- Page 1 ® BRACKET PRO SERIE® 77 - FL OPERATING GUIDE SAFETY AND FLEXIBILITY WHERE IT MATTERS MOST...
-
Page 2: Copyrights
- Laerdal Compact Suction Unit is a registered trademark of Laerdal Medical Corporation. ® For any issues with your Technimount product, its components, or for any technical questions during the installation, operation, or maintenance, please contact Technical Support at techsupport@technimount.com. Contact Information Technimount E.M.S. -
Page 3: Table Of Contents
..2.2. Remove the Bracket Pro Serie 77 - FL from the Micro Base ................7 3. Perform the Daily Safety Checks ........................8 ..3.1. Required Tools ................................8 ..3.2. Daily Safety Checks ..............................8 ..3.3. Illustrated Inspections Parts ............................10 © 2023 Technimount E.M.S. Holding Inc. OG-BP77FL-202306EN-01 | Page iii of iii... -
Page 4: Safety Guidelines
CAUTION - Safe Handling and Operation - Improper use of the Technimount product may damage the device or cause injury to the patients or EMS personnel. - The Bracket Pro Serie 77 - FL is intended for Laerdal Compact Suction Unit 4 with 300 ml disposable canister and tubing. -
Page 5: Operate The Bracket Pro Serie 77 - Fl
NOTE: Always perform the Safety checks BEFORE using the Bracket Pro Serie 77 - FL. Refer to the "Daily Safety Checks" on page 8 before each use NOTE: Technimount continually seeks advancements in product design and quality. While this operating guide contains the most updated product information available at the time of printing, it may contain minor differences from the current version. -
Page 6: Install The Bracket Pro Serie 77 - Fl On A Micro Base
® 2.1. Install the Bracket Pro Serie 77 - FL on a Micro Base NOTE: Only a Technimount bracket with an anti-rotation micro disc or bottom micro disc can be installed on a Micro Base. 1. Align the bottom micro disc with the Micro Base opening (Figure 2 A). -
Page 7: Remove The Bracket Pro Serie 77 - Fl From The Micro Base
Press and hold the quick release button of the Micro Base (Figure 4 A), then pull the bracket out of the base horizontally and set it aside (Figure 4 B). Figure 4: Removing the Bracket Pro Serie 77 - FL from the Micro Base © 2023 Technimount E.M.S. Holding Inc. OG-BP77FL-202306EN-01 | Page 7 of 12... -
Page 8: Perform The Daily Safety Checks
3. Perform the Daily Safety Checks Daily safety checks on Technimount products are recommended to keep them in good condition and avoid failure or injury to the patient or EMS personnel. EMS personnel should perform the daily safety checks at the beginning of each work shift. - Page 9 BRACKET PRO SERIE 77 - FL ® Operating Guide ® DAILY SAFETY CHECKS COMPLIANT INSPECTIONS Daily Safety Checks completed on (dd/mm/yyyy), by Comments and observations: © 2023 Technimount E.M.S. Holding Inc. OG-BP77FL-202306EN-01 | Page 9 of 12...
-
Page 10: Illustrated Inspections Parts
3.3. Illustrated Inspections Parts 1. Bracket Pro Serie 77 - FL 3. Bottom micro disc 2. Retaining frame Figure 5: Bracket Pro Serie 77 - FL inspection parts © 2023 Technimount E.M.S. Holding Inc. OG-BP77FL-202306EN-01 | Page 10 of 12... - Page 11 BRACKET PRO SERIE 77 - FL ® Operating Guide ® © 2023 Technimount E.M.S. Holding Inc. OG-BP77FL-202306EN-01 | Page 11 of 12...
- Page 12 Critical Care Transport (CCT) teams for ground and air ambulances. Safety is at the core of our values, all Technimount systems are tested in compliance with the highest industry standards for impact resistance. Technimount EMS is committed to developing innovative solutions as healthcare practices evolve.
