Multi-Purpose Mobile Podium
Instruction Manual
SKU: CART-V03E/W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/cart-v03e
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo CART-V03E/W
Summary of Contents for Vivo CART-V03E/W
- Page 1 Multi-Purpose Mobile Podium Instruction Manual SKU: CART-V03E/W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/cart-v03e GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 44 lbs 22 lbs Failure to do so may result in serious injury. (20 kg) (10kg) Phillips TOP SHELF BOTTOM SHELF Screwdriver ASSEMBLY STEPS STEP 1 Attach Casters (C) to Short and Long Square Tubes (A, B) using the provided Wrench (T-D). - Page 4 STEP 4 After making sure the poles are at the same height, insert Plastic Knobs (J) into the back of the Pole Set (G) to set the height of the Inner Poles. STEP 5 Slide Tube Connector Cover (E) over Pole Set (G). Attach Pole Set (G) to Tube Connector (D) using M6x10mm Screws (S-C) and 4mm Allen Wrench (T-B) in the back, and M5x6mm Set Screws (S-E) and 2mm Allen Wrench (T-A) in the sides.
- Page 5 STEP 7 Attach Shelf Supports (K) to Pole Set (G) using M6x10 Screws (S-C) and 4mm Allen Wrench (T-B). STEP 8 Attach the Shelf (L) to Shelf Supports (K) using M4x6mm Screws (S-D). Tighten with a Phillips screwdriver. STEP 9 Mount the Right and Left Connecting Plates (N, O) to the Top Plate (M) using M6 Nuts (S-A) and tighten with the provided Wrench (T-D).
- Page 6 STEP 10 Place the assembled top plate onto Pole Set (G), and secure with M6x10mm Screws (S-C) and 4mm Allen Wrench (T-B). STEP 11 Insert Levers (P) with M6 Washers (S-F) through the slots in Connecting Plates (N, O) and screw into Pole Set (G).
- Page 7 STEP 13 Loosen Levers (P) to adjust the tilt angle, then tighten in the desired position. Adjust the height by loosening Plastic Knobs (J), then tighten at the desired height. tilt 40˚ STEP 14...
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
