D-Link xStack Storage DSN-5210 Hardware Reference Manual page 18

Switch / LED
Power
Reset
Restart
Table 2-6. Rear Panel LEDs (xStack Storage DSN-5210 and xStack Storage DSN-5410)
Switch / LED
Ready/Fault
"A" and "B" LEDs
10 Chapter 2 DSN-5000 Series Primary Array Layout
Table 2-3. Port Speed and Port Activity LEDs (xStack Storage DSN-5210)
LED Color
Port Speed Yellow
Port Activity Green
Table 2-4. Port Speed and Port Activity LEDs (xStack Storage DSN-5410)
LED Color
Port Speed Yellow
Port Activity Green
Table 2-5. Rear Panel Switches
Applies power to the DSN-5000 series primary array. The DSN-5000 series primary array has two
power switches. Both must be turned on.
Resets the system. This switch is recessed to prevent against accidental resets. Note: This switch
simply reboots the system without changing your configuration.
This switch is reserved for future use.
Color
OFF Primary array is powered off or performing its Power On Self Test.
Red ON = a fault has occurred. Please contact D-Link Technical Support.
Green ON = normal operation.
OFF Battery is fully charged and not sustaining cache.
Green ON = battery is good or being charged.
Flash = contents of system cache memory is being preserved by the battery subsystem
after an unexpected loss of power or system failure has occurred.
Yellow These LEDs are reserved for future use.
Description
ON = link is operating at 1 Gbps.
OFF = link is operating at either 10 Mbps or 100 Mbps.
ON = link is operational.
Blink = data is being sent or received.
ON = link is operating at 10 Gbps
OFF = link is not operating
ON = link is operational
Blink = data is being sent or received
Description
Description
Description
