Operation - Craftsman 486.24352 Operator's Manual

KNOW YOUr spreader
read this owner's manual and safety rules before operating your spreader.
Compare the illustration below with your spreader to familiarize yourself with the various controls and their locations.
FLOW cONtrOL arM - Opens and closes the closure
plate in the bottom of the hopper.
adJUstaBLe stOp - Limits how far the closure plate
opens.
HOW tO Use YOUr spreader
settING tHe FLOW cONtrOL
• Loosen the nylon wing nut, set the adjustable stop to
the desired flow rate setting and retighten the wing
nut. The higher the setting number, the wider the
opening in the bottom of the hopper.
• Refer to the application chart on this page and to the
instructions on the fertilizer bag to select the proper
flow rate setting.
• Pull the flow control arm against the adjustable stop
for the on position and toward the hopper for the off
position.

OperatION

cLOsUre pLate (not shown) - Slides to open or close
the opening in the bottom of the hopper.
HItcH eXteNsION BracKet - Adjusts to allow more
clearance between the spreader and towing vehicle
7
FLOW cONtrOL arM
adJUstaBLe stOp
HItcH eXteNsION BracKet
