Pelican NEMO 2400, 2400N - Flashlight Manual

If the pellets become wet, let them air dry. Pelican Products assumes no liability for any brand batteries which are defective or cause injury to anyone when used in any Pelican flashlight.

Battery Replacement

Do not mix battery brands or use Nicad or Zinc Carbon Batteries. Do not mix old and new batteries. Replace all batteries at the same time.
DO NOT MODIFY THIS PRODUCT!

Battery Safety Bulletin

Alkaline Batteries

1. Hazardous location safety approvals for explosive environments are only valid for the specified cell type manufacturer and, where applicable, brand names that are displayed on the flashlight and/or instructions sheets that are supplied with the light.
2. The use of other battery technologies may reduce the performance of the the flashlight. Always read the battery manufacturers recommendations for the appropriate use of the battery technology/brand prior to using them in the flashlight.
3. When replacing the batteries:
   1. Replace all the batteries at the same time.
   2. Do not mix battery brands and old and new batteries.
   3. Always insert batteries correctly with regard to polarity (+ and -) marked on the battery and equipment.
4. Do not change batteries in a hazardous location.
5. Remove batteries from equipment if it is not to be used for an extended period of time.

PELICAN LEGENDARY FULL LIFETIME GUARANTEE OF EXCELLENCE

Pelican Products, Inc. guarantees its lights for a lifetime against breakage or defects in workmanship. This guarantee does not cover the lamp or batteries (rechargeable or alkaline).
Pelican will either repair or replace any defective product, at our sole option. THE REMEDIES HEREBY PROVIDED SHALL BE THE EXCLUSIVE AND SOLE REMEDY OF THE PURCHASER.
To make a warranty claim, the purchaser must contact Pelican Products, Inc. at 23215 Early Avenue, Torrance, CA 90505 or sales@pelican.com. The purchaser must obtain a return authorization number from Pelican Customer Service prior to returning any product.
Refer to www.pelican.com/warranty for full details

BATTERY INSTALLATION

1. Remove lens housing by turning counter-clockwise.
2. Remove the lamp and contact module.
3. Remove used batteries and replace with fresh batteries as shown on the outside of the engraved body.
4. Replace the contact module and lamp.
5. Replace lens housing squarely on threads and turn clockwise while pressing on the lens housing slightly.

ON/OFF

Swing the switch lever to the right (light facing away from you) until light activates. To turn light off, swing the switch lever to the left (light facing away from you) until light goes off.

SCUBA DIVING APPLICATION

(Follow these instructions whenever you replace the batteries) Check closely for cuts, scratches, or otherwise damaged o-ring or mating lens lip surface as this can cause your light to flood instantly under pressure. Remove any salt deposits, sand, dirt, and foreign matter from O-ring sealing surfaces. KEEP THREADS, O-RING GROOVE AND INSIDE LIP OF LENS LUBRICATED WITH SILICONE GREASE.

LAMP REPLACEMENT

1. Remove lens housing by turning counter-clockwise.
2. Remove the lamp and contact module.
3. Replace the contact module and lamp.
4. Replace lens housing squarely on threads and turn clockwise while pressing on the lens housing slightly.

If light is not to be used for some time, remove batteries to prevent possible leakage and corrosion.

PRODUCT SPECIFICATIONS

Lamp Type: Xenon
Lamp Life: 30 hours
Battery Type: E91 1.5V Alkaline AA-cell (4)

REPLACEMENT PARTS

Read This Notice Before Use.
Hydrogen Gas Absorber Pellets Located inside the flashlight are catalyst pellets which are present to absorb hydrogen gas that could possibly be emitted by defective, leaking, reversed polarity or heavily discharged batteries.

23215 Early Ave.

• Torrance, CA 90505 USA

Tel (310) 326-4700

• FAX (310) 326-3311 www.pelican.com

PELICAN CANADA

10221-184 St.

• Edmonton, Alberta T5S 2J4

Tel (780) 481-6076

• FAX (780) 481-9586

PELI PRODUCTS, S.L.U.
c/ Provença, 388, Planta 7

• 08025
• Barcelona, Spain

Tel: +34 934 674 999

• Fax: +34 934 877 393

© PELICAN PRODUCTS 2011
All trademarks and logos displayed herein are registered and unregistered trademarks of Pelican Products, Inc. and others.
Eveready and Energizer are registered trademarks of Eveready Battery Company, Inc.
