Page 2: Table Of Contents
TABLE OF CONTENTS Before You Assemble ....3 Product Specifications ....4 Product Features ......4 Parts List / Box Contents ..... 5 Exploded View ....... 6 Hardware and Tool List ....7 Assembly Guide ......8 Warranty Information ....15 Important Contact Numbers .. -
Page 3: Before You Assemble
BEFOrE YOu ASSEmBLE BaSic aSSeMBly PriNciPleS Here are a few basic tips that will aid in the assembly of the Nautilus® NS75X. By using these principles, you can simplify each process and save yourself extra time and effort. 1. To make the assembly process go faster, gather the pieces you need for each step and thoroughly read the assembly instructions for that step prior to starting assembly for the step. -
Page 4: Product Specifications
PrOduCT SPECIFICATIONS NOTE: All instructions in the manual are given with the orientation of sitting on the machine ready to exercise. 300lbs / 136.1Kg user Weight Capacity: dimensions: 56”w x 76”l x 46”h / 142 cm x 193 cm x 117 cm Shipping Weight: 207 lbs / 93.9 kg Net Weight:... -
Page 5: Parts List / Box Contents
39 1” x 1/2” Flat Washer ......6 40 3/8” Flat Washer ....... 60 41 Shim Washer ........1 42 1/2” Lock Nut ........3 43 3/8” Lock Nut ........30 44 Step Spacer - 5/8”H ......8 Nautilus NS75X... -
Page 6: Exploded View
ExPLOdEd VIEW • Compare the Bill of Materials to the box contents to insure that all parts are present before installation begins. -
Page 7: Hardware And Tool List
HArdWArE ANd TOOLS NS-75 Nautilus NS75X... -
Page 8: Assembly Guide
NS75X Leg Press attachment can be assembled in a right or left configuration for use on the NS300X ,NS200X, NS600X and NS700X. You may also mount the Ab Crunch arm on either side to most efficiently use space. - Page 9 B. If using a NS200X,NS300X or NS600X attach the Vertical Pulley Hex Bolt - 3/8” x 3”L Bracket (5) to the connecting Tube Assembly (2) using the hardware 3/8” Flat Washer shown above. 3/8” Lock Nut c. Tighten all hardware securely. Hex Bolt - 3/8” x 3 1/2”L Nautilus NS75X...
- Page 10 ASSEmBLY STEP 2 3/8" x 3 1/4"L 3/8" x 2 3/4"L 3/8" x 3 1/4"L 3/8" x 3"L 3/8" x 3"L Step 2 Components: Procedure: component a. Position the Seat Back Support Assembly (16) over the rear holes of the Main Base Assembly (1) and position Main Base Assembly next to the Connecting Tube Assembly (2).
- Page 11 Button Head Screw - F. Attach the Foot Plate Assembly (9) to the Leg Press Top 3/8” x 3/4”L w/ Thread Lock Link (8) using the hardware shown above. 1/2” Flat Washer G. Tighten all hardware securely. 1/2” lock Nut Nautilus NS75X...
- Page 12 ASSEmBLY STEP 4 3/8" x 3"L 1/2" x 7"L 3/8" x 3"L 3/8" x 3"L Procedure: Step 4 Components: a. Attach the Angled Pulley Bracket (7) to the Connecting component Tube Assembly using the hardware shown above. Angled Pulley Bracket B.
- Page 13 Back Adjuster in to the Seat Back Support Assembly and Seat Back Pad secure with the Pop Pin. Hex Bolt - 3/8” x 1”L c. Attach the Seat Pad (23) to the Seat Tube Assembly 3/8” Flat Washer using the hardware shown. Nautilus NS75X...
- Page 14 ASSEmBLY STEP 6 3/8" x 1"L 3/8" x 2"L 3/8" x 2 3/4"L NOT USED ON THE NS700X 3/8" x 2 3/4"L 3/8" x 2"L 3/8" x 2"L Procedure: Step 6 Components: a. Attach the looped end of the Leg Press Cable (25) to the cable bracket component located on the Seat Back Support Assembly using the hardware Leg Press Cable w/ Termination 1...
