Rimage Prism Specifications

Prism Printer Specifications

Item
Printing Speed
Printing Direction
Printing Modes
Print Quality
Media Types
Standard Ribbon Color
Multi-Color Ribbon
Ribbon Capacity
Physical Properties
Interface
Power
Operating Temperature
Relative Humidity
System Requirements
5/17/2007
Description
0.65 inches/second @ 300 x 300 dpi, typical
0.45 inches/second @ 300 x 600 dpi, typical
Images are printed from a top to bottom orientation as the media is moving out of
the machine.
Single-pass (standard) and double-pass (monocolor ribbon only) for improved print
quality on some media types.
300x300 or 300x600 dpi (11.8 dots per mm)
120mm CD and DVD media with thermal protective layers
Black, Red, and Blue monocolor ribbons
3-color (CMY) panel ribbon
Monochrome black = 2100 discs
Monochrome red = 2100 discs
Monochrome blue = 2100 discs
3-color panel = 500 discs
6.0" H x 8.5" W x 14.0" D
(15.24 cm x 21.59 cm x 35.56 cm)
18 pounds (8.2 kg)
USB 1.0, Parallel, Serial (USB supported with Windows 2000 Professional with SP4;
Windows XP Professional with SP2 or higher; Windows Server 2003)
100-240 VAC, 50-60 Hz, 1.10–0.55 Amps auto ranging
60° F to 90° F (15.5° C to 35° C)
30% to 80% non-condensing
Pentium 450 (1 GHz or higher recommended).
256 MB RAM (512 MB or higher recommended)
Windows 2000 Professional with SP4; Windows XP Professional with SP2 or higher,
or Server 2003
1
