OPERATOR'S MANUAL
This manual provides information on
installation, operating, maintenance,
trouble shooting & replacement parts for
FULL VIEW DROP-IN
REFRIGERATED
DISPLAY CASE
44250DIMA
44262DIMA
44274DIMA
44250DIPA
44262DIPA
44274DIPA
44250DISA
44262DISA
44274DISA
NOTIFY CARIER OF DAMAGE AT ONCE.
It is the responsibility of the consignee to inspect the
container upon receipt of same and to determine the
possibility of any damage, including concealed
damage. Randell suggests that if you are suspicious
of damage to make a notation on the delivery receipt.
It will be the responsibility of the consignee to file a
claim with the carrier. We recommend that you do so
at once.
Information contained in this document is known to
be current and accurate at the time of printing/
creation. Unified Brands recommends referencing
our product line websites, unifiedbrands.net, for the
most
updated
product
information
and
specifications.
1055 Mendell Davis Drive, Jackson MS 39272
888-994-7636 • Fax 888-864-7636 • randell.com
10/30/2006
PP MNL0603
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Randell 44250DIMA
Summary of Contents for Randell 44250DIMA
- Page 1 Randell suggests that if you are suspicious of damage to make a notation on the delivery receipt. It will be the responsibility of the consignee to file a claim with the carrier.
-
Page 2: Table Of Contents
12-13……………………..………Preventive Maintenance page 14-15..………………………………..……Troubleshooting page 16-17…………………………….……..Replacement Parts Congratulations on your recent purchase of Randell food service equipment, and welcome to the growing family of satisfied Randell customers. Our reputation for superior products is the result of consistent quality craftsmanship. From the earliest stages of product design to successive steps in fabrication and assembly, rigid standards of excellence are maintained by out staff of designers, engineers, and skilled employees. -
Page 3: Serial Number Location
In addition, all Randell food service equipment is backed by some of the best warranties in the food service industry and by our professional staff of service technicians. Retain this manual for future reference. NOTICE: Due to a continuous program of product improvement, Randell reserves the right to make changes in design and specifications without prior notice. -
Page 4: Warranty Policies
LABOR COVERAGE In the unlikely event a Randell unit fails due to defects in materials or workmanship within the first ninety days, Randell agrees to pay the contracted labor rate performed by an Authorized Service Agent (ASA). - Page 5 2. Provide repair at the manufacturing facility by requiring that the defective unit be sent back to Randell freight prepaid. Perform repair at the expense of Randell and ship the item back to the customer freight collect. 3. Furnish complete condensing unit freight collect in exchange for the return of the defective compressor sent back freight prepaid.
-
Page 6: Returned Goods
Randell requires all equipment to be professionally installed. *FOOTNOTES IN REFERENCE TO PARAGRAPHS ABOVE 1. Herein called Randell. 2. NET means list price less discount, warranty, labor policy, freight, Randell delivery and other miscellaneous charges. CASH DISCOUNTS WILL BE CALCULATED ON NET ONLY. -
Page 7: Unit Specifications
25.25” 44”* 44274DISA 74" 25.25" 44"* * 44” is the height of the unit above counter top. Overall height including the compressor housing is 62”. Unit Specifications 44250DIMA shown Capacity Style Cu. Ft. Single Service, 20.1 Mirrored Back Single Service, 25.5... -
Page 8: Installation Checklist
SELECTING A LOCATION FOR YOUR NEW UNIT The following conditions should be considered when selecting a location for your unit: Floor and Countertop Load: The area on which the unit will rest must be level, free of vibration, and suitably strong enough to support the combined weights of the unit plus the maximum product load weight. - Page 9 NOTE: it is important that your unit has its own dedicated line. Condensing units are designed to operate with a voltage fluctuation of plus or minus 10% of the voltage indicated on the unit data tag. Burn out of a condensing unit due to exceeding voltage limits will void the warranty. randell.com...
-
Page 10: Electrical Diagrams
Electrical Diagram 800-621-8560... -
Page 11: Unit Operation
Randell has attempted to preset the cold controls to ensure that your unit runs at an optimum temperature, but due to varying ambient conditions, including elevation, food product as well as type of operation, you may need to alter this temperature. -
Page 12: Preventive Maintenance
Randell strongly suggests a preventive maintenance program which would include the following Monthly procedures: 1. Cleaning of all condenser coils. Condenser coils are a critical component in the life of the compressor and must remain clean to assure proper air flow and heat transfer. - Page 13 These services often offer guarantees as well as the flexibility in scheduling or maintenance for your convenience. Randell believes strongly in the products it manufactures and backs those products with one of the best warranties in the industry. We believe with the proper maintenance and use, you will realize a profitable return on your investment and years of satisfied service.
-
Page 14: Troubleshooting Guide
SYMPTOM POSSIBLE CAUSE Unit doesn't run 1. No power to unit 2. Temperature control turned off 3. Temperature control faulty 4. Compressor overheated 5. Condenser fan faulty 6. Overload protector faulty 7. Compressor relay faulty 8. Defrost timer faulty 9. Compressor faulty Unit short cycles 1. - Page 15 3. Raise temperature setting 1. Clean drain 2. Adjust leveling leg/shim casters 1. Adjust leveling leg/shim casters 2. Tighten or replace compressor mountings 3. Inspect condenser fan 4. Inspect evaporator fan 5. Bend or align tabs to reduce noise. Replace if necessary. randell.com...
- Page 16 44000 Series Replacement Full View Drop-In Display Case Parts 800-621-8560...
- Page 17 Blade, Evaporator Fan Mounting Ring & Guard Pan, Evaporator Drip Pan Condensing Unit, 3/8 HP Tecumseh, R-134A Condensing Unit, 1/2 HP Copeland, R-134A Compressor, AEA4448YXA Compressor, ART62C1E-IAA-901 Switch, ON/OFF 44250DIMA 44262DIMA PART # 44250DIPA 44262DIPA 44250DISA 44262DISA HD DOR058L HD DOR062L...
