12. Make sure that the knob on the Latch
Assembly (67) is on the indicated side.
Attach the Latch Assembly (67) to the Left
Upright (66) with two #10 x 3/4" Screws (8) ; start
both Screws, and then tighten them.
13. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plastic
on the treadmill decals, remove the plastic. To protect the fl oor or carpet, place a mat under the treadmill. To
avoid damage to the console, keep the treadmill out of direct sunlight. Keep the included hex keys in a secure
place; one of the hex keys is used to adjust the walking belt (see page 22). Note: Extra parts may be
included.
12
67
Knob
8
13
66
