Savoy House M2013 Series Owner's Manual

56” ceiling fan
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
56" CEILING FAN
OWNER'S MANUAL
READ AND SAVE THESE INSTRUCTIONS
MODEL: M2013XX
FAN RATING AC 120V. 60Hz
UL LISTED MODEL : AM-472

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M2013 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Savoy House M2013 Series

Summary of Contents for Savoy House M2013 Series

  • Page 1 56” CEILING FAN OWNER'S MANUAL READ AND SAVE THESE INSTRUCTIONS MODEL: M2013XX FAN RATING AC 120V. 60Hz UL LISTED MODEL : AM-472...

  • Page 2: Tools And Materials Required

    1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: a. Set of blades assembly (3) b.

  • Page 3: Safety Rules

    3. SAFETY RULES 1. To reduce the risk of electric shock, insure 10. Do not use water or detergents when cleaning electricity has been turned off at the circuit the fan or fan blades. A dry dust cloth or lightly breaker or fuse box before beginning.

  • Page 4: Mounting Options

    4. MOUNTING OPTIONS If there isn't an existing UL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Secure the outlet box directly to the building Outlet box structure. Use appropriate fasteners and building materials.

  • Page 5: Hanging The Fan

    5. HANGING THE FAN Hanger bracket REMEMBER to turn off the power. Follow the steps below to hang your fan properly: Ceiling Step 1. Remove the decorative canopy canopy bottom cover from the canopy by turning the cover counter clockwise. (Fig. 5) Canopy cover Step 2.

  • Page 6: Make The Electrical Connections

    6. MAKE THE ELECTRICAL CONNECTIONS WARNING: To avoid possible electrical shock, Outlet Box be sure electricity is turned off at the main fuse box before wiring. White (Neutral) Green or bare copper (ground) Black (Hot) Step 1. Motor to House Supply Wires Electrical Connections: Connect the WHITE wire (Neutral) Black ("AC IN L") Ground (green)

  • Page 7: Finishing The Installation

    7. FINISHING THE INSTALLATION Step 1. Tuck connections neatly into ceiling Outlet box outlet box. Step 2. Slide the canopy up to hanger bracket Hanger and place the key hole on the canopy over the bracket screw on the hanger bracket, turn canopy until it locks in place at the narrow section of the key Screws holes.

  • Page 8: Attaching The Fan Blades

    8. ATTACHING THE FAN BLADES Step 1. Insert the blade through the slot in the housing. Align the holes in the blade, the blade support plate, and the fan motor assembly and secure with a blade attachment screws with lock washers. (Fig. 11) Slot Blade Blade support plate...
  • Page 9 10. INSTALLING THE LED LIGHT KIT & LIGHT KIT DECORATIVE RING NOTE: Before starting installation, disconect the power by turning off the circuit breaker or removing the fuse at fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock.
  • Page 10 11. OPERATING INSTRUCTIONS F. The " " button is used to set the fan Insert the 3 volt battery (included) and make forward or reverse, press the button sure the battery is properly seated with the forward (for warm weather) or reverse (for Positive + sign facing up.
  • Page 11 Pairing Process: The auto-learning process will only initiate This receiver provides the following protective within the first 60 seconds of supplying power function: to the fan. 1. Lock Rotor Position: The DC motor has a Beginning with the fans power off, restore built-in safety against a stalled or locked rotor power to the fan.

  • Page 12: Care Of Your Fan

    Speed settings for warm or cool weather depend on factors such as the room size. Ceiling height, number of fans and so on. NOTE: To operate the reverse function on this fan, press the reverse button while the fan is running. Warm weather - (Forward) A downward airflow creates a cooling effect as shown in Fig.

  • Page 13: Troubleshooting

    13. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. 3. Check to make sure the dip switches from the transmitter and receiver are set to the same frequency.
