OPERATORS MANUAL
This manual provides
Installation & Operating instructions for
PIZZA HUT
MAKETABLE
For Models:
PH120E2
NOTIFY CARRIER OF DAMAGE AT ONCE.
It is the responsibility of the consignee to inspect the
container upon receipt of same and to determine
the possibility of any damage, including concealed
damage. Randell suggests that if you are suspicious
of damage to make a notation on the delivery re-
ceipt. It will be the responsibility of the consignee to
file a claim with the carrier. We recommend that you
do so at once.
Manufacture Service/Questions 888-994-7636.
Information contained in this document is known to be
current and accurate at the time of printing/creation.
Unified Brands recommends referencing our product line
websites, unifiedbrands.net, for the most updated product
information and specifications.
P/N OMANUAL_MNL0504-05/05
1055 Mendell Davis Drive
Jackson, MS 39272
888-994-7636, fax 888-864-7636
randell.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Randell PH120E2-220
Summary of Contents for Randell PH120E2-220
- Page 1 Randell suggests that if you are suspicious of damage to make a notation on the delivery re- ceipt. It will be the responsibility of the consignee to file a claim with the carrier.
- Page 3 15………………………………………..Electrical Diagram page 16……………………………………..……Troubleshooting page 17-20…………………………….……..Replacement Parts Congratulations on your recent purchase of Randell food service equipment, and welcome to the growing family of satisfied Randell customers. Our reputation for superior products is the result of consistent quality craftsmanship. From the earliest stages of product design to successive steps in fabrication and assembly, rigid standards of excellence are maintained by out staff of designers, engineers, and skilled employees.
- Page 5 In addition, all Randell food service equipment is backed by some of the best warranties in the food service industry and by our professional staff of service technicians. Retain this manual for future reference. NOTICE: Due to a continuous program of product improvement, Randell Manufacturing reserves the right to make changes in design and specifications without prior notice.
-
Page 6: Warranty Policies
Warranty Policies Congratulations on your purchase of a Randell Manufactured piece of equipment. Randell believes strongly in the products it builds and backs them with the best warranty in the industry. Standard with every unit comes the peace of mind that this unit has been thoroughly engineered, properly tested and manufactured to excruciating tolerances, by a manufacturer with over 25 years of industry presence. - Page 7 2. Provide repair at the manufacturing facility by requiring that the defective unit be sent back to Randell freight prepaid. Perform repair at the expense of Randell and ship the item back to the customer freight collect. 3. Furnish complete condensing unit freight collect in exchange for the return of the defective compressor sent back freight prepaid.
- Page 8 Randell recommends thorough cleaning of gaskets on a weekly basis with a mild dish soap and warm water. With proper care Randell gaskets can last up to two years, at which time we recommend replacement of all gaskets on the equipment for the best possible performance.
-
Page 9: Returned Goods
(www.doriandrake.com), Randell’s export management organization. *FOOTNOTES IN REFERENCE TO PARAGRAPHS ABOVE 1. Herein called Randell. 2. NET means list price less discount, warranty, labor policy, freight, Randell delivery and other miscellaneous charges. CASH DISCOUNTS WILL BE CALCULATED ON NET ONLY. -
Page 10: Unit Specifications
Model PH120E2 120" 40"* 57"** PH120E2-220 120” 40”* 57”** * 33” with work surface removed. ** Overall dimension to top of hood. Optional Ticket Rail adds approximately 17” to height. 800-621-8560 Unit Specifications Work Doors H.P. Voltage Amps Hgt. 35"... -
Page 11: Unit Installation
Adjusting bullet feet heights or shimming casters may be necessary if the floor is not level. followed. Randell is not responsible for damage to equipment if improperly installed. 4. Plug in unit and turn on main on/off power switch. 5. Allow unit time to cool down to temperature. - Page 12 NOTE: FAILURE FOLLOW INSTALLATION GUIDELINES RECOMMENDATIONS MAY VOID THE WARRANTY ON YOUR UNIT. ELECTRICAL SUPPLY: The wiring should be done by a qualified electrician in accordance with local electrical codes. A properly wired and grounded outlet will assure proper operation. Please consult the data tag attached to the compressor to ascertain the correct electrical requirements.
-
Page 13: Unit Operation
3. Rail cleaning may be performed at this time if the frost has melted off the rail surface. Randell has attempted to preset the cold controls to ensure that your unit runs at an optimum temperature, but due to varying ambient conditions, including elevation, food product as well as type of operation, you may need to alter this temperature. - Page 14 To raise temperature in the refrigerated rail: A. Push and hold the “set” button until 34 appears then release the “set” button. 34 is the current set point temperature. B. Push and release the up arrow 2 times until 36 is displayed. Push and release the “set”...
-
Page 15: Preventive Maintenance
Randell strongly suggests a preventive maintenance program which would include the following Monthly procedures: 1. Cleaning of all condenser coils. Condenser coils are a critical component in the life of the compressor and must remain clean to assure proper air flow and heat transfer. - Page 16 These services often offer guarantees as well as the flexibility in scheduling or maintenance for your convenience. Randell believes strongly in the products it manufactures and backs those products with one of the best warranties in the industry. We believe with the proper maintenance and use, you will realize a profitable return on your investment and years of satisfied service.
-
Page 17: Electrical Diagram
Electrical Diagram difoodservice.com... -
Page 18: Troubleshooting Guide
SYMPTOM POSSIBLE CAUSE Unit doesn't run 1. No power to unit 2. Temperature control turned off 3. Temperature control faulty 4. Compressor overheated 5. Condenser fan faulty 6. Overload protector faulty 7. Compressor relay faulty 8. Compressor faulty Unit short cycles 1. - Page 19 Pizza Hut Maketable Replacement PH120E2 Parts List difoodservice.com...
- Page 20 800-621-8560...
-
Page 21: Item Description
ITEM DESCRIPTION Hood Only Lid for Rail Hood, 38” x 13 _” Removable Nosing and Work Surface Door with handle, right hinged 23 _” x 24 _” Door with handle, left hinged 23 _” x 24 _” Door Handle, 10" x 2” Caster, 6”... - Page 22 Ball Valve, 1 1/2” PVC Female Pipe, 1 1/2” PVC Elbow, 1 1/2” PVC Fem x Glue Fan Register, Middle Fan Shroud, Rail Fan Mounting Bracket for Base Coil Assembly Mounting Support for Base Coil Assembly Evaporator Fan Motor Dial Temperature Control for Base Plastic Bottom for Base Coil Assembly Box Refrigeration Valve for Base Coil Assembly Evaporator Coil Assembly...
