- Page 1 4K@60Hz 50m KVM Extender with USB 2.0 4KEX50-KVM User Manual...
- Page 2 Introduction Introduction Overview This product is a 50m HDMI 2.0 KVM extender kit. The kit supports visual lossless compression function, and it can transmit HDMI signal up to 4K@60Hz 4:4:4 8bit via a single Cat 5e or above cable. With one USB Host port in transmitter and four USB 2.0 Device ports in receiver, the kit also supports KVM Control.
- Page 3 Installation and Application Name Description On: HDMI data is being transmitted. Status LED Off: No signal. On: UTP link is normal. Link LED Off: No UTP link or link error. USB Host Connect to a host PC. Reserved. With one-way PoC supported, one power adapter is needed to be connected to the receiver to power both units.
- Page 4 Installation and Application Attach the brackets to the surface you want to hold the unit against using the screws (provided by others). Application HDMI In USB Host Transmitter Cat 5e or above Receiver Power Supply HDMI Audio Devices Camera AV Receiver Display Keyboard &...
- Page 5 Specifications connected to the receiver to power both units. USB devices connected with the receiver can be connected to the USB host PC connected with the transmitter. The two USB 2.0 ports supports 1A can be connected to high-power USB ...
- Page 6 The warranty has expired. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide.
