Tighten all wheel bolts to 120nm after the first 2 hours of driving.
Transport
*
Only use stable loading surfaces with sufficient loading capacity (see section 2.2).
*
Secure the MULTI-MOVER L against tilting or sliding.
*
It is prohibited to;
-
get under the MULTI-MOVER L while lifting
-
remain within the tilting range of the MULTI-MOVER L during unloading
MULTI-MOVER L25S
USER MANUAL and PARTS LIST
MULTI-MOVER L25S
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L25S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Multi-Mover L25S

Summary of Contents for Multi-Mover L25S

  • Page 1 Only use stable loading surfaces with sufficient loading capacity (see section 2.2). Secure the MULTI-MOVER L against tilting or sliding. It is prohibited to; get under the MULTI-MOVER L while lifting remain within the tilting range of the MULTI-MOVER L during unloading MULTI-MOVER L25S...

  • Page 2: Table Of Contents

    Chapter 8 FAILURES Chapter 9 PARTS Chapter 10 DECLARATION OF CONFORMITY Appendix Electrical circuit diagram (optional) Appendix User manual battery charger (see box) Multi-Mover Europe B.V. www.multi-mover.eu T +31 24 744 00 70 F +31 24 890 17 90 MULTI-MOVER L25S...

  • Page 3: Introduction / Warranty / Definitions / Safety Symbols

    The user manual should be made available to the user of the Multi-Mover L and must be present at the Multi-Mover L when it is being used. The user manual must have been read by anyone working with/at the Multi-Mover L, and the instructions must be observed.

  • Page 4: Chapter 2 Technical Description

    Safety symbols On various places on the Multi-Mover L you will find standardized safety symbol stickers as displayed to the right. The upper part warns against a general or particular hazard. The lower part indicates what type of hazard is being warned against and will explain what you must do.

  • Page 5: Packaging, Loading / Unloading, Towing, Recycling

    Avoid injury and damage as a result of incorrect placement of the lift truck's lift forks. Loading and unloading If the Multi-Mover L has to be moved by means of a lift truck, the lift forks must be placed at the heaviest part at the rear of the Multi-Mover L, between the 2 large wheels.

  • Page 6: Chapter 3 Safety Regulations

    Never drive onto a slope at an angle or crosswise. Only ever drive on and off a slope at a right angle. The Multi-Mover L with trailer(s) may also tip over if the bends are taken at a speed that is too high.
  • Page 7 Make sure the trailer(s) has/have been loaded evenly and safely. 3.11 Caution! Wear clothing that allows you to move freely and does not hinder your view on the Multi-Mover L plus trailer(s). Observe your company's safety regulations. 3.12 Caution! Hazard of injury. In case of an unusual noise;...
  • Page 8 Multi-Mover L, temporary personnel for instance. The MULTI-MOVER L may only be operated after the operator has thoroughly studied the user manual and after the owner of the Multi-Mover L has provided a full training / instruction concerning the operation and the safety regulations.

  • Page 9: Chapter 4 Preparation

    - only original Multi-Mover Europe BV or CE certified parts may be used in the Multi-Mover L. 3.23 As the operator you will determine the limits for "safe driving / working" with the Multi-Mover L. Do not take any risks. Be particularly careful in case of obstacles or uneven terrain.

  • Page 10: Responsibility Operator

    - check the jam safety on the steering handle by pressing the safety switch (3, fig. 2), the Multi-Mover L should not start in that case. If you establish a fault, or if you have any doubts concerning the operation of the Multi-Mover L you must immediately report this to your supervisor or the maintenance personnel.

  • Page 11: Chapter 5 Use

    Avoid bends if necessary and be careful on small hills, thresholds, etc. Reduce speed in case of sharp bends. The Multi-Mover L may only be driven at speeds that allow you to stop in time, e.g. if an obstacle is standing in or entering the driving area.
  • Page 12 Only transport safe and stable loads. Make sure the weight of the load to be moved lies within the capacity of the Multi-Mover L. The maximum traction force is stated on the type plate.

  • Page 13: Operation

    Counter weight plates 20 kg, 1 to 5 (#) Engine caste Grip electromagnetic brake 10 Ignition lock 11 Swivel wheel, Castor (#) 12 Emergency stop switch 13 BDI Battery indicator/hours counter (#) 14 Charger plug 24V 15 Type plate (#) Option MULTI-MOVER L25S...
  • Page 14 EM brake grip (9) The wheels (4) are coupled to/disconnected from the motor by means of the handbrake button. If the button is pulled out it is in the free position, the Multi-Mover L can now be freely manoeuvred by hand.

  • Page 15: Batteries

    For a longer life span, it is better not to allow the battery to get completely empty. It is also not good to continue charging a battery that is almost full. If the Multi-Mover L is out of operation (for a longer period), we recommend keeping the battery charger connected, it will automatically keep the battery in a charged condition.
  • Page 16 The temperature of the batteries will increase, resulting in premature wear. Also, the voltage of the battery will become higher than the actual energy condi- tion, which means that the discharge limiter will no longer work correctly. Ambient temperature MULTI-MOVER L25S...

  • Page 17: Coupling Trailer(S)

    5.5 Coupling trailer(s) The Multi-Mover L is made with a standard tow eye with tow pin or a ball coupling point in the middle of the Multi-Mover L, to which the pole of a trailer can be coupled.

  • Page 18: Chapter 6 Maintenance

    Only use the Multi-Mover L if you have thoroughly studied the previous pages and you have no more questions. MAINTENANCE When performing maintenance, you should always observe the safety regulations, (chapter 3).

  • Page 19: Annual Maintenance

    Multi-Mover L on blocks, so that the tyres do not touch the ground Have maintenance and repairs performed by persons authorized by Multi-Mover Europe BV. In case of doubt, always consult your supplier. For the above-mentioned maintenance instructions, we assumed normal use.

  • Page 20: Chapter 7 Environment

    Consequences for the environment Life span The expected life span of the Multi-Mover L depend on maintenance, operating hours and ambient conditions (dust, contamination, humidity etc.). Good maintenance will be beneficial to the life span.

  • Page 21: Chapter 8 Failures

    FAILURES When removing a failure, ALWAYS switch off the Multi-Mover L and remove the ignition key. If a defect is established at the Multi-Mover L, do not use it until the repair has been completed. Failure Solution The Multi-Mover L does not drive.

  • Page 22: Chapter 10 Declaration Of Conformity

    We, Multi-Mover Europe BV, Boomsestraat 38, 6613 AH Balgoij, Netherlands declare at our own full responsibility, that the Multi-Mover MML25S with serial number MM L25S…. From 2020 to which this declaration applies, is in conformity with the provisions of the following directive(s):...
