Operating Instructions
Radar sensor for continuous level
measurement
VEGAPULS 42
Three-wire with IO-Link (2 x transistor or
4 ... 20 mA plus 1 x transistor)
Document ID: 1016153

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEGAPULS 42 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vega VEGAPULS 42

Summary of Contents for Vega VEGAPULS 42

  • Page 1 Operating Instructions Radar sensor for continuous level measurement VEGAPULS 42 Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor) Document ID: 1016153...

  • Page 2: Table Of Contents

    10.1 Maintenance ........................29 10.2 Rectify faults ........................29 10.3 Diagnosis, fault messages ..................... 30 10.4 Status messages according to NE 107 ................30 VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 3 These instructions are attached as documents to each instrument with Ex approval and are part of the operating instructions. Editing status: 2023-03-15 VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 4: About This Document

    The dot set in front indicates a list with no implied sequence. Sequence of actions Numbers set in front indicate successive steps in a procedure. Disposal This symbol indicates special instructions for disposal. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 5: For Your Safety

    No health impairments are to be expected with intended use. The band range of the measuring frequency can be found in chapter " Technical data". VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 6: Country Of Use - Radar Signal

    Installations in the US shall comply with the relevant requirements of the National Electrical Code (ANSI/NFPA 70). Installations in Canada shall comply with the relevant requirements of the Canadian Electrical Code. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 7: Product Description

    Scope of this operating This operating instructions manual applies to the following instrument instructions versions: • Hardware version from 1.0.0 • Software version from 1.0.0 VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 8: Principle Of Operation

    VEGAPULS 42 is a radar sensor for non-contact, continuous level measurement of liquids. Functional principle The instrument emits a continuous, frequency-modulated radar signal through its antenna. The emitted signal is reflected by the medium and received by the antenna as an echo with modified frequency. The VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 9: Adjustment

    Unless otherwise indicated, the packages must be stored only under the following conditions: • Not in the open • Dry and dust free • Not exposed to corrosive media VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 10: Accessories

    Technical data - Ambient conditions" • Relative moisture 20 … 85 % Accessories Accessories and related instructions can be found on our homepage. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 11: Mounting

    The measuring range of the VEGAPULS 42 physically begins with the antenna end. However, the min./max. adjustment begins mathematically with the reference plane, which is located differently depending on the sensor version. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 12 In vessels with conical bottom it can be advantageous to mount the device in the centre of the vessel, as measurement is then possible down to the bottom. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 13 Fig. 6: Thread mounting If the reflective properties of the medium are good, you can mount VEGAPULS 42 on sockets longer than the antenna. The socket end should be smooth and burr-free, if possible also rounded. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 14 " clear view" to the measured product. In case of existing vessel installations, a false signal suppression should be carried out during setup. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 15 Fig. 10: Agitators Through the action of filling, stirring and other processes in the vessel, Foam generation compact foams which considerably damp the emitted signals may form on the medium surface. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 16 If foams lead to measurement errors, you should use the biggest pos- sible radar antennas or as an alternative, sensors with guided radar. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 17: Connecting To Power Supply

    Connection procedure M12 x 1 plug This plug connection requires a complete confectioned cable with counter plug. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 18: Wiring Plan

    The output signal jumps to the set fault current • Switching outputs are controlled The current measured value is then output on the signal cable. With current output activated VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 19: Access Protection

    " Ac- cess protection". If this document is lost, the emergency device code can be retrieved from your personal contact person after legitimation. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 20: Storing The Codes In Myvega

    " PINs and Codes". This greatly simplifies the use of additional adjust- ment tools, as all Bluetooth access and device codes are automati- cally synchronized when connected to the " myVEGA" account VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 21: Setup With Smartphone/Tablet (Bluetooth)

    The message " Waiting for authentication" is displayed on the smart- phone/tablet. Connected After connection, the sensor adjustment menu is displayed on the respective adjustment tool. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 22: Parameter Adjustment

    The selected menu item can be recognized by the colour change. Fig. 13: Example of an app view - Setup measured values Enter the requested parameters and confirm via the keyboard or the editing field. The settings are then active in the sensor. Close the app to terminate connection. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 23: Setup With Pc/Notebook (Bluetooth)

    Enter Bluetooth access For authentication, enter in the next menu window the 6-digit code Bluetooth access code: Fig. 14: Enter Bluetooth access code VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 24: Parameter Adjustment

    The DTMs can also be integrated into other frame applications according to FDT standard. Fig. 15: Example of a DTM view - Setup, sensor adjustment VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 25: Menu Overview

    Selection Adjustment options Units Temperature unit of the instrument °C, °F, K Damping Integration time (DAM) in s 0 … 999 s VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 26 Colour selection, flashing yes/no False signal suppression Create new, expand, delete Sounded distance to the medium from the 0 … 15 m antenna edge VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 27 Device name, order number, serial number, hardware/software version, factory calibra- tion Sensor characteristics Sensor features from order text Measured value memory (DTM) Indication measured value memory from VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 28: Explanation Special Parameters

    Here you can switch over if the adjustment and the measured value output is carried out in " Distance" or " Filling height". VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 29: Diagnostics And Servicing

    VEGA service hotline under the phone no. +49 1805 858550. The hotline is also available outside normal working hours, seven days a week around the clock. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 30: Diagnosis, Fault Messages

    Signalling of process pressure ranges by colour and flashing, adjustable via VEGA Tools app or PACTware/DTM. Delivery status; adjustable via VEGA Tools app or PACTware/DTM VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 31 No measured value in the switch-on Check or correct installation and/or pa- phase or during operation rameter settings no measured value available Clean the antenna system VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 32 Error when carrying out a reset settings False signal suppression faulty M508 Checksum error in Bluetooth software Carry out software update No executable Bluetooth software VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 33: Treatment Of Measurement Errors

    (e.g. condensation, build- false signals, carry out false signal sup- time up); false signal suppression no longer pression, e.g. with condensation. matches actual conditions VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 34 The max. level (0 m distance) Remove contamination on the antenna as well as the status message " Overfill protection" are output. time VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 35: Software Update

    Clean the instrument and pack it damage-proof • Attach the completed form and, if need be, also a safety data sheet outside on the packaging VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 36 10 Diagnostics and servicing • Ask the agency serving you to get the address for the return ship- ment. You can find the agency on our homepage. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 37: Dismount

    If personal data is stored on the old device to be disposed of, delete it before disposal. If you have no way to dispose of the old instrument properly, please contact us concerning return and disposal. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 38: Certificates And Approvals

    Protection of the environment is one of our most important duties. That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 39 Help us to meet these requirements and observe the environmental instructions in the chapters " Packaging, transport and storage", " Disposal" of this operating instructions. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 40: Supplement

    0 mm (0 in) Switch-on phase Run-up time for U < 5 s Starting current active current output ≤ 3.6 mA IO-Link communication readiness VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 41 Overload resistance Short-circuit resistance Permanently Voltage loss < 3 V Inverse current PNP < 10 µA Inverse current NPN < 25 µA VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 42 Fig. 18: Deviation under reference conditions Reference plane Antenna edge Recommended measuring range In case of deviations from reference conditions, the offset due to installation can be up to ± 4 mm. This offset can be compensated by the adjustment. Already included in the meas. deviation VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 43 -1 … 16 bar (-100 … 1600 kPa/-14.5 … 232.06 psig) Process temperature -40 … +130 °C (-40 … +266 °F) Temperature derating Outside the specified beam angle, the energy level of the radar signal is 50% (-3 dB) less. EIRP: Equivalent Isotropic Radiated Power VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 44 12 … 35 V DC Operating voltage U - IO-Link commu- 18 … 35 V DC nication Depending on the local conditions; with M12 x 1 plug stainless steel (closed full metal housing) effective range up to approx. 5 m (16.40 ft) VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 45: Io-Link

    HexCode Remark, value MasterCycleTime MinCycleTime 0x28 5 ms = 35 V DC, output signal = 20 mA Load current = 250 mA VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 46 IO-Link specific device data Data ISDU (dez) ISDU (hex) Size (Byte) Data type Access Value DeviceAccess 0x000C Profile Identification 0x000D 0x0018 0x4000 PD-Descriptor 0x000E U8[12] VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 47 0x0105 String19 (TAG) Device Revision 0x010B Unit of Lenght 0x010C 1010 = m 1013 = mm 1018 = ft 1019 = in VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 48 0=Individually colour, Switching output 1=Red, 2=Orange, 3=White, 4=Green, 5=Blue, 6=Yellow, 7=No signalling Siganlizing switching output: 0x011E 0=No, 1= Yes switching output Flashing VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 49 Free signalling: Flashing 0x012F 0 = No, 1 = Yes range 2 Free signalling: Upper lim- 0x0130 Float 0 … 15000 it range 2 VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 50 0 … 255 1 Blue Switching output: Range 0x0142 0 … 255 1 Red Switching output: Range 1 0x0143 0 … 255 Green VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 51 0 = No, 1 = Yes uring range begin (2) Manual limitation of the 0x0156 Float 0 … 15000 measuring range begin VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 52 0x0171 0 = Off, 1 = On Maintenance required 0x0172 0 = Off, 1 = On Device name 0x0173 String19 Serial number 0x0174 String16 Software version 0x0175 String19 Hardware version 0x0176 String19 VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 53 Back to Box Reset 0x00A2 Reset pointer distance 0x00A0 Reset pointer measurement reliability 0x00A1 Reset pointer electronics temperature 0x00A2 Reset pointer meas. rate 0x00A3 VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 54: Dimensions

    Fig. 20: Dimensions VEGAPULS 42 without display Thread G¾ Thread G1 Hygienic version thread G1 with O-ring Hygienic version thread G1 with cone VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 55 Fig. 21: Dimensions VEGAPULS 42 with display Thread G¾ Thread G1 Hygienic version thread G1 with O-ring Hygienic version thread G1 with cone VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)

  • Page 56: Industrial Property Rights

    13.6 Trademark All the brands as well as trade and company names used are property of their lawful proprietor/ originator. VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 57 Notes VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 58 Notes VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 59 Notes VEGAPULS 42 • Three-wire with IO-Link (2 x transistor or 4 … 20 mA plus 1 x transistor)
  • Page 60 Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2023 VEGA Grieshaber KG Am Hohenstein 113 Phone +49 7836 50-0 77761 Schiltach E-mail: info.de@vega.com...
