OPERATOR'S MANUAL
This manual provides information on
installation, operating, maintenance,
trouble shooting & replacement parts for
PH120E2/PH120E2.1
NOTIFY CARIER OF DAMAGE AT ONCE.
It is the responsibility of the consignee to inspect the
container upon receipt of same and to determine the
possibility of any damage, including concealed
damage. Randell suggests that if you are suspicious
of damage to make a notation on the delivery receipt.
It will be the responsibility of the consignee to file a
claim with the carrier. We recommend that you do so
at once.
1/29/2008
PP MNL0504 rev B
Advertisement
Table of Contents
Related Manuals for Randell PH120E2
Summary of Contents for Randell PH120E2
- Page 1 Randell suggests that if you are suspicious of damage to make a notation on the delivery receipt. It will be the responsibility of the consignee to file a claim with the carrier.
- Page 2 17-19………………..……..PH120E2 Exploded Drawings page 20-23…………………….PH120E2.1 Exploded Drawings page 24-25………………………………Repalcement Parts List Congratulations on your recent purchase of Randell food service equipment, and welcome to the growing family of satisfied Randell customers. Our reputation for superior products is the result of consistent quality craftsmanship.
-
Page 3: Installation Date
In addition, all Randell food service equipment is backed by some of the best warranties in the food service industry and by our professional staff of service technicians. Retain this manual for future reference. NOTICE: Due to a continuous program of product improvement, Randell reserves the right to make changes in design and specifications without prior notice. -
Page 4: Warranty Policies
Any warranty work performed by a non-ASA will not be honored by Randell. Please consult Randell Technical Support for a complete listing of ASAs. A complete listing of ASAs may also be found on the Randell page of our web site at www.unifiedbrands.net... - Page 5 2. Provide repair at the manufacturing facility by requiring that the defective unit be sent back to Randell freight prepaid. Perform repair at the expense of Randell and ship the item back to the customer freight collect. 3. Furnish complete condensing unit freight collect in exchange for the return of the defective compressor sent back freight prepaid.
- Page 6 With proper care Randell gaskets can last up to two years, at which time we recommend replacement of all gaskets on the equipment for the best possible performance. NOTICE: FOOD LOSS IS NOT COVERED UNDER WARRANTY 3.
-
Page 7: Returned Goods
(www.doriandrake.com), Randell’s export management organization. *FOOTNOTES IN REFERENCE TO PARAGRAPHS ABOVE 1. Herein called Randell. 2. NET means list price less discount, warranty, labor policy, freight, Randell delivery and other miscellaneous charges. CASH DISCOUNTS WILL BE CALCULATED ON NET ONLY. -
Page 8: Unit Specifications
Model PH120E2 120" 40"* 57"** PH120E2-220 120” 40”* 57”** PH120E2.1 120” 40”* 57”** PH120E2.1-220 120” 40”* 57”** * 33” with work surface removed. ** Overall dimension to top of hood. Optional Ticket Rail adds approximately 17” to height. 8 8 8 8... -
Page 9: Unit Installation
Floor Load: The area on which the unit will rest must be level, free of vibration, and suitably strong enough to support the combined weights of the unit plus the maximum product load weight (PH120E2.1 max floor load = 1870 lbs.). - Page 10 Unit Installation (cont.) ELECTRICAL SUPPLY: The wiring should be done by a qualified electrician in accordance with local electrical codes. A properly wired and grounded outlet will assure proper operation. Please consult the data tag attached to the compressor to ascertain the correct electrical requirements. Supply voltage and amperage requirements are located on the serial number tag located inside the mechanical housing.
-
Page 11: Unit Operation
3. Rail cleaning may be performed at this time. Randell has attempted to preset the cold controls to ensure that your unit runs at an optimum temperature, but due to varying ambient conditions, including elevation, food product as well as type of operation, you may need to alter this temperature. - Page 12 To raise temperature in the refrigerated rail: A. Push and hold the “set” button until 34 appears then release the “set” button. 34 is the current set point temperature. B. Push and release the up arrow 2 times until 36 is displayed. Push and release the “set”...
-
Page 13: Preventive Maintenance
Preventive Maintenance Randell strongly suggests a preventive maintenance program which would include the following Monthly procedures: 1. Cleaning of all condenser coils. Condenser coils are a critical component in the life of the compressor and must remain clean to assure proper air flow and heat transfer. -
Page 14: Cleaning Agent
These services often offer guarantees as well as the flexibility in scheduling or maintenance for your convenience. Randell believes strongly in the products it manufactures and backs those products with one of the best warranties in the industry. We believe with the proper maintenance and use, you will realize a profitable return on your investment and years of satisfied service. -
Page 15: Electrical Diagram
Electrical Diagram unifiedbrands.net... -
Page 16: Troubleshooting Guide
SYMPTOM POSSIBLE CAUSE Unit doesn't run 1. No power to unit 2. Temperature control turned off 3. Temperature control faulty 4. Compressor overheated 5. Condenser fan faulty 6. Overload protector faulty 7. Compressor relay faulty 8. Compressor faulty Unit short cycles 1. - Page 17 Pizza Hut Maketable Replacement Parts unifiedbrands.net...
- Page 18 Pizza Hut Maketable Replacement Parts 800-621-8560...
- Page 19 Pizza Hut Maketable Replacement Parts unifiedbrands.net...
- Page 20 Pizza Hut Maketable Replacement Parts Unit Exterior 800-621-8560...
- Page 21 Pizza Hut Maketable Replacement Parts Refrigerated Rail Top Section unifiedbrands.net...
- Page 22 Pizza Hut Maketable Replacement Parts Refrigerated Rail Condensing Unit 800-621-8560...
- Page 23 Pizza Hut Maketable Replacement Parts Coil Assembly unifiedbrands.net...
-
Page 24: Replacement Parts List
Door Hinge Bushing Shelf Holding Pin Wire Shelf, 19 1/8” x 25 ¼” Bracket for shelf support Fan Register, Back Fan Register, Back, One Piece (PH120E2.1 only) Evaporator Coil, 53"x4"x1" Drain Screen, 2” Evaporator Fan Motor, Rail Fan Mounting Box... - Page 25 Refrigeration Valve for Base Coil Assembly Evaporator Coil Assembly Evaporator Coil Solenoid Valve for Base / Rail Shield Panel for Base Coil Assembly Evap coil housing - rear panel Evap coil housing – front panel Compressor Condensing Unit Pressure Control Dixell Temperature Control for Rail Sensing Probes for Dixell Control Magnet Striker Plate...
