Countertop Installation

Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Installation
1.
Select a level surface that provide
enough open space for the intake
and/or outlet vents.
12 inches (30cm)
3.0 inches (7.5cm)
OPEN
3.0 inches (7.5cm)
A minimum clearance of 3.0 inches
(7.5cm) is required between the oven and
any adjacent walls. One side must be open.
(1) Leave a minimum clearance of 12
inches (30cm) above the oven.
(2) Do not remove the legs from the
bottom of the oven.

Optional Accessories

Available at extra cost through www.kenmore.com or by calling the following customer
assistance number: 1-844-553-6667
Choose the appropriate Installation Kit to convert this oven to a built-in wall oven.
For 27" installations:
Model
111.72219 / 111.72213
For 30" installations:
Model
111.72219 / 111.72213
Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do not remove the off-white Mica cover
that is attached to the oven cavity to
protect the magnetron.
(3) Blocking the intake or outlet vent openings
can damage the oven.
(4) Place the oven as far away from
radios and TV as possible.
Operation of microwave oven may
cause interference to your radio or TV
reception.
2.
Plug your oven into a standard household
outlet. Be sure the voltage and the
frequency is the same as the voltage
and the frequency on the rating label.
WARNING: Do not install oven over a
range cooktop or other heat-producing
appliance. If installed near or over a heat
source, the oven could be damaged and the
warranty would be void.
kit
22703 – Stainless Steel
kit
22003 – Stainless Steel /
EN-7
22009 – Black
