Sony XM-5040X Service Manual page 10

AMPLIFIER
Ref. No. Part No. Description
JR37 1-216-296-00 SHORT
JR38 1-216-296-00 SHORT
JR39 1-216-295-00 SHORT
JR40 1-216-296-00 SHORT
JR41 1-216-295-00 SHORT
JR42 1-216-296-00 SHORT
JR43 1-216-296-00 SHORT
< COIL >
L901 1-416-322-11 COIL, CHOKE
L902 1-410-397-21 FERRITE BEAD INDUCTOR 1.1uH
< PILOT LAMP >
PL901 1-518-540-11 LAMP, PILOT
< TRANSISTOR >
Q102 8-729-014-85 TRANSISTOR 2SA1618-YGRTE85R
Q103 8-729-014-87 TRANSISTOR 2SC4207-YGRTE85R
Q104 8-729-140-82 TRANSISTOR 2SA988TP-FA
Q105 8-729-184-53 TRANSISTOR 2SC1841TP-FA
Q106 1-809-603-11 TRANSISTOR 2SC4038-R-TL2
Q107 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
Q108 8-729-207-82 TRANSISTOR 2SC3421-Y
Q109 8-729-207-89 TRANSISTOR 2SA1358-Y
Q110 8-729-024-80 TRANSISTOR 2SC5100-Y
Q111 8-729-024-77 TRANSISTOR 2SA1908-Y
Q112 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
Q202 8-729-014-85 TRANSISTOR 2SA1618-YGRTE85R
Q203 8-729-014-87 TRANSISTOR 2SC4207-YGRTE85R
Q204 8-729-140-82 TRANSISTOR 2SA988TP-FA
Q205 8-729-184-53 TRANSISTOR 2SC1841TP-FA
Q206 1-809-603-11 TRANSISTOR 2SC4038-R-TL2
Q207 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
Q208 8-729-207-82 TRANSISTOR 2SC3421-Y
Q209 8-729-207-89 TRANSISTOR 2SA1358-Y
Q210 8-729-024-80 TRANSISTOR 2SC5100-Y
Q211 8-729-024-77 TRANSISTOR 2SA1908-Y
Q212 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
Q302 8-729-014-85 TRANSISTOR 2SA1618-YGRTE85R
Q303 8-729-014-87 TRANSISTOR 2SC4207-YGRTE85R
Q304 8-729-140-82 TRANSISTOR 2SA988TP-FA
Q305 8-729-184-53 TRANSISTOR 2SC1841TP-FA
Q306 1-809-603-11 TRANSISTOR 2SC4038-R-TL2
Q307 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
Q308 8-729-207-82 TRANSISTOR 2SC3421-Y
Q309 8-729-207-89 TRANSISTOR 2SA1358-Y
Q310 8-729-024-80 TRANSISTOR 2SC5100-Y
Q311 8-729-024-77 TRANSISTOR 2SA1908-Y
Q312 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
Q402 8-729-014-85 TRANSISTOR 2SA1618-YGRTE85R
Q403 8-729-014-87 TRANSISTOR 2SC4207-YGRTE85R
Q404 8-729-140-82 TRANSISTOR 2SA988TP-FA
10
Remark Ref. No.
0 Q405
0 Q406
0 Q407
0 Q408
0 Q409
0 Q410
0 Q411
Q412
Q901
Q902
278uH
Q903
Q904
Q905
Q906
Q907
Q908
Q909
Q910
Q911
Q912
Q914
Q915
Q916
Q917
Q918
Q919
Q920
R101
R102
R103
R104
R105
R106
R107
R126
R127
R128
R129
R130
R131
R132
R133
R134
R135
R136
R137
R138
R139
R140
R141
R142
Part No. Description
8-729-184-53 TRANSISTOR 2SC1841TP-FA
1-809-603-11 TRANSISTOR 2SC4038-R-TL2
8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
8-729-207-82 TRANSISTOR 2SC3421-Y
8-729-207-89 TRANSISTOR 2SA1358-Y
8-729-024-80 TRANSISTOR 2SC5100-Y
8-729-024-77 TRANSISTOR 2SA1908-Y
8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
8-729-869-84 TRANSISTOR 2SB698-G
8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
8-729-051-97 FET 2SK2420T
8-729-051-97 FET 2SK2420T
8-729-051-97 FET 2SK2420T
8-729-051-97 FET 2SK2420T
8-729-207-82 TRANSISTOR 2SC3421-Y
8-729-209-15 TRANSISTOR 2SD2012
8-729-018-59 TRANSISTOR 2SB1375(LB-SONY)
8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
< RESISTOR >
1-216-234-00 RES-CHIP 33K
1-208-522-61 RES-CHIP 33K
1-216-471-11 METAL OXIDE 27
1-208-529-61 RES-CHIP 62K
1-208-529-61 RES-CHIP 62K
1-208-826-11 RES-CHIP 68K
1-208-826-11 RES-CHIP 68K
1-208-826-11 RES-CHIP 68K
1-208-449-61 RES-CHIP 3.3K
1-208-449-61 RES-CHIP 3.3K
1-208-449-61 RES-CHIP 3.3K
1-208-449-61 RES-CHIP 3.3K
1-208-826-11 RES-CHIP 68K
1-208-365-61 RES-CHIP 100
1-216-699-11 METAL CHIP 100K
1-216-699-11 METAL CHIP 100K
1-208-365-61 RES-CHIP 100
1-249-953-11 CARBON 18K
1-249-539-11 CARBON 300
1-247-712-11 CARBON 820
1-249-538-11 CARBON 270
1-216-671-11 METAL CHIP 6.8K
1-249-536-11 CARBON 220
1-259-111-11 CARBON 4.7
Remark
2% 1/8W
2% 1/10W
5% 3W F
2% 1/10W
2% 1/10W
2% 1/10W
2% 1/10W
2% 1/10W
2% 1/10W
2% 1/10W
2% 1/10W
2% 1/10W
2% 1/10W
2% 1/10W
0.5% 1/10W
0.5% 1/10W
2% 1/10W
5% 1/4W
5% 1/4W
5% 1/4W
5% 1/4W
0.5% 1/10W
5% 1/4W
5% 1/4W
