehumidified air at carefully controlled temperatures for use in plastic drying systems. -
Page 13: Safety Features
Options Options can tailor your dryer to meet the exact requirements of the drying task being performed. • Floor-mount configuration • Membrane compressed air dryer for low dew point operation • 220/1/50 operation • 230/1/60 operation Safety Features This section includes information on safety devices and procedures that are inherent to the 10 cfm compressed air dryer. - Page 14 Line Cord Plug (115/1/60 units only) The line cord plug allows the operator or maintenance personnel to unplug the dryer from its power source and tag it out. This plug may be tagged with any number of approved electrical lockout tags. These tags are available at most electrical supply stores. Always disconnect power before servicing or moving this unit.
- Page 15 Remote Membrane Dryer for Low-Dew point Operation (Optional) Membrane dryers take a small percentage of the dried gas and direct it back in a sweeping pattern through the module shell. This provides a driving force to remove the moisture with the minimum purge required.
- Page 16 Microprocessor Controls The compressed air dryer uses a microprocessor-based PID temperature controller for maintaining process air temperature. The controller is a modular, self-contained unit that you can remove from the mounting housing. All parameters except for the process air set point are factory set and adjusted.
-
Page 17: Chapter 3: Installation
Chapter 3: Installation Uncrating the Equipment The compressed air dryer has a handle at the top of the cabinet to use for lifting. For hopper-mount configurations, be sure to support the hopper when lifting and placing the dryer. Use caution and observe safety rules when lifting and placing your dryer. Be sure it is securely attached and additional bracing is used if necessary. - Page 18 Connecting a Floor-Mount Dryer to a Hopper (Optional) Use high-temperature flexible dryer hose or rigid tubing to connect the dryer to the drying hopper. Keep the delivery hose to the drying hopper as short as possible to minimize heat loss. We strongly recommend insulated hose for maximum energy savings. Make sure that hoses are not kinked or collapsed.
-
Page 19: Electrical Connections
Making Electrical Connections The serial tag lists voltage, phase, and amp draw information. Line voltage must be within plus or minus ten percent of the voltage listed on the serial tag, or damage may occur. Never supply any voltage other than what the dryer is configured for. Fulfill all national, state, and local safety and electrical code requirements. - Page 20 Installing the Remote-Mount Membrane Dryer (Optional) The membrane drying kit can be mounted anywhere near the compressed air dryer. The kit is pre-assembled with a bracket that can be mounted to any flat surface with two screws. Use Figure 5 as a reference for this installation. Remove the large particle filter, including the close nipple, from the inlet of the compressed air dryer.
-
Page 21: Chapter 4: Operation
Chapter 4: Operation Before beginning dryer operation, make sure that there is a good compressed air connection and that the main power is securely plugged in. Check the process hose and hopper exhaust filter for tight connections. Check all companion equipment, such as the drying hopper; verify that the loading system is ready for operation. -
Page 22: Start-Up
Setting the Alarm Value The Alarm Value setting determines how many degrees the process temperature is allowed to exceed the set point temperature before the high temperature alarm is triggered and the heater turned off. Use the following procedure to set the alarm value: Press to scroll to Press... -
Page 23: Chapter 5: Maintenance
Chapter 5: Maintenance This dryer is designed to be virtually maintenance-free. This unit is factory-sealed. Any service required on this unit must be performed by factory personnel at the manufacturer’s facility. WARNING! The compressed air dryer is sealed at the factory. Removing this seal and opening the box that houses the dryer will void your warranty. - Page 24 Replacing the Fuse Outside of the Cabinet Note: If the compressed air dryer does not start when the ON/OFF switch is in the “ON” position, check the main power supply to ensure that it is properly installed. If the main power supply is correct, check the fuse. This is located on the front of the driver cabinet.
-
Page 25: Chapter 6: Troubleshooting
Chapter 6: Troubleshooting Introduction The utmost in safety precautions should be observed at all times when working on or around the machine and the electrical components. All normal trouble-shooting must be accomplished with the power off, circuit breakers turned off, and with the machine tagged as out of service. - Page 26 Problem Possible Cause Possible Remedy Check resin manufacturer’s data sheet for proper drying Process temperature set too temperature. Make sure high due to operator error. plant personnel are aware of the correct process Material in drying hopper temperature set point. cakes, or meltdown occurs.
- Page 27 Problem Possible Cause Possible Remedy Compressed air source is no Check compressed air longer sufficiently above 35 source for proper psi. functioning. Alarm light is on and unit has no air pressure. Regulator is set below 35 Check regulator for proper psi.
-
Page 28: Chapter 7: Appendix
Chapter 7: Appendix Customer Satisfaction Warranty Program The terms and conditions of the warranty set forth are for one (1) year from the original date of purchase by the original purchaser. The manufacturer warrants to the original purchaser the product and/or goods to which this disclaimer is attached, and manufactured by us, to be free from defects in material and workmanship under normal use and service. - Page 29 Refer to this manual for assistance in installing and maintaining a highly efficient machine. Questions regarding areas that are not covered in the manual should be referred to the customer service manager at the factory at 262-641-8600. Compressed Air Dryer 882.03168.00 2/13/2023...
-
Page 30: Technical Specifications
• Exhaust air cartridge filter • 1/16 DIN PID temperature controller • High process temperature alarm light • Automatic shutoff system to monitor compressed air supply • Full load amps: MODEL 115V 230V ACD5 3.25 ACD10 12.5 6.25 ACD15 18.5 7.25 •... - Page 31 Drying Parameters Material Drying Hopper Capacity,* lbs./hr (kg/hr) Drying Temp, Drying ºF, (ºC) time in Initial Final 0.4 cu. ft. 0.9 cu. ft. hours moisture moisture (11 liter) (25 liter) content. content drying drying 0 in % 0 in % hopper hopper 176 (80)
- Page 32 284 (140) 0.05 4.6 (2.1) 10.4 (4.7) 176 (80) 0.05 0.02 7 (3.2) 15.8 (7.1) 302 (150) 0.05 4.6 (2.1) 16.4 (7.4) 176 (80) 0.01 4.6 (2.1) 16.4 (7.4) 158 (70) 0.10 9.3 (4.2) 41.9 (19) 176 (80) 0.03 5.6 (2.5) 25.2 (11.4) 176 (80) 0.03...
-
Page 33: Spare Parts List
Spare Parts List Parts not included in this list must be replaced by the factory. Part No. Quantity Description 35452 Filter Regulator 725.00002.00 Fuse (110 volt) 725.00001.00 Fuse 220/1/50 725.00001.00 Fuse 230/1/60 CT92241 Hopper Mounting CLDMP CT94233 Hopper Mounting Gasket Compressed Air Dryer 882.03168.00 2/13/2023... -
Page 34: Technical Assistance
Technical Assistance PARTS SUPPORT ACS welcomes inquiries on all your parts needs and is dedicated to providing excellent customer service. The ACS Customer Service Group will provide your company with genuine OEM quality parts manufactured to engineering design specifications, which will maximize your equipment’s performance and efficiency.
