Introducing the SATA II PCIe Pro
The SATA II PCIe Pro is an ultra high-speed dual channel
Serial ATA Generation 2 controller for use in PCI Express-
enabled system.
Features and Benefits
•
Compliant with PCI Express Base Specification 1.0a
•
Compliant with Serial 1.0a specification with support
for full complement of SATA II optional features
•
PCI Express 1-lane (x1) SATA II adapter works with
PCI Express slots with different lane width
•
Installs in any available PCI Express slot and support
data transfer rates up to 3.0Gbps (300MBps)
•
Supports Native Command Queuing (NCQ), Non-
zero offsets NCQ, and Out-of-order date delivery
NCQ
System Requirements
PC:
•
PCI Express-enabled system with an available PCI
Express slot
•
Windows
(32-/64-bit)/Vista (32-/64-bit)
Mac:
•
PCI Express-enabled system with an available PCI
Express slot
•
Mac OS 10.4 or later
04-0397B
SATA II PCIe Pro
Quick Installation Guide
2000/XP (32-/64-bit)/Server 2003
®
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SIIG SC-SAE412-S3
Summary of Contents for SIIG SC-SAE412-S3
-
Page 1: Quick Installation Guide
SATA II PCIe Pro Quick Installation Guide Introducing the SATA II PCIe Pro The SATA II PCIe Pro is an ultra high-speed dual channel Serial ATA Generation 2 controller for use in PCI Express- enabled system. Features and Benefits • Compliant with PCI Express Base Specification 1.0a •... -
Page 2: Hardware Installation
Package Contents • SATA II PCIe Pro adapter • Driver CD • Quick Installation Guide Board Layout External connectors Figure 1. SATA II PCIe Pro Board Layout Hardware Installation General instructions for installing the card are provided below. Since the design of computer cases and motherboards vary, refer to your computer’s reference manual for further information, if needed. -
Page 3: Windows Driver Installation
Unplug the power cord and remove your computer's cover. Remove the slot bracket from an available PCIe slot. Carefully align the card to the selected PCIe slot push the board down firmly, but gently, until it is well seated. Replace the slot bracket holding screw to secure the card. - Page 4 Press Enter to continue and follow on-screen instructions to complete the installation. Existing Windows 2000 Installation Install the board and boot up Windows 2000. At the Found New Hardware Wizard, click Next. Select Search for a suitable driver for my device (recommended) and click Next.
- Page 5 Existing 32-bit Windows XP/Server 2003 Installation Install the board and boot up Windows. At the Found New Hardware Wizard. XP (w/SP1 or earlier)/Server 2003: continue to step #3. XP (w/SP2 or later)/Server 2003 (w/ SP1 or later): select No, not this time, then click Next. Note: Most systems will install the driver automatically after inserting driver CD.
- Page 6 Existing 64-bit Windows XP/Server 2003 Installation Install the board and boot up Windows. At the Found New Hardware Wizard: XP (w/SP1 or earlier)/Server 2003: continue to step #3. XP (w/SP2 or later)/Server 2003 (w/ SP1 or later): select No, not this time, then click Next. Insert the driver CD, select Install the software automatically (Recommended), then click Next.
- Page 7 32-bit Windows Vista™ New 32-bit Windows Vista Installation Install the board and follow Microsoft procedures to install Windows accordingly. At Where do you want to install Windows?, click Load Driver. Insert driver CD, then click Browse. Double click CD Drive (D:). (change D: to match your CD-ROM drive letter).
- Page 8 Double click CD Drive (D:). (change D: to match your CD-ROM drive letter). Double click 64bit folder, highlight AMD64, then click OK. Select Silicon Image SiI 3132...Controller (D:\64bit\AMD64\SI3132.inf), then click Next. Follow on-screen instructions to complete Windows Vista installation. Existing 64-bit Windows Vista Installation Install the board and boot up Windows.
-
Page 9: Bios Configuration
BIOS Configuration The SATA II PCIe BIOS will appear everytime your system starts up. If the bios doesn't show, please try your controller in another PCIe slot. During this (Post) process, the bios will show up and indicate the devices attached to it. -
Page 10: Mac Os Driver Installation
Mac OS Driver Installation This section provides information on how to install the SATA II PCIe Pro drivers. Install the SATA II PCIe Pro and boot up your system. Insert driver CD. At the desktop double click Drivers icon. Double click Mac folder. Double click Sil3132_1.1.9u_S.1_Pkg.pkg. -
Page 11: Technical Support And Warranty
Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. If the product is determined to be defective, an RMA number will be issued. SIIG RMA department can also be reached at (510) 413-5333. - Page 12 6078 Stewart Avenue Fremont, CA 94538-3152, USA SATA II PCIe Pro is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft, Windows and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
