Physical Specifications - Quantum Scalar i2000 User Manual

Customer Library
Connection Types and
Speeds
Table 6 Library Connections
Types and Speeds
a
Connection
Fibre Channel on FC I/O Blade
Fibre Channel on management control blade
Ethernet on management control blade
SCSI-2 on management control blade
a.The DB-9 serial connection on the management control blade is not intended for customer use.

Physical Specifications

Scalar i2000 Planning Guide
Table 6 lists the library connection types and speeds.
3
This section contains the physical specifications for the library modules.
If the library is installed on a raised floor, the raised floor should be
stabilized to prevent any horizontal movement. The library has four point
loads each on the control and expansion modules. See
Note
Connector
LC
LC
RJ45
68-pin VHDCI
The Scalar i2000 control module-only weight is
approximately 600 lbs. This is the weight of a control
module without packaging or media.
Chapter 3 System Specifications
Physical Specifications
Speed
2 gigabit/sec (6404)
4 gigabit/sec (7404)
1 gigabit/sec
10/100 Base-T
Ultra-2 SCSI
table 7 on page 36.
35
