Sony XM-5040X Service Manual page 9

Ref. No. Part No. Description
C924 1-126-960-11 ELECT
C925 1-126-933-11 ELECT
C926 1-126-933-11 ELECT
C927 1-126-956-11 ELECT
C928 1-164-088-11 CERAMIC
C929 1-164-088-11 CERAMIC
C930 1-164-088-11 CERAMIC
C931 1-164-088-11 CERAMIC
C932 1-104-664-11 ELECT
C933 1-107-715-11 ELECT
C949 1-163-275-11 CERAMIC CHIP
C951 1-126-933-11 ELECT
C953 1-164-004-11 CERAMIC CHIP
C954 1-164-004-11 CERAMIC CHIP
C955 1-111-044-11 ELECT
C990 1-164-004-11 CERAMIC CHIP
< TERMINAL >
CN901 1-537-477-31 TERMINAL BOARD (3P) (REMOTE,+12V,GND)
CN902 1-537-478-31 TERMINAL BOARD (4P)
CN903 1-537-478-31 TERMINAL BOARD (4P) (SPEAKER OUT (REAR))
* CN904 1-691-785-11 PIN, CONNECTOR (PC BOARD) 4P
CN905 1-691-785-21 PIN, CONNECTOR (PC BOARD) 4P
< JACK >
CNJ901 1-779-078-41 JACK, PIN 4P (INPUT)
< CONNECTOR >
CNP902 1-766-929-11 CONNECTOR, BOARD TO BOARD 8P
CNP903 1-766-801-11 CONNECTOR, BOARD TO BOARD 5P
CNP904 1-766-801-11 CONNECTOR, BOARD TO BOARD 5P
CNP905 1-766-929-11 CONNECTOR, BOARD TO BOARD 8P
< DIODE >
D101 8-719-991-33 DIODE 1SS133T-77
D102 8-719-991-33 DIODE 1SS133T-77
D201 8-719-991-33 DIODE 1SS133T-77
D202 8-719-991-33 DIODE 1SS133T-77
D301 8-719-991-33 DIODE 1SS133T-77
D302 8-719-991-33 DIODE 1SS133T-77
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-991-33 DIODE 1SS133T-77
D901 8-719-110-48 DIODE MTZJ-T-72-18A
D902 8-719-109-97 DIODE MTZJ-T-72-6.8C
D903 8-719-820-04 DIODE 1SS184-TE85L
D904 8-719-820-04 DIODE 1SS184-TE85L
D905 8-719-054-55 DIODE 1SS306(TE85L)
D906 8-719-023-35 DIODE FMG-32S
D907 8-719-054-55 DIODE 1SS306(TE85L)
D908 8-719-023-34 DIODE FMG-32R
Remark Ref. No.
1uF 20% 50V D909
100uF 20% 16V D910
100uF 20% 16V D911
0.1uF 20% 50V D912
0.001uF 50V D913
0.001uF 50V D914
0.001uF 50V D915
0.001uF 50V D916
47uF 20% 10V D930
22uF 20% 16V
0.001uF 5% 50V
100uF 20% 16V IC101
0.1uF 10% 25V IC301
0.1uF 10% 25V IC901
2200uF 20% 16V IC902
0.1uF 10% 25V
JR1
JR2
JR3
JR4
(SPEAKER OUT (FRONT)) JR5
JR6
(HIGH LEVEL INPUT (FRONT)) JR7
JR8
(HIGH LEVEL INPUT (REAR)) JR9
JR10
JR11
JR12
JR13
JR14
JR15
JR16
JR17
JR18
JR19
JR20
JR21
JR22
JR23
JR24
JR25
JR26
JR27
JR28
JR29
JR30
JR31
JR32
JR33
JR34
JR35
JR36
Part No. Description
8-719-820-04 DIODE 1SS184-TE85L
8-719-933-36 DIODE HZS6B1LT2
8-719-991-33 DIODE 1SS133T-77
8-719-820-04 DIODE 1SS184-TE85L
8-719-934-91 DIODE HZS16-1LT2
8-719-934-91 DIODE HZS16-1LT2
8-719-820-04 DIODE 1SS184-TE85L
8-719-109-97 DIODE MTZJ-T-72-6.8C
8-719-820-04 DIODE 1SS184-TE85L
< IC >
8-759-711-85 IC NJM4580E-D-TE2
8-759-711-85 IC NJM4580E-D-TE2
8-719-156-73 PHOTO COUPLER PS2501-1-L
8-759-144-88 IC uPC494GS-T1
< JUMPER RESISTOR >
1-216-296-00 SHORT 0
1-216-296-00 SHORT 0
1-216-296-00 SHORT 0
1-216-296-00 SHORT 0
1-216-296-00 SHORT 0
1-216-295-00 SHORT 0
1-216-296-00 SHORT 0
1-216-295-00 SHORT 0
1-216-296-00 SHORT 0
1-216-296-00 SHORT 0
1-216-295-00 SHORT 0
1-216-295-00 SHORT 0
1-216-296-00 SHORT 0
1-216-296-00 SHORT 0
1-216-296-00 SHORT 0
1-216-295-00 SHORT 0
1-216-296-00 SHORT 0
1-216-295-00 SHORT 0
1-216-295-00 SHORT 0
1-216-296-00 SHORT 0
1-216-295-00 SHORT 0
1-216-295-00 SHORT 0
1-216-295-00 SHORT 0
1-216-295-00 SHORT 0
1-216-295-00 SHORT 0
1-216-296-00 SHORT 0
1-216-296-00 SHORT 0
1-216-295-00 SHORT 0
1-216-295-00 SHORT 0
1-216-295-00 SHORT 0
1-216-295-00 SHORT 0
1-216-295-00 SHORT 0
1-216-295-00 SHORT 0
1-216-295-00 SHORT 0
1-216-295-00 SHORT 0
1-216-295-00 SHORT 0
AMPLIFIER
