- Page 1 IR PANEL HEATER MANUAL ON/OFF LOCK MODE TIME • Classic • Frameless • NXT GEN • Nexus • Image • Custom Image • Glass & Mirror Range Remote control only available with NXT Gen panels Remote control only available with Nexus panels...
-
Page 2: Table Of Contents
INTRO PRECAUTIONS SPECS TABLE SUSPENSION KIT INSTALLATION SEPARATELY SOLD CEILING BRACKET INSTALLATION SEPARATELY SOLD PANEL STAND INSTALLATION SEPARATELY SOLD CLASSIC INFRARED HEATING PANELS Included In The Box Device Structure Wall Installation PREMIUM FRAMELESS INFRARED HEATING PANELS Included In The Box... - Page 3 NEXUS WI FI/IMAGE/CUSTOM IMAGE INFRARED HEATING PANELS 10a. Included In The Box 10b. Device Structure 10c. Nexus Wi-Fi Remote Control Specs 10d. Built-In Nexus Wi-Fi Receiver Specs 10e. Nexus Wi-Fi Remote Control Diagram 10f. Nexus Wi-Fi Remote LCD Display 10g. Built-In Nexus Wi-Fi Receiver Diagram 10h.
-
Page 4: Intro
INTRO Thank you for purchasing your new infrared heater. When used properly, it should provide you with plenty of eco-friendly, energy saving infrared heat for many years to come. Please keep this manual safe for future reference. It contains lots of important information that will help you manage and look after your panel and ensure it lasts for as long as possible. -
Page 5: Precautions
PRECAUTIONS No Covering Do Not Touch Do Not Spray To prevent burns or injuries related to prolonged contact with the heating panel, children, those who suffer from sensitive skin, the elderly, the sick or those who are taking any medication that causes drowsiness should take extra care around the appliance. Do not damage, destroy, change, bend, stretch or press the power cord, otherwise it may result in fire or electric shock. -
Page 6: Specs Table
SPECS TABLE Available Sizes Rated Power Amps Heated Area 295mm x 595mm 180W 2 - 3m 0.75A 595mm x 595mm 350W 5 - 6m 1.46A 595mm x 995mm 580W 9 - 10m 2.42A 595mm x 1195mm 700W 11 - 12m 2.92A 795mm x 1195mm 900W... -
Page 7: Suspension Kit Installation Separately Sold
SUSPENSION KIT INSTALLATION SEPARATELY SOLD Suspension kits (sold separately) should only be used for ceiling installations, and if there is no suspended ceiling. Works with All Classic Panels (excpet 180W), All NXT Gen, All Nexus. B1x4 B2x4 4 x Suspension Cable (A) - Page 8 Remove the screws from the back of the frame of the Heating Panel. Take the loose end of the Cable (A2), and screw it into the holes that are now in the back of the frame of the Heating Panel. Repeat steps 1 to 7 for the other 3 remaining Cables (A) IR Panel Heater Manual...
-
Page 9: Ceiling Bracket Installation Separately Sold
350mm Bracket is only compatible with 350W, 580W, 700W NXT Gen Panels, & 580W, 700W Classic Panels. 500mm Bracket is only compatible with 900W NXT Gen Panel & 900W Classic Panel Remove Cap 1. Drill into your ceiling and mount both ceiling brackets. -
Page 10: Panel Stand Installation Separately Sold
Compatible with all Classic, NXT Gen, Nexus Wi-Fi, Image & Custom Image Panels. We recom- mend one pair of panel stands for sizes up to 700W, and two pairs of panel stands for 900W &... -
Page 11: Classic Infrared Heating Panels
CLASSIC INFRARED HEATING PANELS IR Panel Heater Manual... -
Page 12: 7A. Included In The Box
INCLUDED IN THE BOX A. Infrared Heater B. Screws C. Wall Plugs D. Mounting Template • This infrared panel heater is designed to provide an efficient, comfortable and healthy heating system for all domestic users and homeowners. • This infrared panel heater can reduce air circulation and help create and maintain a clean, silent and dust free environment. -
Page 13: 7B. Device Structure
DEVICE STRUCTURE FIR coating Heating Element Aluminum Frame Aluminum Alloy Hanging Bracket • Most of our panels come with a premium FIR coating that helps maximise the performance of your heating. It can withstand temperatures of up to 200°C without yellowing. •... -
Page 14: 7C. Wall Installation
WALL INSTALLATION Use the supplied paper to cover the back of the panel, and use a pencil to mark the locations of the holes. Use some double sided adhesive tape to fix the paper onto the wall or ceiling. Use this template to drill the holes. -
Page 15: Premium Frameless Infrared Heating Panels
PREMIUM FRAMELESS INFRARED HEATING PANELS IR Panel Heater Manual... -
Page 16: 8A. Included In The Box
INCLUDED IN THE BOX A. Infrared Heater B. Screws C. Wall Plugs D. Mounting Template • This infrared panel heater is designed to provide an efficient, comfortable and healthy heating system for all domestic users and homeowners. • This infrared panel heater can reduce air circulation and help create and maintain a clean, silent and dust free environment. -
Page 17: 8B. Device Structure
DEVICE STRUCTURE Powder Coated Aluminium Heating Element Aluminum Alloy Hanging Bracket • This panel comes with a Powder Coated Aluminium finish that helps provide a durable build that won't yellow over time, as well as maximising the performance of the heater itself. -
Page 18: 8C. Wall Installation
WALL INSTALLATION Use the supplied paper to cover the back of the panel, and use a pencil to mark the locations of the holes. Use some double sided adhesive tape to fix the paper onto the wall or ceiling. Use this template to drill the holes. -
Page 19: Nxt Gen Infrared Heating Panels
NXT GEN INFRARED HEATING PANELS ON/OFF LOCK MODE TIME IR Panel Heater Manual... -
Page 20: 9A. Included In The Box
INCLUDED IN THE BOX ON/OFF LOCK MODE TIME A. Infrared Heater B. Screws C. Wall Plugs D. Mounting Template E. Remote Control (ONLY provided with NXT Gen Panels) • This infrared panel heater is designed to provide an efficient, comfortable and healthy heating system for all domestic users and homeowners. -
Page 21: 9B. Device Structure
DEVICE STRUCTURE FIR coating Heating Element Aluminum Frame Aluminum Alloy Hanging Bracket • Most of our panels come with a premium FIR coating that helps maximise the performance of your heating. It can withstand temperatures of up to 200°C without yellowing. •... -
Page 22: 9C. Nxt Gen Remote Control Specs
NXT GEN REMOTE CONTROL SPECS NXT Gen Remote and NXT Gen features ONLY available with NXT Gen Panels. REMOTE CONTROL • Battery Powered: DC 3V (2 x 1.5V AAA Batteries, not included) • Power Consumption: 3V, 0.1mA • Dimensions: 135mm length x 56mm width x 18mm thickness •... -
Page 23: 9E. Nxt Gen Remote Control Diagram
NXT GEN REMOTE CONTROL DIAGRAM Lock Symbol Learn Symbol Heater On Indicator Battery Capacity Indicator Current Room ROOM 188.0 Target Room Temperature 188.0 Temperature SUN MON TUE WED THU FRI SAT Date M O D E 2088 Mode Settings SMART ON OFF 20:88 TIMER... -
Page 24: 9G. Built-In Nxt Gen Receiver Diagram
BUILT IN NXT GEN RECEIVER DIAGRAM Green override switch (remote will be in operation when this is switch of OFF) IR Panel Heater Manual... -
Page 25: 9H. Wall Installation
WALL INSTALLATION Use the supplied paper to cover the back of the panel, and use a pencil to mark the locations of the holes. Use some double sided adhesive tape to fix the paper onto the wall or ceiling. Use this template to drill the holes. -
Page 26: 9I. Pairing Your Nxt Gen Remote
PAIRING YOUR NXT GEN REMOTE • Included with each panel is a remote controller with an LCD digital display. This features an integrated room temperature sensor located at the top of the remote. • At the back of the panel itself is the integrated receiver that communicates with the remote controller. -
Page 27: 9J. Basic Functions
BASIC FUNCTIONS • Press the ‘on/off button’ to switch the heater on or off. • Press the ‘C/F toggle button’ to change between Celsius and Fahrenheit temperature displays. • Hold down the ‘Lock button’ for 3 seconds to lock the remote, and hold it again for 3 seconds to unlock the remote. -
Page 28: 9L. Timer & Temperature Settings
TIMER & TEMPERATURE SETTINGS • Hold down the 'Set button' for 3 seconds, this will let you set the timer and temperature settings. Initially, you will be able to set the time you would like the heater to switch on for Monday to Friday (indicated by the flashing '1-5' on the LCD display) - press the 'Up button' •... -
Page 29: 9M. Adaptive Start
ADAPTIVE START • Adaptive Start switches your panel on early so that you room is up to temperature at the time you set, by measuring the room temperature 3 hours before the start time, and calcu- lating how long it will take the room to warm up. •... -
Page 30: 9O. Unpairing Your Nxt Gen Remote
UNPAIRING YOUR NXT GEN REMOTE In some cases, you may want to unpair your remote from your NXT Gen IR Panel. Please follow the steps below to unpair your remote. • Hold the power button down on the remote for 5 seconds, or until the display on the remote disappears. -
Page 31: Nexus Wi Fi/Image/Custom Image Infrared Heating Panels
NEXUS WI FI/IMAGE/CUSTOM IMAGE INFRARED HEATING PANELS IR Panel Heater Manual... -
Page 32: 10A. Included In The Box
INCLUDED IN THE BOX A. Infrared Heater B. Screws C. Wall Plugs D. Mounting Template E. Remote Control (ONLY provided with Nexus Infrared Heating Panels) • This infrared panel heater is designed to provide an efficient, comfortable and healthy heating system for all domestic users and homeowners. •... -
Page 33: 10B. Device Structure
DEVICE STRUCTURE FIR coating Heating Element Aluminum Frame Aluminum Alloy Hanging Bracket • Most of our panels come with a premium FIR coating that helps maximise the performance of your heating. It can withstand temperatures of up to 200°C without yellowing. •... -
Page 34: 10C. Nexus Wi-Fi Remote Control Specs
NEXUS WI FI REMOTE CONTROL SPECS Nexus Infrared Remote and Nexus features ONLY available with Nexus Infrared Panels, Image Panels and Custom Image Panels. REMOTE CONTROL • Battery Powered: DC 3V (2 x 1.5V AAA batteries, not included) • Consumption: 3V 0.1mA •... -
Page 35: 10E. Nexus Wi-Fi Remote Control Diagram
NEXUS WI FI REMOTE CONTROL DIAGRAM The remote control and integrated receiver allow full control of the operation of the heater. The remote control reads the current room temperature using a sensor located at the top of the unit, and sends real time data to the receiver. The screen on the remote control can display the current room temperature, target temperature, lock status, battery level, heating status and Wi-Fi status. -
Page 36: 10F. Nexus Wi-Fi Remote Lcd Display
NEXUS WI FI REMOTE LCD DISPLAY • The “ ” symbol indicates when the IR Panel is beaming out heat. • The “ ” symbol indicates that the button on the remote controller are locked. • The “ ” symbol indicates when your heater is connected to your Wi-Fi network. •... -
Page 37: 10H. Wall Installation
WALL INSTALLATION Use the supplied paper to cover the back of the panel, and use a pencil to mark the locations of the holes. Use some double sided adhesive tape to fix the paper onto the wall or ceiling. Use this template to drill the holes. -
Page 38: 10I. Pairing Your Nexus Wi-Fi Remote
PAIRING YOUR NEXUS WI FI REMOTE Before starting, please ensure that you have inserted 2 x 1.5V AAA batteries into the remote control. Power on your panel heater by connecting it to a plug socket, using the 3-pin plug at the end of the flex cable. -
Page 39: 10K. Electronic Temperature Control
ELECTRONIC TEMPERATURE CONTROL • To increase the target temperature by 1 °C, press the Temperature + button. Similarly, to decrease the target temperature by 1 °C, press the Temperature - button. • Alternatively, you can hold down the Temperature + or Temperature - buttons to increase or decrease the target temperature continuously. -
Page 40: 10M. Connecting Your Nexus Wi-Fi Panel To Wi-Fi
CONNECTING YOUR NEXUS PANEL TO WI-FI Scan QR code for video instructions on how to pair your Nexus panel to your home Wi-fi Network. Before you start: Please make sure your phone/tablet/smart device is connected to a 2.4GHz Wi-Fi signal. All Wi-Fi routers emit a 2.4GHz signal, but some newer models emit both 2.4GHz and 5GHz. - Page 41 In the Smart Life app, select the add device button, then ‘Small home appliances.’ Then select ‘Wi-Fi Heater’. You will be prompted to enter your Wi-Fi password, but don’t do so yet. On the back of the panel, press and hold the Wi-Fi reset button for at least five seconds. The indicator LED on the front of the panel will start to blink rapidly.
- Page 42 Enter your Wi-Fi password. WI-FI WI-FI Confirm the light on the panel is blinking slowly. The app will now ask you to connect your phone to the device's hotspot. Follow the prompts provided to do so. If the phone prompts you, tell it you only wish to connect to this network once.
-
Page 43: Glass/Mirror Infrared Heating Panels
GLASS/MIRROR INFRARED HEATING PANELSS IR Panel Heater Manual... -
Page 44: 11A. Included In The Box
INCLUDED IN THE BOX A. Infrared Heater B. Screws C. Wall Plugs D. Mounting Template • This infrared panel heater is designed to provide an efficient, comfortable and healthy heating system for all domestic users and homeowners. • This infrared panel heater can reduce air circulation and help create and maintain a clean, silent and dust free environment. -
Page 45: 11B. Device Structure
DEVICE STRUCTURE Toughened Glass Heating Element Aluminum Alloy Hanging Bracket • The toughened glass ensures that your panel is durable enough for daily use. • The carbon crystal heating element will distribute • The hanging bracket can be used to hang your panel on the wall, or used alongside your suspension kit or ceiling bracket. -
Page 46: 11C. Wall Installation
WALL INSTALLATION Use the supplied paper to cover the back of the panel, and use a pencil to mark the locations of the holes. Use some double sided adhesive tape to fix the paper onto the wall or ceiling. Use this template to drill the holes. -
Page 47: Maintenance & Servicing
This infrared heating panel requires no servicing, and very little maintenance. When cleaning any Classic , Frameless , Nexus , Glass or Mirror IR panel, you can use a damp cloth and gently wipe the surface of the panel. 3. When cleaning any Image or Custom Image IR Panel, use a dry cloth to gently wipe the surface of the panel to prevent any damage to the ink. -
Page 48: Troubleshooting
TROUBLE SHOOTING Symptom Cause/Solution Double check that the heater is connected to a power source, and The heater will not turn on that there is no damage to the flex cable. Try connecting a working electrical appliance to the same socket to determine the circuit is working. -
Page 49: Disposal
• When installing the panel on your ceiling, you must use a Suspension Kit and leave a space of at least 50mm between the ceiling and the panel, or use a Ceiling Bracket. Our panels can be installed on your wall in both portrait and landscape orientations. •... - Page 50 86 Scudamore Road Leicester, LE3 1UQ +44 (0) 116 436 2250...
