5.23 Parameter clear/ All parameter clear

POINT
Set "1" in Pr.CL Parameter clear, ALLC all parameter clear to initialize all parameters. (Parameters are not cleared
when "1" is set in Pr. 77Parameter write selection.)
Refer to the extended parameter list on page 84 for parameters cleared with this operation.
Operation
1.
Screen at power-ON
The inverter starts up in Network operation
mode.
The monitor display appears.
2.
Press to choose the PU operation mode.
3.
Press to choose the parameter setting
mode.
4.
Turn until
5.
Press to read the currently set value.
" "(initial value) appears.
6.
Turn to change it to the set value "
7.
Press to set.
Turn
Press
Press
Setting
0 Not executed.
Set parameters back to the initial values. (Parameter clear sets back all parameters except
1 terminal function selection parameters to the initial values.) Refer to the parameter list on page 84 for
availability of parameter clear and all parameter clear.
REMARKS
and
The inverter is not in the PU operation mode.
USB connector is used.
1. Press . [PU] is lit and the monitor (4-digit LED) displays "1". (When Pr. 79 = "0" (initial value))
2. Carry out operation from step 6 again.
( ) appears.
".
Flicker ··· Parameter setting complete!!
to read another parameter.
to show the setting again.
twice to show the next parameter.
Description
are displayed alternately ... Why?
Parameter clear/ All parameter clear
Display
PU indicator is lit.
PRM indicator is lit.
(The parameter number read previously appears.)
Parameter clear
All parameter clear
Parameter clear
All parameter clear
