- Page 1 MD R a n g e O p e r a t o r s H a n d b o o k Covering Models:- MD35/20 MD75/150 MD75/150V MD75/250 MD75/250V MD150/500 MD225/1000 BAMBI AIR LTD 152 Thimble Mill Lane Heartlands Birmingham B7 5HT United Kingdom Tel: 0121 322 2299 Fax: 0121 322 2297 Email: sales@bambi-air.co.uk www.bambi-air.co.uk...
-
Page 3: Warranty
Bambi reserves the right to modify the contents of this operating booklet without notice and the information is in no way binding on the company. -
Page 4: Safety Precautions
Safety Precautions Bambi 1110S compressor oil does not contain hazardous components and is not required to be labelled dangerous, What you must do according to the Classification, • Read these instructions before using Packaging and Labelling of Dangerous your air compressor. -
Page 5: Operation
Operation Refer to exploded parts diagrams and illustrations when reading this section. Oil level Your Bambi compressor is shipped without oil for transit. Before use you must fill the motor to the correct level. Models 75/80 to 225/1000 • Remove air intake filter housing by pulling gently out of intake tube - see fig 9 •... -
Page 6: Routine Maintenance
Routine Maintenance Draining the Air Receiver Drain condensate from air receiver at a pressure of no more than 2 Bar. Slowly open the drain tap provided to allow water to flow out – see figs 7 & 8. Close drain tap when all water has drained off. Do not overtighten, this will damage the tap seal. -
Page 7: Preventative Maintenance
Preventative Maintenance Operation Daily Weekly Monthly Annually Drain air receiver < 15 Litres • Drain air receiver > 15 Litres • Drain filter regulator • Check oil level • Change oil • Replace air intake filter • Replace filter regulator element •... - Page 8 MD35/20 Ref No. Description Part no. Ref No. Description Part no. 4 litre vessel BPB1094 Non-return valve BPB1086 Filter regulator BPB1080 Pressure switch BPB1074 Regulator gauge BPB1077 1/4” 10 Bar relief valve BPB1084 1/4” Male/Female elbow BPB1139 Handle insert BPB0078...
- Page 9 MD75/150 Ref No. Description Part no. Ref No. Description Part no. 15 litre vessel BPB1099b Filter regulator BPB1080 140mm wheel BPB1144 Regulator gauge BPB1077 Starlock washer BPB1091 Vessel pressure gauge BPB1081 Inspection plug BPB0243 1/4” Extension BPB0152 Inspection plug seal BPB0502 Drain tap BPB1138...
- Page 10 MD 75/150V Ref No. Description Part no. Ref No. Description Part no. 15 litre vessel BPB1099 Vessel pressure gauge BPB1081 Non-return valve BPB1086 1/4” Male/Female/Female tee BPB1109 500mm delivery pipe BPB1087a Drain tap BPB1138 Pressure switch BPB1074 Inspection plug BPB0243 1/4”...
- Page 11 MD75/250 Ref No. Description Part no. Ref No. Description Part no. 24 litre vessel BPB1088b On/off valve BPB1079 Inspection plug seal BPB0502 Filter regulator BPB1080 Inspection plug BPB0243 Regulator gauge BPB1077 200mm Delivery pipe BPB1102 Vessel pressure gauge BPB1081 Non-return valve BPB1086 1/4”...
- Page 12 MD 75/250V Ref No. Description Part no. Ref No. Description Part no. 24 litre vessel BPB1088 Drain tap BPB1138 Non-return valve BPB1086 Rubber foot BPB0247 500mm Delivery pipe BPB1087a Inspection plug seal BPB0502 Pressure switch BPB1074 Inspection plug BPB0243 1/4” 10 Bar relief valve BPB1084 1/4”...
- Page 13 MD150/500 Ref No. Description Part no. Ref No. Description Part no. 50 litre vessel BPB1097 Pressure switch BPB1074 Inspection plug BPB0243 1/4” Male / 1/4” Male adaptor BPB1078 Inspection plug seal BPB0502 On/off valve BPB1079 300mm Delivery pipe BPB1087 Filter regulator BPB1080 1/4”...
- Page 14 MD225/1000 Ref No. Description Part no. Ref No. Description Part no. 100 litre vessel BPB1105 Drain tap BPB1138 Inspection plug BPB0243 Siphon tube BPB0035 Inspection plug seal BPB0502 Pressure switch BPB1074 300mm Delivery pipe BPB1087 1/4” Male / 1/4” Male adaptor BPB1078 1/4”...
- Page 15 Ref No. Description Part no. Motor / Pump Parts: Mounting set BPB1008 75 model Bottom casing BPB1011 Large rubber gasket BPB1007 Closing ring BPB1005 Bearing bolt BPB1025 Mounting spring BPB1038a Delivery gasket BPB1026 Delivery mufflers BPB1128 Pressure pipe BPB0132 Pressure pipe bolt BPB1027 Pressure pipe horse shoe BPB0108...
- Page 16 Fig 1 Fig 2 Fig 3 Fig 4 “Click” Fig 5...
- Page 17 Fig 6 Fig 7 “Click” Fig 8 Fig 9 Fig 6...
-
Page 18: Service Record
SERVICE RECORD Date installed____________________________ Date Maintenance work Signature / Company SERVICE KITS BPVT 1 Service Kit covers models: BPB1122A Service Kit type 35 pump unit VT75 / VT150 / VT250 (2 kits) VT300 (2 kits) – including H/D/S variants BB24D (2 Kits) BB50D (2 Kits) BPVT2 Service Kit covers models: BPB1124A Service Kit type 75 pump unit... - Page 19 NOTES...
- Page 20 Declaracion de Conformidad CE - EG Verklaring van Overeenstemming Declaracion de Conformidad CE - EG Verklaring van Overeenstemming Bambi Air Ltd declares that this product conforms to the European Bambi Air Compressors declares that this product conforms to the European Directives listed below.
